Dometic RM2662 Installation And Operating Instructions Manual

Dometic RM2662 Installation And Operating Instructions Manual

Refrigerator for lp-gas and electric operation
Hide thumbs Also See for RM2662:
Table of Contents

Advertisement

Quick Links

See also: User Manual , Installation Manual
REFRIGERATOR FOR LP-GAS AND ELECTRIC OPERATION
RM2662, RM2663
RM2862
FOR YOUR SAFETY
If you smell gas:
1. Open windows.
2. Don't touch electrical switches.
3. Extinguish any open flame.
4. Immediately call your gas supplier.
FOR YOUR SAFETY
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
WARNING: Improper installation,
adjustment, alteration, service or
maintenance can cause injury or
property damage. Refer to this
manual. For assistance or additional
information consult a qualified
installer, service agency or the gas
supplier.
USA
Service Office
Dometic Corporation
2320 Industrial Pkwy.
Elkhart, IN 46516
Phone: 574-294-2511
English 822701314MO-FO 0448 (French 3309771.016)
INSTALLATION AND
®
OPERATING INSTRUCTIONS
Pour votre sécurité
Si vous sentez une odeur de gaz:
1. Ouvrez les fenêtres.
2. Ne touchez à aucun interrupteur.
3. Éteignez toute flamme nue.
4. Avertissez immédiatement votre fournis-
Pour votre sécurité
Ne pas entreposer ni utiliser de l'essence ni
d'autres vapeurs ou liquides inflammables à
proximité de cet appareil ou de tout autre
appareil.
Avertissement: Une installation, un réglage,
une modification, une réparation ou un
entretien non conforme aux normes peut
entraîner des blessures ou des dommages
matériels. Lisez attentivement le mode d'em-
ploi fourni avec l'appareil. Pour obtenir de
l'aide ou des renseignements supplémentai-
res, consultez un installateur ou un service
d'entretien qualifié ou le fournisseur de gaz.
Corporate Office
2320 Industrial Parkway Elkhart, IN 46515
For Service Center Assistance
Call: 800-544-4881
Contents:
Installation
Operating Instructions
Maintenance & Service
seur de gaz.
®
CANADA
Dometic Distribution Inc.
866 Langs Drive
Cambridge, Ontario
N3H 2N7 Canada
Phone: 519-653-4390
Page
4
8
12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RM2662 and is the answer not in the manual?

Questions and answers

Related Manuals for Dometic RM2662

Summary of Contents for Dometic RM2662

  • Page 1 REFRIGERATOR FOR LP-GAS AND ELECTRIC OPERATION RM2662, RM2663 RM2862 FOR YOUR SAFETY If you smell gas: 1. Open windows. 2. Don’t touch electrical switches. 3. Extinguish any open flame. 4. Immediately call your gas supplier. FOR YOUR SAFETY Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
  • Page 3 Relay, 3-Way only Power module cover FIG. 1 Flexible cord 2 - WAY display panel 3 - WAY display panel LEGEND 2-WAY Model 1. Main Power Button ON/OFF 2. AUTO/GAS Mode Selector Button 3. Temperature Selector Button B. AC Mode Indicator Lamp C.

  • Page 4: Installation

    INSTALLATION GENERAL INSTRUCTION This appliance is designed for storage of foods and storage of frozen foods and making ice. This appliance is certified under the latest edition of ANSI Z21.19•CSA 1.4 Refrigerators using gas fuel. The installation must conform with local codes, or in absence of local codes, the following standards as ap- plicable.

  • Page 5: Securing The Refrigerator

    The 12 volt DC heater is fused with a 30 amp. in-line fuse. Recommended wire sizes are shown below. MAXIMUM TOTAL CONDUCTOR WIRE LENGTH (in feet and meters) RM2662, RM2862 Wire length 2-Way min. wire size 17 ft.

  • Page 6: Drain Water Hose

    FIG. 6 2. Once the lower front strip is slipped under the hinge, the part is possible to swing into place as shown in FIG. 6. 3. Secure the refrigerator and the lower front strip with two screws: One screw through the hinge, and on the opposite side one screw through the lower front strip.

  • Page 7: Certified Installation

    VENTILATION HEIGHTS Installation with roof Minimum ventilation vent and lower side vent heights in: Refrigerator Inches RM2662, RM2663 57-3/4 RM2862 63-3/4 FIG. 10 Condenser CLEARANCES Minimum clearances in inches to combustible materials are:...

  • Page 8: Operating Instructions

    Side view Overall Refrigerator Dimensions Model Height Width RM2662 inch 54-21/32 24-7/8 RM2663 1388 inch 60-51/64 24-7/8 RM2862 1544 This method of installation and these clearances will give you adequate space for service and proper installation. OPERATING INSTRUCTIONS IMPORTANCE OF LEVELING A...

  • Page 9: 2-Way And 3-Way Display Panels

    2-WAY display panel AUTO CHECK START UP INSTRUCTIONS A. A continuous 12 volt DC supply must be available for the electronic control to function. B. Press the main power ON/OFF button (1) to the DOWN position. C. Press the TEMPERATURE SELECTOR button (3) 2-WAY Model or (4) 3-WAY Model until the lamp at the desired setting is illuminated.

  • Page 10: Description Of Operating Modes

    2-WAY display panel AUTO CHECK THERMOSTAT The thermostat on the refrigerator, controls both the gas and electric operation, thereby eliminating the neces- sity of resetting each time a different energy source is employed. After the initial start-up, the thermostat should be moved from “COLDEST”...

  • Page 11: How To Use The Refrigerator

    Food in the lower compartment may be frozen if the set- ting is left on “COLDEST” position. Refrigerator volume. Total refrigerated volume is 6 cu.ft. for the models RM2662 and RM2663. Total refrigerated volume is 8 cu.ft. for the model RM2862.

  • Page 12: Refrigerator Removal

    SOLENOID VALVE INLET FITTING MANUAL SHUTOFF VALVE Shown in open position PRESSURE TEST PORT FIG. 12 ELECTRIC EQUIPMENT HEATER(S) The heat necessary for the operation of an absorption cooling unit is supplied by an electric heater mounted in a pocket of the boiler system. The 3-WAY Model is equipped with two electric heat- ers, one for 120 volt AC and one for 12 volt DC.

  • Page 13: Troubleshooting

    B. Check all connections in the LP gas system (at the back of the refrigerator) for gas leaks. The LP gas supply must be turned on. Apply a non-corrosive bubble solution to all LP gas connections. The appearance of bubbles indicates a leak and should be repaired immediately by a QUALIFIED SERVICEMAN WHO IS FAMILIAR WITH GAS SYS- TEM AND REFRIGERATORS.
  • Page 14 H. LP gas pressure low at burner. Set main regulator so pressure does not drop below 11 inches of water column at pressure test port. (See FIG. 12). I. Burner not located properly under flue tube. Relocate. J. Burner damaged. Replace.

  • Page 15: Panel Dimensions

    PANEL DIMENSIONS MAX. THICKNESS 5/32" (4 mm) REFR. MODELS TYPE RM2662 RM2663 upper inch lower inch RM2862 upper inch lower inch HEIGHT WIDTH MAX. MIN. MAX. MIN. 15-27/32 15-25/32 20-3/4 20-5/8 32-9/16 32-1/2 20-3/4 20-5/8 15-27/32 15-25/32 20-3/4 20-5/8 38-11/16...

  • Page 16: Spare Parts

    SPARE PARTS The following list is a list of commonly used parts, which should be available, if required, from your Dometic Ser- vice Center. A = RM2662; B = RM2663; C = RM2862. Part No. Description 17 37 68-03/7 A B C Heater, 325W, 120V...

  • Page 17: Positioning Of Shelves

    Put a screwdriver into the slot of the shelf lock. Turn the screwdriver counterclockwise. Remove the shelf locks from the wire shelf. Slide the wire shelf to the left. The right-hand side of the shelf will come loose. Lower the right-hand side of the wire shelf and let the left-hand side slide out of the holes in the wall.
  • Page 18 RM2662, RM2862 RM2663...
  • Page 20 MO-FO 0448...
