porter cale FN250A Instruction Manual

Finish nailer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Instruction
manual
To learn more about Porter-Cable
visit our website at:
http://www.porter-cable.com
Copyright © 2003 Porter-Cable Corporation
ESPAÑOL: PÁGINA 13
FRANÇAISE : PAGE 25
FINISH NAILER
MODEL FN250A
IMPORTANT
Please make certain that the person who is
to use this equipment carefully reads and
understands these instructions before
starting operations.
The Model and Serial No. plate is located on the main
housing of the tool. Record these numbers in the
spaces below and retain for future reference.
Model No. ______________________________________
Type ___________________________________________
Serial No. _______________________________________
Part No. 903096 - 05-09-03

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FN250A and is the answer not in the manual?

Questions and answers

Summary of Contents for porter cale FN250A

  • Page 1 ESPAÑOL: PÁGINA 13 FRANÇAISE : PAGE 25 Instruction FINISH NAILER manual MODEL FN250A IMPORTANT Please make certain that the person who is To learn more about Porter-Cable to use this equipment carefully reads and visit our website at: understands these instructions before http://www.porter-cable.com...
  • Page 2 ✦ ✦ PORTER CABLE Porter-Cable Corporation 4825 Highway 45 North Jackson, TN 38305 ENGLISH EC-DECLARATION OF CONFORMITY W e d e c l a r e u n d e r o u r s o l e r e s p o n s i b i l i t y t h a t t h i s p r o d u c t i s i n c o n f o r m i t y w i t h t h e r e g u l a t i o n s E N 2 9 2 - 2 : s e c t i o n 3 o f 1 9 9 2 E N 2 9 2 - 1 : s e c t i o n 5 o f 1 9 9 2...

  • Page 3: Safety Guidelines - Definitions

    SAFETY GUIDELINES / DEFINITIONS This manual contains information that is important for you to know and under- stand. This information relates to protecting YOUR SAFETY and PREVENTING EQUIPMENT PROBLEMS. To help you recognize this information, we use the symbols below. Please read the manual and pay attention to these sections. indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.

  • Page 4: General Safety Rules

    GENERAL SAFETY RULES 1. Read and understand tool labels and Fig. 1 manual. Failure to follow warnings could result in DEATH or SERIOUS INJURY. Fig. 1. 2. Operator and others in work area MUST Fig. 2 wear safety glasses with side shields. These safety glasses must conform to ANSI Z87.1 requirements (approved glasses have “Z87”...
  • Page 5 Do not connect tool to pressure which potentially exceeds 200 PSI (13.7 BAR). 10. Only use air hose that is rated for a maximum working pressure of at least 150 PSI (10.3 BAR) or 150% of the maximum system pressure, which ever is greater. 11.

  • Page 6: Technical Specifications

    21. Remove finger from trigger when not Fig. 14 driving fasteners. Never carry tool with finger on trigger. In “Contact Actuation Mode” tool will fire a fastener if safety is bumped while trigger is depressed. Fig. 14. 22. Do not overreach. Keep proper footing and balance at all times when using or handling the tool.

  • Page 7: Employer's Responsibilities

    SERIOUS INJURY. Read and follow all of these instructions carefully. FUNCTIONAL DESCRIPTION FOREWORD Porter-Cable Model FN250A is a heavy duty pneumatic finish nailer. It is designed to install 16 ga. finish nails of various lengths (from " to 2- "...
  • Page 8 Never point tool at yourself or others. Always connect tool to air supply before loading fasteners (Fig. 18). Do not load fasteners with trigger or safety depressed. Only use approved Porter-Cable fasteners. Operator and others in work area MUST wear safety glasses with side shields.

  • Page 9: Fastener Guide

    Fig. 25 A Fastener Guide (A) Fig. 23 and 24, is factory installed on Model FN250A. The Guide is held in place with a bolt and nut (B) Fig. 23 and 24. The Fastener Guide must be used whenever driving fasteners that are less than 1 "...

  • Page 10: Clearing A Jammed Fastener

    Remove finger from trigger when not driving fasteners. Never carry tool with finger on trigger: tool will fire a fastener if safety is bumped. Keep fingers AWAY from trigger when not driving fasteners to avoid accidental firing. Never carry tool with finger on trigger.

  • Page 11: Maintenance

    Fig. 28 Fig. 27 MAINTENANCE CLEAN AND INSPECT DAILY Disconnect tool from air supply before cleaning and inspection. Correct all problems before placing the tool back in use. Wipe tool clean and inspect for wear or damage. Use non-flammable cleaning solutions to wipe exterior of tool only if necessary. DO NOT SOAK tool with cleaning solutions.
  • Page 12 2. Tool does nothing or Inadequate air supply. Verify adequate air supply. operates sluggishly. Inadequate lubrication. Put 5 or 6 drops of oil into air inlet. Worn or damaged Install Overhaul Kit. o-rings or seals. 3. Air leak near bottom Loose screws.
  • Page 13 PORTER-CABLE • DELTA SERVICE CENTERS (CENTROS DE SERVICIO DE PORTER-CABLE • DELTA) (CENTRE DE SERVICE PORTER-CABLE • DELTA) Parts and Repair Service for Porter-Cable • Delta Power Tools are Available at These Locations (Obtenga Refaccion de Partes o Servicio para su Herramienta en los Siguientes Centros de Porter-Cable • Delta) (Locations où...
  • Page 15 Parts List for FN250A Type 1 Item Number Part Number Description Qty Required 904673 WARNING LABEL 904673 WARNING LABEL 000000-00 No Longer Available 000000-00 No Longer Available 883827 SPRING WASHER 903143 CYLINDER CAP ASSY 903143 CYLINDER CAP ASSY 883912 SET SCREW...
  • Page 16 Parts List for FN250A Type 1 Item Number Part Number Description Qty Required 886079 O-RING 891022 CYLINDER 886119 CHECK SEAL 886122 BUMPER 886121 CYLINDER SPACER 886098 O-RING 886123 DRIVER GUIDE 897480 BASE 903505 MUFFLER 890245 MUFFLER A08368 SS/A TRIGGER VALVE K...
  • Page 17 Parts List for FN250A Type 1 Item Number Part Number Description Qty Required 883942 O-RING 5140030-09 BOTTOM FIRE TRIGGER 893077 RESTRICTIVE TRIGGER 893930 BOTTOM FIRE TRIGGER 5140030-10 RESTRICTIVE TRIGGER 883945 ROLLED PIN 884404 ROLLED PIN 890722 TRIGGER PIVOT PIN 884404...
  • Page 18 Parts List for FN250A Type 1 Item Number Part Number Description Qty Required 886109 SPRING 886069 E-RING 893809 PUSHER 886135 CHANNEL 886261 BOLT 893810 MAGAZINE COVER 886126 SPRING 883882 LOCK NUT 886447 DRIVER GUIDE SAFETY 883898 BOLT 883866 BOLT 883867...
  • Page 19 Parts List for FN250A Type 1 Item Number Part Number Description Qty Required 883864 BOLT 893812 MAGAZINE ASSY. 898283 DRIVER GDE/MAG. ASSY 884541 SCREW 894745 BOLT 891903 HEX WRENCH 2.5MM 884298 HEX WRENCH (4MM) 884297 HEX WRENCH (3MM) 884293 AIR TOOL OIL (18CC)
