Summary of Contents for Quanmax QBOX-2060
- Page 1 QBOX-2060 ® Fanless BOX PC with Dual Core Intel Atom™ Processor D2550 User’s Guide QBOX-2060 User’s Manual...
- Page 2 © 2012 Quanmax Inc. All rights reserved. The information in this user’s guide is provided for reference only. Quanmax does not assume any liability arising out of the application or use of the information or products described herein. This user’s guide may contain or reference information and products protected by copyrights or patents and does not convey any license under the patent rights of Quanmax, nor the rights of others.
-
Page 3: Table Of Contents
Chapter 3 AMI BIOS Setup ..................25 Overview ....................25 Main Menu ....................26 Advanced Menu ..................27 Boot Menu ....................38 Security Menu .................... 39 Save & Exit Menu ..................39 Chapter 4 D river Installation .................. 41 QBOX-2060 User’s Manual... -
Page 4: Figures
Figure 4 DVI-I / HDMI ................20 Figure 5 Connect USB mouse & keyboard ..........21 Figure 6 RJ45 connector ................21 Figure 7 Com ports ..................22 Figure 8 DIO port ..................23 Figure 9 Turning on the system ..............24 QBOX-2060 User’s Manual... -
Page 5: Tables
Tables Tables Table 1 QBOX-2060 Specification .............. 16 Table 2 BIOS Main Menu ................26 Table 3 Advanced Menu ................27 Table 4 Advanced Menu – Display Configuration ........28 Table 5 Advanced Menu –Power Management Configuration ....29 Table 6 Advanced Menu –CPU Advanced Configuration ......30 Table 7 Advanced Menu –SATA Configuration ........... -
Page 6: Safety Instructions
Use extreme caution when installing or removing components. Refer to the installation instructions in this user’s guide for precautions and procedures. If you have any questions, please contact Quanmax Post-Sales Technical Support. Access can only be gained by service persons or by users who have ... -
Page 7: When Working Inside A Computer
Also, before connecting a cable, make sure both connectors are correctly oriented and aligned. CAUTION Do not attempt to service the system yourself except as explained in this user’s guide. Follow installation and troubleshooting instructions closely. QBOX-2060 User’s Manual... -
Page 8: Preventing Electrostatic Discharge
Static electricity can harm system boards. Perform service at an ESD workstation and follow proper ESD procedure to reduce the risk of damage to components. Quanmax strongly encourages you to follow proper ESD procedure, which can include wrist straps and smocks, when servicing equipment. -
Page 9: Instructions For Lithium Battery
Do not dispose of lithium batteries in domestic waste. Dispose of the battery according to the local regulations dealing with the disposal of these special materials (e.g. to the collecting points for disposal of batteries) QBOX-2060 User’s Manual... -
Page 10: Preface
Remove all items from the box. If any items listed on the purchase order are missing, notify Quanmax customer service immediately. Inspect the product for damage. If there is damage, notify Quanmax customer service immediately. Refer to “Warranty Policy” for the return procedure. -
Page 11: Warranty Policy
Quanmax or its authorized agent; or if the failure is caused by accident, acts of God, or other causes beyond the control of Quanmax or the manufacturer. Neglect, misuse, and abuse shall include any installation, operation, or maintenance of the product other than in accordance with the user’s guide. -
Page 12: Maintaining Your Computer
Quanmax. Limitation of Liability In no event shall Quanmax be liable for any defect in hardware, software, loss, or inadequacy of data of any kind, or for any direct, indirect, incidental, or consequential damages in connection with or arising out of the performance or use of any product furnished hereunder. - Page 13 Line conditioners keep a system’s AC power source voltage at a fairly constant level and, therefore, can handle brownouts. Because of this added protection, line conditioners cost more than surge protectors. However, line conditioners cannot protect against a complete loss of power. QBOX-2060 User’s Manual...
- Page 14 Surge protectors should be used with all UPS systems, and the UPS system should be Underwriters Laboratories (UL) safety approved. QBOX-2060 User’s Manual...
-
Page 15: Chapter 1 Introduction
Chapter 1 Chapter 1 Introduction Overview The QBOX-2060 is a fanless BOX PC is ideal for space critical applications. This ® embedded hardware platform is designed with Intel Atom™ D2550 Processor which ® provides with excellent performance. The system is supported with Intel NM10 Express chipset, and DDR3 SO-DIMM up to 4GB. -
Page 16: Product Specifications
1-255 step, can be set with software on Super I/O Timer Power DC 12V Input OS Support Windows 7 Dimensions 210x35x135mm(WxHxD) Environment Operation Temp: 0ºC - 50ºC Storage Temp.: -20ºC - 60ºC Humidity: 0% - 95% Certification CE, FCC Class A Table 1 QBOX-2060 Specification QBOX-2060 User’s Manual... -
Page 17: System Tour
The microphone jack is designed to connect the microphone used for video conferencing, voice narrations, or simple audio recordings. Line-IN The Line-in jack is designed to take input from a higher-powered sound source. COM 1~4 D-Sub 9 pin connector QBOX-2060 User’s Manual... -
Page 18: Figure 2 Rear Panel
HDMI HDMI connector for display output Digital I/O This interface used to connect digital signals for input and output purposes. Wireless LAN Antenna (Optional) The reserved holes for wireless antenna connections. QBOX-2060 User’s Manual... -
Page 19: Mechanical Dimensions
Chapter 1 Mechanical Dimensions 210 x 35 x135 mm (W x H x D) Figure 3 Mechanical Dimensions QBOX-2060 User’s Manual... -
Page 20: Chapter 2 Getting Started
Figure 4 DVI-I / HDMI NOTE When the system reboots without connecting the DVI-I /HDMI, there might be no image on screen when you insert the DVI-I /HDMI cable. Please pressing <Ctrl>+<Alt>+<F4> simultaneously to show the image on screen. QBOX-2060 User’s Manual... -
Page 21: Figure 5 Connect Usb Mouse & Keyboard
Chapter 2 Connect USB mouse & keyboard Your QBOX-2060 does not come with a keyboard and mouse connector, but you can use any USB keyboard or mouse to connect with your computer. Figure 5 Connect USB mouse & keyboard NOTE Using a third-party USB mouse or keyboard may require software drivers. -
Page 22: Figure 7 Com Ports
Com ports with the pin definitions. COM 1 COM 2 COM 3 COM 4 COM1 RS-232/422/485 Port 1 D-SUB 9P Half Duplex Full Duplex RS-232 RS-422 RS-485 RS-485 DATA- DATA+ COM2,3,4 RS-232 Port 2,3,4 D-SUB 9P RS-232 Figure 7 Com ports QBOX-2060 User’s Manual... -
Page 23: Figure 8 Dio Port
Chapter 2 Digital Input / Output DIO port with the pin definition. Digital Input / Output D-SUB 9P Signal Name DIO_0 DIO_1 DIO_2 DIO_3 DIO_4 DIO_5 DIO_6 DIO_7 Figure 8 DIO port QBOX-2060 User’s Manual... -
Page 24: Figure 9 Turning On The System
Connect the power cable to the power adapter Connect the power cable to a power outlet Press the power switch on the front panel to turn on the system DC Jack Power switch Figure 9 Turning on the system QBOX-2060 User’s Manual... -
Page 25: Chapter 3 Ami Bios Setup
This chapter provides a description of the AMI BIOS. The BIOS setup menus and available selections may vary from those of your product. For specific information on the BIOS for your product, please contact Quanmax. NOTE: The BIOS menus and selections for your product may vary from those in this chapter. -
Page 26: Main Menu
F1: General Help F2: Previous Values Total Size 1024 MB F3: Optimized Defaults Frequency 1067 MHz (DDR3) F4 Save & Exit System date [Thu 12/08/2011] ESC Exit System time [22:44:19] Version 2.14.1219. Copyright (C) 2011, American Megatrends, Inc. QBOX-2060 User’s Manual... -
Page 27: Advanced Menu
Version 2.14.1219. Copyright (C) 2011, American Megatrends, Inc. Onboard LAN 1 Controller Options: Disabled, Enabled Onboard LAN 1 Boot Options: Disabled, Enabled Onboard LAN 2 Controller Options: Disabled, Enabled Onboard LAN 2 Boot Options: Disabled, Enabled Audio Controller Options: Disabled, Enabled QBOX-2060 User’s Manual... -
Page 28: Table 4 Advanced Menu - Display Configuration
F2: Previous Values F3: Optimized Defaults F4 Save & Exit ESC Exit Version 2.14.1219. Copyright (C) 2011, American Megatrends, Inc. Fixed Graphics Memory Size Options: 128MB, 256MB IGFX – Boot Type Options: VBIOS Default, CRT, DVI, HDMI QBOX-2060 User’s Manual... -
Page 29: Table 5 Advanced Menu -Power Management Configuration
Options: Suspend Disabled, S1 (CPU Stop Clock), S3 (Suspend to RAM) Restore AC Power Loss Options: Power Off, Power On, Last State Resume By PCIE Device Options: Disabled, Enabled Resume By RTC Alarm Options: Disabled, Enabled Watchdog Timer Configuration WDT Function ■ Options: Disabled, Enabled QBOX-2060 User’s Manual... -
Page 30: Table 6 Advanced Menu -Cpu Advanced Configuration
F3: Optimized Defaults F4 Save & Exit ESC Exit Version 2.14.1219. Copyright (C) 2011, American Megatrends, Inc. Hyper-Treading Options: Disabled, Enabled Execute Disable Bit Options: Disabled, Enabled Limit CPUID Maximum Options: Disabled, Enabled EIST Options: Disabled, Enabled QBOX-2060 User’s Manual... -
Page 31: Table 7 Advanced Menu -Sata Configuration
F4 Save & Exit [Auto] ESC Exit Version 2.14.1219. Copyright (C) 2011, American Megatrends, Inc. Legacy USB Support Options: Disabled, Enabled, Auto EHCI hand-off Options: Disabled, Enabled San Disk Options: Auto, Floppy, Forced FDD, Hard Disk, CD-ROM QBOX-2060 User’s Manual... -
Page 32: Table 9 Advanced Menu -Dio Configuration
Options: Output Low, Output High, Input DIO-3 Options: Output Low, Output High, Input DIO-4 Options: Output Low, Output High, Input DIO-5 Options: Output Low, Output High, Input DIO-6 Options: Output Low, Output High, Input DIO-7 Options: Output Low, Output High, Input QBOX-2060 User’s Manual... -
Page 33: Table 10 Advanced Menu - Super Io Configuration
IO=3F8h; IRQ=3, 4, 5, 6, 7, 10, 11, 12; IO=2F8h; IRQ=3, 4, 5, 6, 7, 10, 11, 12; IO=3E8h; IRQ=3, 4, 5, 6, 7, 10, 11, 12; IO=2E8h; IRQ=3, 4, 5, 6, 7, 10, 11, 12; Serial Port Type Options: RS232, RS422, RS485 QBOX-2060 User’s Manual... -
Page 34: Table 12 Advanced Menu - Super Io Configuration - Serial Port
IO=2F8h; IRQ=3; IO=3F8h; IRQ=3, 4, 5, 6, 7, 10, 11, 12; IO=2F8h; IRQ=3, 4, 5, 6, 7, 10, 11, 12; IO=3E8h; IRQ=3, 4, 5, 6, 7, 10, 11, 12; IO=2E8h; IRQ=3, 4, 5, 6, 7, 10, 11, 12 QBOX-2060 User’s Manual... -
Page 35: Table 13 Advanced Menu - Super Io Configuration - Serial Port
IO=2F8h; IRQ=3, 4, 5, 6, 7, 10, 11, 12; IO=3E8h; IRQ=3, 4, 5, 6, 7, 10, 11, 12; IO=2E8h; IRQ=3, 4, 5, 6, 7, 10, 11, 12 IO=2F0h; IRQ=3, 4, 5, 6, 7, 10, 11, 12 IO=2E0h; IRQ=3, 4, 5, 6, 7, 10, 11, 12 QBOX-2060 User’s Manual... -
Page 36: Table 14 Advanced Menu - Super Io Configuration - Serial Port
IO=2F8h; IRQ=3, 4, 5, 6, 7, 10, 11, 12; IO=3E8h; IRQ=3, 4, 5, 6, 7, 10, 11, 12; IO=2E8h; IRQ=3, 4, 5, 6, 7, 10, 11, 12 IO=2F0h; IRQ=3, 4, 5, 6, 7, 10, 11, 12 IO=2E0h; IRQ=3, 4, 5, 6, 7, 10, 11, 12 QBOX-2060 User’s Manual... -
Page 37: Table 15 Advanced Menu -H/W Monitor
F3: Optimized Defaults +1.5V : +1.508 V F4 Save & Exit +VSBVCC : +4.963 V ESC Exit Version 2.14.1219. Copyright (C) 2011, American Megatrends, Inc. CPU Warning Temperature Options: Disabled, 80 ºC , 85 ºC, 90 ºC QBOX-2060 User’s Manual... -
Page 38: Boot Menu
Boot Option #1 Options: UEFI, SATA PM: Disabled Boot Option #2 Options: UEFI, SATA PM: Disabled Hard Drive BBS Priorities ■ Boot Option #1 Options: UEFI, SATA PM: Disabled ■ Boot Option #2 Options: UEFI, SATA PM: Disabled QBOX-2060 User’s Manual... -
Page 39: Security Menu
↑↓ Select Item Enter: Select Save Options +- Change Opt. Save Changes F1: General Help Discard Changes F2: Previous Values F3: Optimized Defaults Restore Defaults F4 Save & Exit ESC Exit Version 2.14.1219. Copyright (C) 2011, American Megatrends, Inc. QBOX-2060 User’s Manual... - Page 40 Load Optimal Default values for all the setup values. This option allows you to load failsafe default values for each of the parameters on the Setup menus, which will provide the most stable performance settings. The F8 key can be used for this operation. QBOX-2060 User’s Manual...
-
Page 41: Chapter 4 D River Installation
Chapter 4 Driver Installation If your QBOX-2060 does not come with an operating system pre-installed, you will need to install an operating system and the necessary drivers to operate it. After you have finished assembling your system and connected the appropriate power source, power it up using the power supply and install the desired operating system.
