American Power Systems APS-500-DCH-28 Operation Manual

On board 28v dc generator system
Hide thumbs
1
2
3
4
5
6

Advertisement

Quick Links

Download this manual
DC Generator
APS-500-DCH-28
DCGS Operation Guide

Advertisement

loading
Need help?

Need help?

Do you have a question about the APS-500-DCH-28 and is the answer not in the manual?

Questions and answers

Summary of Contents for American Power Systems APS-500-DCH-28

  • Page 1 DC Generator APS-500-DCH-28 DCGS Operation Guide...
  • Page 2 DCGS Generator Operation Guide Summary The APS-500-DCH-28 is an on board 28V DC generator system (DCGS) designed to provide 14 kW of DC power in a lightweight high-power diesel engine package. The DCGS houses the engine, generator pack and radiator with remote panel interface.

  • Page 3: Generator Specifications

    Specifications: GENERATOR SPECIFICATIONS Power: 14 kW @ 28VDC Voltage: 27.6 VDC, Floating Positive, Chassis Ground Frequency: Current: 500 Amps Current Distortion: less than 1000 milli-amp ripple current typical Voltage Distortion: negligible Induction type: 3-72 pole stationary stators, redundant Load Regulation: +/- 1.0% No Load to Full Load.
  • Page 4 Operation: The unit is a self contained, self regulating system requiring no setup or adjustments. DCGS does not have an integral fuel tank so fuel must be provided from an outside source such as the vehicle fuel system with a fuel pump. When DC load is applied to the DCGS, it will self regulate and adjust current output and engine rpm automatically.
