IDEAL SK618 Owner's Manual

Wireless alarm system with auto dialer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SK618
WIRELESS ALARM SYSTEM WITH AUTO DIALER
OWNER'S MANUAL
Thank you for choosing Ideal Security's Home Security System with Telephone Dialer.
If at any time during your installation you have any questions or comments, please do not
hesitate to contact our customer service department through our web site at
www.idealinc.com, via email at info@idealinc.com, or by calling our toll free number at
800-361-2236 x 230. Normal business hours are 7:30am to 3:30pm Eastern time. Monday
to Friday.
You can add up to 23 wireless Ideal Security sensors to this unit, i.e. motion detector,
water detector, door and window contacts, temperature sensor as well as 7 additional
remote controls (for a total of 8 remotes)
Up to date instructions & installation tips can be found at www.idealalert.com
INTRODUCTION
Our unique Auto dialer is designed to allow you to create your own security system. It
will alert you of any intrusion, temperature changes or water leakage (depending on what
sensors you have installed). Choose a desired location for the auto-dialer, set the auto-
dialer to ARM mode. Once a sensor sends signal, the auto-dialer will turn on the built-in
siren (if activated) and dial out (if activated) the pre-programmed telephone numbers one
by one, for the pre-programmed cycles. You can set the auto-dialer to chime mode, you
will hear one chime only when a sensor is activated.
THE TELEPHONE DIALER REQUIRES A LAND TELEPHONE LINE TO MAKE
OUTGOING CALLS AND ELECTRICITY.
Important note regarding:
REGARDING AUTO DIALER, ANSWERING MACHINES &
"REMOTE ACTIVATION" allows user to call into the telephone dialer to perform he
following functions: Activate the system
ANSWERING MACHINE SETTING AND REMOTE ACTIVATION
If the "REMOTE ACTIVATION" feature is required, the response setting must be
changed to allow for the auto dialer to respond before the answering machine
REMOTE COMMUNICATION.
De-Activate the system
Listen in to the room containing the auto dialer.
Rev. 10/05/2012

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SK618 and is the answer not in the manual?

Questions and answers

Related Manuals for IDEAL SK618

Summary of Contents for IDEAL SK618

  • Page 1 800-361-2236 x 230. Normal business hours are 7:30am to 3:30pm Eastern time. Monday to Friday. You can add up to 23 wireless Ideal Security sensors to this unit, i.e. motion detector, water detector, door and window contacts, temperature sensor as well as 7 additional remote controls (for a total of 8 remotes) Up to date instructions &...

  • Page 2: Important Safety Tips

    Rev. 10/05/2012 Depending on your specific needs, priority must be given to either the answering machine or “REMOTE ACTIVATION” If you intend to use the “REMOTE ACTIVATION” features (controlling the alarm unit remotely), you cannot use an answering machine in the usual way. To use the remote activation feature: Set the auto dialer to respond (pick up) before your answering machine responds.

  • Page 3: Installation

    Rev. 10/05/2012 FEATURES • Received signal from wireless sensor activates auto-dialer and alarm • 16 Digit large number display with date/time and function icon • 9 zone icon for easy differentiating sensor location - From Zone 1 to Zone 7, you can learn one wireless sensor for each zone to trigger the system (Works in ARM mode only) - Zone 8S you can learn up to 8 wireless sensors to trigger the system (Works in ARM mode only)
  • Page 4 Rev. 10/05/2012 2. Raise the antenna on the side of the unit so it points up (Fig.3). The antenna should be vertically straight up for better reception. 3. The supplied telephone line splitter can be installed into your telephone wall socket.
  • Page 5 Rev. 10/05/2012 1. TO SET PASSWORD a. Enter factory pre-set password 0-0-0. Press PROG button once (1), PASSWORD will flash on the auto-dialer screen. (Fig.5) b. Press the ARM/DISARM button to confirm that you want to enter the PASSWORD. c. Enter your new password then press the ARM/DISARM button to confirm (you can choose from 3 to 6 digits for your password).
  • Page 6 Rev. 10/05/2012 e. Enter correct year by pressing */UP or #/DOWN button, then press the ARM/DISARM button. The next set of numbers will start flashing, enter the month by pressing */UP or #/DOWN button, then press the button ARM/DISARM , and so on until all numbers have been entered. You will now have the correct date and time.

  • Page 7: Pause Function

    Rev. 10/05/2012 5. PAUSE FUNCTION The "PAUSE" function can be stored as one digit in the telephone number memory for some dialing operations. Every one PAUSE in the memory dialing sequence will pause for 3.6 seconds. For example, if you want to store telephone number 514-363-1030 EXTENSION 230 to a memory location, the operation will be as follows: a.
  • Page 8 Rev. 10/05/2012 b. The " " icon will flash on the auto-dialer screen. (Fig.8) c. Press ARM/DISARM button to confirm. d. Using */UP or #/DOWN buttons to select call OFF followed by the ARM/DISARM button to confirm. e. Press PROG button five (5) times to exit the set-up mode.
  • Page 9 Rev. 10/05/2012 c. Press the ARM/DISARM button to confirm. d. Using the */UP and #/DOWN buttons select the seconds 0,5,10,15 or 20. Press ARM/DISARM to confirm the number of seconds you require for the entry delay time. e. Press the PROG button twice (2) to exit set-up mode.

  • Page 10: To Disarm The System

    Rev. 10/05/2012 automatically dial all the numbers stored, one by one, for the CYCLE (amount of times the numbers are dialed) you have chosen. The receiver of the phone call will hear one beep cycle for zones 1-7 and 8S, two beep cycles for 24hr zone and four beep cycles for PANIC.
  • Page 11 Rev. 10/05/2012 Enabling and Disabling sensors when in HOME mode. When in HOME mode all sensors will send signal to auto dialer and you will hear a chime when a sensor is triggered. If you have one or more sensors that you do not wish to have them send a signal to the auto dialer, example a contact on a patio door that is in HOME zone 3, then you would disable zone 3.

  • Page 12: View Function

    Rev. 10/05/2012 7. REMOTE CONTROL BY TELEPHONE TO CONTROL ALARM (To control your auto dialer via telephone) (see ANSWERING MACHINES and REMOTE COMMUNICATION) a. Dial your home number (from anoher line). The auto-dialer will answer after the designated amount of rings that you have programmed. b.
  • Page 13 Zone REMOTE (LCD icon REMOTE) is the remote control zone and you can learn up to 8 remote controls. (Ideal Security part # SK629 ONLY) You can learn a total of 23 sensors and 8 remote controls to this unit.
  • Page 14 Rev. 10/05/2012 e. Press ARM/DISARM to confirm that this is the zone you want the sensor to be. f. Trigger the sensor or remote control that you are trying to learn as follows: 1. Wireless motion detector SK615, by moving hand in front of sensor to send signal.* please see NOTE below 2.

  • Page 15: Troubleshooting Guide

    Rev. 10/05/2012 Once learn code was successful you must turn ON the AC Outlet Control in order to receive the signal from the auto-dialer. NOTE: You will hear a long beep to confirm that the learn code was successful. When learn code is not successful you will hear 4 short beeps.
  • Page 16 Rev. 10/05/2012 All batteries including the back up battery in the telephone dialer should be changed once per year. Should a power failure occur and the back up battery is weak, or batteries in all your sensors are weak, false alarms may occur. If the telephone dialer or any other detector is not being used for an extended period, remove the batteries to avoid any damage due to battery leakage.
