Connecting to the TV

•
Connect one end of the included S/AV cable into the
Super Retro® Trio Console S/AV port located on the back
of the console:
–
Red & white connection into the (L R) sockets
–
Yellow connection into the (V) socket
–
S-Video connection into the (S) socket
•
Plug the other end into the signal input ports on the TV
set, also matching the colors indicated.

Powering the SR3

•
Plug the DC end of supplied power adapter into the DC
socket on back of Super Retro® Trio Console
•
Plug the other end of the power adapter into wall outlet
PRECAUTIONS
•
Use ONLY the Super Retro® Trio AC Adapter included. Using a different AC adapter will damage your Super Retro® Trio Console.
•
When not in use, unplug the AC adapter from the electrical outlet.
•
Do not leave the system or any of its parts in direct sunlight, in damp areas or near a heater
•
Do not disassemble the console or any of its parts
