Analog Metric 2A3 User Manual page 12

Analog Metric
Analog Metric
Analog Analog Metric Metric
2A3 2A3 Push Push Push- - - - Pull Pull Pull
2A3 2A3 Push Pull Amplifier
Components Components
Components Components
C1A, C1B
C2A, C2B
C3A, C3B
C4A, C4B, C5A, C5B
C6A, C6B, C12
C7A, C7B
C11
C31, C32
D11, D21
R1A, R1B
R2A, R2B
R3A, R3B
R4A, R4B
R5A, R5B
R6A, R6B
R7A, R7B
R8A, R8B
R9A, R9B
R10A, R10B, R11A, R11B, R11,
R12, R31, R32
R12A, R12B
R13A, R13B
R16A, R16B
R17
L11, L12
VR1, VR2
T1
T1A, T1B
T2A, T2B
T3A, T3B, T4A, T4B
4-Pin Plate PCB Mount Tube Socket
8-Pin PCB Mount Tube Socket
2-Pin Blue Connector
3-Pin Blue Connector
PCB
Amplifier Amplifier
Amplifier
Value Value
Value Value
0.47uF/200V
100uF/35V
22uF/250V
0.22uF/400V
47uF/450V
100uF/100V
100uF/450V
220uF/450V
6A10
100K 1W
100R 1W
27K 1W
82K 1W
1M 1W
22K 1W
30K 1W
1K 1W
20K 3W
200K 1W
100R 5W
6.8K 1W
750R 10W
10R 1W
10H 250mA
100R
5Z3P/5U4G
6SN7
6J8P/6SJ7
2A3
Quantity Quantity
Quantity Quantity
2 Electrolytic Capacitor
2 Electrolytic Capacitor
2 Electrolytic Capacitor
2 MKP Film Capacitor
3 Electrolytic Capacitor
2 Electrolytic Capacitor
1 Electrolytic Capacitor
2 Electrolytic Capacitor
2
2
2
2
2
2
2
2
2
2
8
2
2
2
1
2 Optional, short without inductors
2 1W
1
2
2
4
4
5
9
5
1
Remark Remark
Remark Remark
