- Page 1 8-port 10/100Base-TX +2-port 100Base-FX Switch (INS-802 / INS-802W) User’s Guide...
- Page 2 COPYRIGHT All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, whether electronic, mechanical, photo copying, recording or otherwise, without the prior written permission of the publisher. FCC WARNING This equipment has been tested and found to comply with the limits for class A device, pursuant to part 15 of FCC rules.
-
Page 3: Table Of Contents
INTRODUCTION ..............5 ........5 NDUSTRIAL THERNET ECHNOLOGY ............. 5 WITCHING ECHNOLOGY ................6 EATURES INS-802 INDUSTRIAL SWITCH UNPACKING AND SETUP ..................8 ................8 NPACKING INS-802............9 AYOUT OF THE DIN R INS-802........ 11 OUNTING OF THE ..........12... -
Page 4: About This Guide
Ethernet environment. With its dry contact smart alarm, the INS-802/INS802W issues an alarm function on the factory floor in the event of any malfunction. The INS-802 has a wide operating temperature range, from 0°C to 70°C, and is... -
Page 5: Introduction
802 is engineered and designed especially for the harsh, industrial type environments commonly encountered in heavy industry. With its redundant DC power inputs, fiber optic uplinks, and high performance components, the INS-802 is perfectly suited for an industrial Ethernet deployment. Switching Technology Another approach to pushing beyond the limits of Ethernet technology is the development of switching technology. -
Page 6: Features
Fast Ethernet LAN segments. Switching is a cost-effective way of increasing the total network capacity available to users on a local area network. A switch increases capacity and decreases network loading by dividing a local area network into different segments, which don’t compete with each other for network transmission capacity. - Page 7 The Switch is an unmanaged 10/100Mbps Fast Ethernet Switch that offers solutions in accelerating small Ethernet workgroup bandwidth. Other key features are: Eight (8) 10/100Base-TX and Two (2) 100Base-FX (SFP type fiber transceivers) Rugged, hardened IP30 Case Vibration/Shock operational Power terminal block Wide voltage range: 9-48V DIP Switch to enable or disable alarm functions Power input polarity protection function...
-
Page 8: Ins-802 Industrial Switch Unpacking And Setup
Switch. Unpacking Open the box of the Switch and carefully unpack it. The box should contain the following items: One INS-802 8-port 10/100M dual fiber uplink Industrial Fast Ethernet Switch One DIN rail bracket Protective caps for unused ports Quick Installation Guide This User’s Guide CD... -
Page 9: Layout Of The Ins-802
Layout of the INS-802 Front View of Switch 1. Fiber Port OFF LINE LED 2. Fiber Port LNK/ ACT LED 3. Fiber Port 100Mbps LED 4. Primary Power LED 5. Redundant Power LED 6. Alarm LED 7. 100Base-FX LC Fiber port (2) Socket 8. - Page 10 TOP View of Switch Grounding Screw Terminal block for power input (PWR/RPS), and alarm dry contact DIP Switches Back View of Switch Din Rail Bracket Screws...
-
Page 11: Din Rail Mounting Of The Ins-802
DIN Rail Mounting of the INS-802 The aluminum DIN Rail attachment plate should already be affixed to the back panel of the Switch. If you need to attach the DIN Rail plate, assure that the stiff metal spring is situated towards the top. Attaching the Switch... -
Page 12: Redundant Power Inputs
Switch. Do not place heavy objects on the Switch. Grounding INS-802 Industrial Switch will help eliminate the effects of noise due to electromagnetic interference (EMI). Always run the ground connection from the ground screw to the grounding surface prior to connecting DC power. - Page 13 DC Powered Switch: Power is supplied through an external DC power source. Check the technical specification section for information about the DC power input voltage. Since the switch does not include a power switch, plugging its power adapter into a power outlet will immediately power it on. plastic green colored...
-
Page 14: Ethernet Connections
Switch, do so now. D. Assure your DC power supply is stable and clean before applying DC power to the Switch. Ethernet Connections The INS-802 Industrial Fast Ethernet Switch has eight 10/100Base-TX Ethernet ports, and two 100 Base-FX... -
Page 15: Led Indicators
This indicator will light red and will signal an alarm (when an external alarm is connected) during a down link condition on any port and during primary power failure to the Switch. Port Status LED Fiber ports on the INS-802 are designated as ports 9 and... -
Page 16: External Alarm Contact
LED will illuminate green during link or activity. Otherwise, the LED’s will be off. External Alarm Contact The INS-802 Industrial Switch has one Alarm Contact located on the green Power Block Contact on the top panel. For detailed instructions on how to connect the... - Page 17 You can connect the Fault circuit to any warning light which the user’s factory or industry already has located in the control room or factory floor. When a fault occurs, the Switch will send a signal through the Alarm contact, to activate the external alarm or siren.
-
Page 18: Dip Switch Settings
Recommended Procedure for configuring and setting DIP switches during initial installation: 1. Turn all DIP switches OFF. 2. Install the INS-802 into your network. 3. Decide which port(s) need to be monitored or triggered alarm(s). 4. Turn the corresponding port DIP switch ON. -
Page 19: Fiber Connector
Fiber Connector The dual Fiber Ports on the INS-802 are LC type SFP modules in either Multi-mode or single mode (sold separately). The Switch’s fiber switched ports operate at a fixed 100 Mbps speed and full duplex mode to provide the best performance. -
Page 20: Switching, Filtering, And Forwarding
Switching, Filtering, and Forwarding Packets entering the INS-802 Switch with source and destination addresses belonging to the same port segment will be filtered, constraining those packets to one port, and relieving the rest of the network from the need to process them. A packet with destination address... -
Page 21: Technical Specifications
ECHNICAL PECIFICATIONS General Standards IEEE 802.3 IEEE 802.3u & IEEE 802.3x Connectors 8 (eight) 10/100BaseTX RJ45 2 (two) SFP (LC) Fiber Connectors Wavelength 1310nm (multi-mode) 1310/1550nm (single mode) Max Distances RJ-45 – 100 meters Fiber Optic – Up to 120,000 meters Ports 8x 10/100Mbps auto-negotiation, auto MDI-X ports 2x 100Mbps Full duplex (Fiber port) - Page 22 Performance Transmission Store and forward, with IEEE802.3x full duplex, Method: non-blocking flow control. Fiber ports did not support flow control Packet 10Mbps Ethernet: 14,880/pps Filtering/Forwar 100Mbps Fast Ethernet: 148,800/pps ding Rate: MAC Address Automatically update Learning:...
-
