Ildvr Digital Technology USA INC-MP1300 User Manual

Socket 478 miniatx sbc w/ inc-mp series megapixel
Hide thumbs
Table of Contents

Advertisement

Quick Links

M0320
Edition 10.1
Issued on December 2011
IP Camera User Manual
For
INC-MP Series
INS-MP1300
Megapixel IP Camera

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the INC-MP1300 and is the answer not in the manual?

Questions and answers

Related Manuals for Ildvr Digital Technology USA INC-MP1300

Summary of Contents for Ildvr Digital Technology USA INC-MP1300

  • Page 1 M0320 Edition 10.1 Issued on December 2011 IP Camera User Manual INC-MP Series INS-MP1300 Megapixel IP Camera...
  • Page 2 ILDVR Digital Technology USA Inc. (“ILDVR”) Product warranty or service will not be extended if: (1) the product is repaired, modified, or altered, unless such repair, modification of alteration is authorized in writing by ILDVR;...
  • Page 3 To contact us: Headquarter: www.ildvr.com Branches Europe: www.ildvr.eu Russia: www.ildvrcom.ru, China: www.ildvr.net ILDVR Global Distribution & Service Danmark: www.ildvr.dk Germany: www.ildvr.de Hungary www.ildvr.hu Italy: www.ildvr.it Netherland: www.ildvr.nl Russia: www.il-dvr.ru www.ildvr-video.ru Ukraine: www.ildvr.com.ua USA: www.ildvr-usa.com Tech-support: support@ildvr.com...

  • Page 4: Table Of Contents

    Directory Introduction……………………………………………………………………………………………………………………………………..………1 Physical Interface Description ……………………….……………………………….………………………………….………………………………..2 Box Camera……………………………………………………………………………….…………..………………………………………………2 1.1.1 INC-MP20A……………………………………………………………………………………………………………………………………………………2 1.1.2 INC-MP12CD………………………………………………………………………………………………………………………………………………….4 1.1.3 INC-MP20CD and INC-MP50N……………………………………………………………………………………………………………………………….5 Dome Camera……………………………………………………………….…………..………………………………………………………………6 Mini Dome Camera…………………………………………………………………….…………………………………………….….………………….7 Hardware Installation …………………….……………………………….……………………………………………………………………………….8 Prepare Audio Connector……………………………………………………………………………………………………….……………………….8 B o x C a m e r a I n s t a l l a t i o n … … … … … … … … … … … … … … … … … … … … … … … … … … … … … … … … … … . … … … … … … … … … . . . 9 Dome Camera Installation……………………………………………………………………………………….…………..………………………….10 Mini Dome Camera Installation……………………………………………………………………………………….…………..……………………….12 IP Speed Dome Installation………………………………………………………………………….…………..………………………………………….16...
  • Page 5 Search and Modify IP Address……………………………………………………………………………………………………….……………………….27 Connect to HVR Server and Live Center………………………………………………………………………………………….………………………...28 Camera System Configuration……………………………………………………………………………………….…………..………………………….29 Continuous Record Setup……………………………………………………………………………………………….…………..……………………….31 Motion Detect Alarm Record Setup………………………………………………………………………………………….……………………………….31 Sensor Trigger Alarm Record Setup…………………………………………………………………………………….……………………………….33 PTZ Operation…………………………………………………………………………………….………………………………………………………34 Display on TV-wall…………………………………………………………………………………….………………………………………………………37 Advanced Operation ……….……………………………………………………………….……………………………………….………..38 SD Card Local Record Setup……………………………………..……………………………….…………………………………………………38 Audio Chat to IP Camera………………….…………………………………………………..……………………………………….…………………….38 Manually Trigger Alarm Out………….……………………………………………………………………………….…………………………………….38 Mobile Phone Access Viewing………………………………………………………………………….……………………………………………………..39...

  • Page 6: Introduction

    Introduction ILDVR INC-MP series megapixel P camera integrates the traditional camera and network video technology. It adopts video and audio data collection, compression, transmission and storage together. It can be used alone with SD card record or used in a network environment. It can connect to network directly without any auxiliary device.

  • Page 7: Physical Interface Description

    Physical Interface Description Box Camera 1.1.1 INC-MP20A ______________________________________________________________________________________________________________________________________________________________ INC-MP Series & INS-MP1300 Megapixel IP Camera User Manual...
  • Page 8 Camera description: Item Description Item Description Lens mount Power supply Back Focus Ring MIC IN: Audio input interface SD: SD card slot D+, D-: RS-485 interface Auto iris interface IN, G: Alarm input interface 10M/100M self-adaptive Ethernet interface 1A, 1B: Alarm output interface VIDEO OUT: Video output interface Ground AUDIO OUT: Audio output interface...

  • Page 9: Inc-Mp12Cd

    1.1.2 INC-MP13CD Camera description: Item Description Item Description CS Lens mount Power supply Back Focus Ring PWR: Power LED indicator Auto iris interface D+, D-: RS-485 interface 10M/100M self-adaptive Ethernet interface Ground AUDIO IN: Audio input interface 1A, 1B: Alarm output interface AUDIO OUT: Audio output interface SD: SD card slot IN, G: Alarm input interface...

  • Page 10: Inc-Mp20Cd And Inc-Mp50N

    1.1.3 INC-MP20CD and INC-MP50N Camera description: Item Description Item Description CS Lens mount RESET: Reset the camera Auto iris interface TXD, RXD, GND: RS-232 interface Bracket mounting holes Power supply F1+ F1-, F2+ F2- ,F3+ F3- (ALARM OUT): Alarm output interface PWR: Power LED indicator T1,T2,T3, T4,GND (ALARM IN): Alarm input interface SD: SD card slot...

  • Page 11: Dome Camera

    Dome Camera INC-MP20V and INC-MP50V Item Description Item Description 10M/100M self-adaptive Ethernet interface D+, D-: RS-485 interface AUDIO IN: Audio input interface ALARM IN, G: Alarm input interface 1A, 1B: Alarm output interface AUDIO OUT: Audio output interface Power supply ______________________________________________________________________________________________________________________________________________________________ INC-MP Series &...

  • Page 12: Mini Dome Camera

    Mini dome camera INC-MP20VM Item Description Back box Lens P: Power LED indicator, It turns solid red when power is applied to the unit. Bottom board Bottom board set screw hole Lens set screw S & L: Network status LED indicator. When the network is connected, the “S”...

  • Page 13: Hardware Installation

    Hardware Installation Prepare Audio Connector The IP cameras use standard 3.5mm Stereo Jack connector but the audio type is mono audio, please refer to following picture to make your audio connector. Figure 2.1.1 ______________________________________________________________________________________________________________________________________________________________ INC-MP Series & INS-MP1300 Megapixel IP Camera User Manual...

  • Page 14: Box Camera Installation

    Box Camera Installation Box camera can be fixed in both wall and ceiling, customers can choose different ways to install the camera according to their specific needs. The following section introduces the ceiling mounting, and the wall mounting follows the same way: Step 1: Fix the mounting bracket to the ceiling.

  • Page 15: Dome Camera Installation

    Figure 2.2.2 Fix the Camera Figure 2.2.3 Mount and adjust Lens Step 3: Mount the camera lens: connect the VIDEO OUT interface of the camera to the debugging monitor, and adjust lens focus until you have obtained the clearest video images on the monitor, and then lock the lens. If required, loosen the knob on the mounting bracket and adjust the camera lens to the desired monitoring scene, and finally tighten the knob on bracket.
  • Page 16 Figure 2.3.1 Unload the Cover Figure 2.3.2 Install the Camera Figure 2.3.3 Adjust the lens ______________________________________________________________________________________________________________________________________________________________ INC-MP Series & INS-MP1300 Megapixel IP Camera User Manual [11]...

  • Page 17: Mini Dome Camera Installation

    Step 4: Tighten the screw after adjusting camera’s view angle, and cover the transparent casing. Figure 2.3.4 Figure 2.3.4 Install the Cover Mini Dome Installation The ceiling mount is a suitable installation method for this camera. Please stick to the following steps: Note: If required, user can apply the pliers to remove the clip (refer to the part marked...
  • Page 18 Figure 2.4.2 Remove the back box Step 2: Use the screws to fix the bottom board on the ceiling. Figure 2.4.3 Fix the bottom board Step 3: While viewing the video on the computer, adjust the camera’s view angle for your need. ______________________________________________________________________________________________________________________________________________________________ INC-MP Series &...
  • Page 19 Loosen the lens set screws. Figure 2.4.4 Insert the hexagonal screw driver into the hole marked in the picture , and then adjust horizontally and vertically the camera’s pan and tilt by turning the hexagonal screw driver. Figure 2.4.5 ______________________________________________________________________________________________________________________________________________________________ INC-MP Series &...
  • Page 20 Note: 1. As the lens of camera has already been factory adjusted to the best imaging effect, thus it only needs to adjust the Tighten the lens set screws. pan and tilt view angle. 2. If the image is not clear without the back box, please don’t worry, the back box will affect the imaging effect, so when you test the imaging effect of lens, the back box must be installed to the camera...

  • Page 21: Ip Speed Dome Installation

    Step 2: Configure the dome address, baud rate and other settings through DIP switch SW1 and SW2 located on the bottom board of the dome, as shown in Figure 1.4.2. Usually you don’t need do this step because the dome address, baud rate and other settings of INC-MP1300 can be configured through ______________________________________________________________________________________________________________________________________________________________ INC-MP Series &...
  • Page 22 software interface. It is self-adaptive design. Figure 1.4.2 Medium Speed Dome DIP Switch Step 3: Push the tab locks on the back box interconnect board and lift the hinged door to the circuit board, as shown in Figure 1.4.3. Unplug the video cable, power cord and other cable terminals to avoid cables twisting during the back box installation.
  • Page 23 Tab Lock 2. Wiring Connector 3. Lock Clips 4. Power LED Indicator Figure 1.4.3 Back Box Interconnect Board 1.Alarm In/Out Terminals (1 inputs/1 outputs) 2. Audio In/Out, Video Out and RS-485 COM Terminals 3. 24VAC Voltage Input and GND Figure 1.4.4 Back Box Circuit Board ______________________________________________________________________________________________________________________________________________________________ INC-MP Series &...
  • Page 24 Step 4: Attach the back box of dome to the mount. For your attention: For outdoor installation, please apply the thread compound and the damp-proof stopper to threads of the back box and the mount. After having made connections of the power cord, video cable, RS-485 control line and alarm input/output lines (if required), close the hinged door and tighten the set screws, as shown in Figure 1.4.5.

  • Page 25: Wall Mount

    Step 5: Install the dome drive as shown in Figure 1.4.6, align the tabs on both sides of the dome drive with the corresponding arrow labels on the back box to snap the drive into the back box firmly. Step 6: Install the bubble and fasten the two set screws on both sides, as shown in Figure 1.4.7 Figure 1.4.6 Install Dome Drive Figure 1.4.7 Install Bubble 2.5.2...
  • Page 26 Nuts and Flat Washers ______________________________________________________________________________________________________________________________________________________________ INC-MP Series & INS-MP1300 Megapixel IP Camera User Manual [21]...

  • Page 27: Corner Mount

    2.5.3 Corner Mount Corner Adapter Hex Screws (M8×30), Nuts, Spring Washers and Flat Washers ______________________________________________________________________________________________________________________________________________________________ INC-MP Series & INS-MP1300 Megapixel IP Camera User Manual [22]...

  • Page 28: Pole Mount

    2.5.4 Pole Mount Pole Adapter Hex Screws (M8×30) and Spring Washers 2.5.5 Pendant Mount ______________________________________________________________________________________________________________________________________________________________ INC-MP Series & INS-MP1300 Megapixel IP Camera User Manual [23]...

  • Page 29: Surface Ceiling Mount

    2.5.6 Surface ceiling mount Surface mount ______________________________________________________________________________________________________________________________________________________________ INC-MP Series & INS-MP1300 Megapixel IP Camera User Manual [24]...
  • Page 30 Push forwards Line up Push upwards Lock clip ______________________________________________________________________________________________________________________________________________________________ INC-MP Series & INS-MP1300 Megapixel IP Camera User Manual [25]...

  • Page 31: Recess Ceiling Mount

    2.5.7 Recess ceiling mount Bracket Drill Drawing ______________________________________________________________________________________________________________________________________________________________ INC-MP Series & INS-MP1300 Megapixel IP Camera User Manual [26]...

  • Page 32: Software Installation

    Software Installation Search and Modify IP Address Before using IP camera, please make sure whether the default IP address of the camera fit your local network environment. If not, please install IPCapture software to search and modify the IP address of INC-MP series Camera. IPCapture is an independent utility program. You can find it in the software CD or download it from ILDVR web site.

  • Page 33: Connect To Hvr Server And Live Center

    Connect to HVR Server and Live Center In the main interface of HVR Server, click Tools icon to expand the Tool Panel, click Add/del IP camera button to bring up “IP Camera Device List” interface. In Live Center the operation is similar but the first step is to enter Local Setup interface. For your attention: All IP cameras must be registered in the software then it could be recorded.

  • Page 34: Camera System Configuration

    Camera System Configuration The following operations need admin user rights to login IP camera. Please refer to above step. Right click IP Camera window to pop up right-click menu. Choose “IPcam_NetDVR_Setup” to bring up “IP Camera Setup” interface. In Live Center, entrance is “Remote Setup” then choose Server alias In “Server”...
  • Page 35 In “Channel” page you can modify video parameters and OSD information. If you need mask privacy area, please check-on the Privacy then draw a rectangle area on the image. That is the mask area. If you have SD card to record, please check-on “Enable Rec” then setup recording schedule. Enable audio ______________________________________________________________________________________________________________________________________________________________ INC-MP Series &...

  • Page 36: Continuous Record Setup

    Continuous Record Setup Continuous Record means always record the video, the operation is simple. You get video connection, get video record. You just enter Camera Setup page Group Setup, choose camera group and cameras, click the icon “Continuous Record” then slide the mouse to set time table. The operation in Live Center is similar. Motion Detect Alarm Record Setup Motion Detect Record is a little bit complicated than Continuous Record because HVR system need additional signal to analyze the video stream type.
  • Page 37 Important: Upload alarm signal to network ______________________________________________________________________________________________________________________________________________________________ INC-MP Series & INS-MP1300 Megapixel IP Camera User Manual [32]...

  • Page 38: Sensor Trigger Alarm Record Setup

    Sensor Trigger Alarm Record Setup Sensor Record is a kind of external alarm-in trigger record. It is more complicated than Motion Record because motion detect signal is embedded in video stream, but sensor alarm signal is a kind of external signal. You must configure 3 places to execute Sensor Record. The first place is Alarm in Record setup in HVR system “Camera Setup”...

  • Page 39: Ptz Operation

    Here is the time table to upload alarm signal PTZ Operation ______________________________________________________________________________________________________________________________________________________________ INC-MP Series & INS-MP1300 Megapixel IP Camera User Manual [34]...
  • Page 40 If you have INS series IP Speed Dome or connect analog speed dome to IP Video Server, please setup preset position, auto-spot plan and preset tour in this page. No like analog PTZ which saves preset in camera system, the IP PTZ saves preset in local computer, so if you use another PC to control same IP PTZ, you should do same setting again in that PC.
  • Page 41 Auto Plan: Auto Plan means HVR software automatically call the preset position by a scheduled time table. When the system time reach, the IP speed dome will auto move to preset position. You can save up to 64 moments and one preset could be used multiple times. Tour Group: Tour Group means you can put different preset position in a sequential group, each preset position could be defined a staying time (stay there without moving).

  • Page 42: Display On Tv-Wall

    Display on TV-wall For large surveillance system the TV-wall is important and necessary. IP camera cannot be integrated into traditional matrix system. ILDVR free software IP Matrix offers innovative TV-wall solution. All ILDVR software support IP matrix operation, one computer running HVR Server / Live Center / CMS supports up to 6 IP Matrix TV-client.

  • Page 43: Advanced Operation

    4. Advanced Operations SD Card Local Record Setup If you install SD card into IP camera to record video locally, please follow these operation steps a. Format SD card in “Server” page. If there is no SD card, the Format button won’t be available. Refer to section 3.3 b.

  • Page 44: Mobile Phone Access Viewing

    Manual trigger alarm out (relay out) can be widely used to integrate other electrical device such as open a door, turn of light, etc. Open alarm panel Sensor record status Click alarm number key Mobile Phone Access Viewing After you connect IP Camera to HVR Server, you can use your mobile phone to login HVR Server to view the real time image. HVR Server support most mainstream mobile phone in the market.

  • Page 45: Ie Web Client Operation

    IE Web Client Operation All IP cameras have built in web server. You can use Internet Explorer directly login to IP camera by input camera’s IP address or domain name. At first time connecting to IP camera, you will be prompted to install ActiveX Control (Add-on). Refer to following illustration ______________________________________________________________________________________________________________________________________________________________ INC-MP Series &...
  • Page 46 Most of the configuration jobs could be done in ILDVR software interface, but some advanced operation must be finished through IE interface. Such as User Management and Restore system to factory default settings. The following illustration show you how to bring up camera advanced system menu to turn ON/OFF ePTZ function.
  • Page 47 For CMOS image sensor camera, please set the video standard in accordance with local city electrical power frequncy. You can also do it in the step of previous page, the item name is FLICKER CONTROL. Change video standard PAL=50Hz NTSC=60Hz ______________________________________________________________________________________________________________________________________________________________ INC-MP Series &...

  • Page 48: Eptz Operaion

    ePTZ Operation ePTZ function is similar to physical PTZ operation but there is no physical PTZ installation. This innovative feature works perfectly with INC-MP13CD and INC-MP20CD, especially the Zoom in / Zoom out. The other models of INC-MP series with CMOS image sensor don’t support zoom in / zoom out of ePTZ but support ePTZ pan/tilt after you setup the resolution less than maximum resolution.
  • Page 49 ______________________________________________________________________________________________________________________________________________________________ INC-MP Series & INS-MP1300 Megapixel IP Camera User Manual [44]...
  • Page 50 Technical Support Information Please fill in this form in order to get prompt technical service in case of emergency! Item Description IP Device Model Name IP Device serial number Firmware Version Purchasing date Company name: Technical Engineer: Dealer’s Contact info Tel: Fax: Email:...
