Owner's Manual
ATTENTION! READ INSTRUCTIONS CAREFULLY BEFORE ASSEMBLY OR USE
Adjustable Wrench, Pipe Wrench, Pipe Sealing Compound and hand held lighter
Burner Systems:
SS-H-12; MATCH LIT (12" H-Burner Style)
SS-H-18; MATCH LIT (18" H-Burner Style)
SS-H-24; MATCH LIT (24" H-Burner Style)
SS-H-30; MATCH LIT (30" H-Burner Style)
SS-H-36; MATCH LIT (36" H-Burner Style)
WARNING: If the information in this manual is
not followed exactly, a fire or explosion may re-
sult causing property damage, personal injury or
loss of life.
— Do not store or use gasoline or other
flammable vapors and liquids in the vicinity of
this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.
•
Do not touch any electrical switch; do not use
•
any phone in your building.
Immediately call your gas supplier from a
•
neighbor's phone. Follow the gas supplier's
instructions.
If you cannot reach your gas supplier, call the
•
fire department.
— Installation and service must be performed by
a qualified installer, service agency or the gas
supplier.
29354 Hunco Way Suite A
Lake Elsinore, CA 92530
www.americanfireglass.com
H-BURNER
DECORATIVE VENTED GLASS BURNER
General Assembly, Installation and Operation Instructions
Tools Needed
All Burners for Natural Gas Only
SAFETY PILOT KITS:
SPK-N-M (MANUAL)
SPK-N-O (ON/OFF REMOTE)
SPK-N-V (VARIABLE REMOTE)
This is a vented gas appliance for use only
in a solid-fuel burning fireplace constructed
on non-combustible material with a fully
functional chimney flue which must vent all
products of combustion. When operating,
the chimney DAMPER MUST BE FULLY
INSTALLER: Leave this manual with the
appliance.
CONSUMER: Retain this manual for future
reference.
Improper installation, alteration, service or
maintenance can cause property damage,
personal injury or loss of life. Read these
instructions thoroughly before installation. For
assistance or additional information, consult
your gas log dealer, qualified installer, service
agency or gas supplier.
Installation must conform with local codes or, in the
absence of local codes, with the National Fuel Gas
Code, ANSI Z223. 1/ Latest Edition
1.
Form AF410
WARNING
OPEN
Advertisement
Table of Contents
Summary of Contents for American Fireglass SS-H-12
- Page 1 Tools Needed Adjustable Wrench, Pipe Wrench, Pipe Sealing Compound and hand held lighter Burner Systems: SAFETY PILOT KITS: SS-H-12; MATCH LIT (12” H-Burner Style) SPK-N-M (MANUAL) SS-H-18; MATCH LIT (18” H-Burner Style) SPK-N-O (ON/OFF REMOTE) SS-H-24; MATCH LIT (24” H-Burner Style) SPK-N-V (VARIABLE REMOTE) SS-H-30;...
- Page 2 IMPORTANT INFORMATION Due to high temperatures, the appliance should be located out of traffic and away from furniture and draperies. • Children and adults should be alerted to the hazard of high surface temperatures and should stay away to avoid •...
-
Page 3: Parts List
Important: Use with other manufacture parts, controls, remotes, parts and accessories which are not design, tested with American Fireglass products is prohibited and will void all warranties. Liability for bodily injures or property damage will not be accepted by American Fireglass if installation and / or product usage does not comply with this H -Burner. -
Page 4: General Installation Instructions
GENERAL INSTALLATION INSTRUCTIONS WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this appliance may result in property damage or personal injury.. STEP ONE PREPARATION: FIGURE 2 1. Verify that the H-Burner is correctly matched. 2. -
Page 5: Gas Supply Connection
“H” FIREBOX FIREBOX FIREBOX FIREBOX CHIMNEY BURNER FRONT REAR DEPTH HEIGHT DIAMETER PERMANENT SIZE WIDTH WIDTH CHIMNEY 6 W.C. 7 W.C. OPENING 12” 18” 12” 14” 16” 6” 29 Sq” 130,000 150,000 18” 24” 18” 14” 16” 7” 39 Sq” 135,000 155,000 24”... - Page 6 INSTALLTION INSTRUCTIONS LIGHTING AND OPERATION OF H-BURNER FILLING H-BURNER WITH GLASS Step 3 1.) Begin by completely covering BURNER TUBES (See figure 4) with glass first. 2.) Focus first on covering the entire BURNER TUBES before spreading evenly within the firebox floor. 3.) Use the entire bag of glass that is provided with the burner.
- Page 7 LIGHTING AND OPERATION OF SAFETY PILOT KITS IMPORTANT! CHIMNEY DAMPER MUST BE WIDE OPEN! THE FLUE MUST VENT ALL PRODUCTS OF COMBUSTION. DAMPER AND GLASS DOORS MUST BE FULLY OPEN BEFORE LIGHTING OR BURNING FOR PROPER VENTILATION AND TO PREVENT HEAT DAMAGE TO THE VAVLE. PILOT LIGHTING INSTRUCTIONS SAFETY MANUAL CONTROL VALVE SKP-N/P-M PILOT ADJUMENT...
- Page 8 LIGHTING AND OPERATION OF SAFETY PILOT KITS AND PILOT ASSEMBLY IMPORTANT! CHIMNEY DAMPER MUST BE WIDE OPEN! THE FLUE MUST VENT ALL PRODUCTS OF COMBUSTION. DAMPER AND GLASS DOORS MUST BE FULLY OPEN BEFORE LIGHTING OR BURNING FOR PROPER VENTILATION AND TO PREVENT HEAT DAMAGE TO THE VAVLE. BURNER OPERATION FOR VARIABLE FLAME HEIGHT SAFETY VARIABLE CONTROL VALVE SKP-N/P-V PILOT ADJUMENT...
-
Page 9: Pilot Adjustment
CONT. PILOT THERMOCOUPLE ASSEMBLY Step 2; Install heat shield on Pilot Assembly as shown THERMOCOUPLE Fasten one 10-32 hex nut unto bolt screw close to pilot hood. LEADS Bend thermocouple lead and pilot tubing back to keep from crimping the leads. HEAT SHIELD WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property... -
Page 10: Normal Operating Characteristics
Do not use with blower inserts or heat exchangers. Do not operate this burner with any burner object other than the American Fireglass specifically designed and approved by American Fireglass with these burner systems. WARNING: Do not allow fans to blow directly into fireplace. Avoid any drafts that alter burner flame patterns.
