CryptoBox 550HDC User Manual

Hd digital cable receiver
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

User Manual

CryptoBox 550HDC
VFD
2xUSB
DISPLAY
FOR
400MHz
*ONLY FOR
MULTIMEDIA
550HD
AND MORE...
HD Digital Cable Receiver
xCX
1
xCI
1
optical
S/PDIF
1
x SLOT FOR
1
x SLOT FOR
SMARTCARD
CAM MODULES
PVR
RS232
TIMESHIFT
FOR
FOR AUTOMATIC
FOR
RECORDING
PAUSE & PLAY
ADVANCED USERS
& PLAYBACK
ECO
WiFi
ETHERNET
Low power
NETWORK
SUPPORT *WITH
consumption
CONNECTION
RECOMMENDED
in Stand By
USB WiFi DONGLE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 550HDC and is the answer not in the manual?

Questions and answers

Related Manuals for CryptoBox 550HDC

Summary of Contents for CryptoBox 550HDC

  • Page 1: User Manual

    User Manual CryptoBox 550HDC HD Digital Cable Receiver WiFi RS232 optical ETHERNET 2xUSB TIMESHIFT S/PDIF DISPLAY Low power x SLOT FOR FOR AUTOMATIC NETWORK SUPPORT *WITH x SLOT FOR 400MHz RECORDING PAUSE & PLAY consumption ADVANCED USERS CONNECTION RECOMMENDED *ONLY FOR...

  • Page 3: Table Of Contents

    Content ..............Safety Precaution 1. Reference ....................4 1.1 General Features ................4 1.2 Accessories ..................4 2. Product Overview ..................6 2.1 Front Panel ..................6 2.2 Rear Panel ..................7 2.3 Remote Control Unit (RCU) ............8 3. Connection with Other Device ............... 10 3.1 Connecting to TV .................
  • Page 4 6.7 Connecting to the LAN ..............23 6.8 USB Update .................. 24 6.9 Network Update ................24 6.10 About STB .................. 24 7. X-tras ...................... 25 7.1 Calendar ..................25 7.2 Games ................... 25 7.3 Network Apps ................25 8. Multimedia ....................26 8.1 Basic Operations ................

  • Page 5: Safety Precaution

    Safety Precaution This STB has been designed and manufactured to satisfy the international safety standards. Please read the following safety precautions carefully before operating this receiver. Main Supply: Before operating, please check the units operating voltage is 90~250V AC 50/60Hz. Overload: Do not overload a wall outlet, extension cord or adapter, neither use damaged power cord or touch it with wet hand as this may result in electric shock.

  • Page 6: Reference

    1. Reference 1.1 General Features DVB-C Compliant (MPEG-II/ MPEG-IV/ H.264) Sensitive Tuner with Loop-Through PAL/NTSC Conversion True full Color (32 bits) on screen display (OSD) Storing memory: 4000 transponders and 6100 channels 8 favorite group and parental lock supported Multi-language menu supported Multi-language audio supported Multi-language DVB Subtitle output 7 days Electronic Program Guide (EPG)
  • Page 7 Figure 1.Accessories...

  • Page 8: Product Overview

    2. Product Overview 2.1 Front Panel Figure 2. Front Panel 1. Power LED Power indicator. 2. Display It displays channel information. In standby mode it displays local time. 3. Power button Switch between operation and standby modes. 4. CH+/CH- Change channel in viewing mode and move the cursor up/down in menu mode.

  • Page 9: Rear Panel

    2.2 Rear Panel Figure 3. Rear Panel 1. LAN Connect to the internet using an Ethernet cable. 2. S/PDIF Digital Audio output (Optical). 3. RS232 Connect to the computer using a serial line. 4. TV SCART Connect to the TV using a Scart cable. 5.

  • Page 10: Remote Control Unit (Rcu)

    2.3 Remote Control Unit (RCU) You can control this receiver by this remote controller with full function. 1. POWER: Switch between operation and standby modes. 2. F1: Accessorial function. 3. SHIFT Enable/Disable timeshift. 4. MUTE: Mute audio. 5. I I : Pause/Time shift. 6.
  • Page 11 25. SUB: Display the subtitle language list. 26. TV/RAD: Switch between TV and RADIO. 27. FIND: Quickly find channels which you want. 28. V-FORMAT: Set the screen mode. 29. TXT: Display the teletext 30. AUDIO: Display the audio list.

  • Page 12: Connection With Other Device

    3. Connection with Other Device The following diagram shows you the connections among receiver, TV, LNB and other equipment, please read this first if you are not sure about the connection, and it will guide you to the correct connection. 3.1 Connecting to TV Figure 5.

  • Page 13: Connecting The Cable

    3.2 Connecting the CABLE You can connect one fixed Cable directly to the ATN IN. Figure6. Connecting to Cable & Router...

  • Page 14: Installation

    4. Installation You should install the receiver when powering on your product for the first time after purchase. Tip: The default password is 0000. If you have forgotten your password, please contact your local product distributor. 4.1 Powering On 1. Connect the power cord of the product to a wall outlet. 2.

  • Page 15: Auto Search

    Add Transponder Press GREEN button to add. Here you can input new transponder frequency: input new frequency, choose polarisation (16QAM, 32QAM， 64QAM， 128QAM， 256QAM) and input new symbol rate. Then Press the OK button to confirm the setting and this new Transponder will be added to the TP list.

  • Page 16: Channel Manager

    to the wizard. Warning: Please note that once you perform Factory Default all, all data and settings will be deleted. 1. Menu->INSTALLTION -> Factory Default 2. Input the password. 3. Highlight the option you want and press the OK button to execute it. Tip: If you select “yes”, all data and setting will be lost.
  • Page 17 similar to the TV Channels. 1. Move Channels 1) Press RED button to enter move mode. 2) Highlight the channel you want to move and press OK to select the channel. 3) Press the ▲/▼ button to the destination in the channel list and press the OK button.

  • Page 18: Edit Favorite

    Note: If the highlighted channel is locked, press the OK button is switched into Unlock. 4. Rename Channels 1) Highlight the Rename function by pressing BLUE button. 2) Highlight the channel you want to rename, press the OK button. 3) Enter a channel name directly using the keyboard displayed on the screen and press the BLUE button to complete.

  • Page 19: User Channel List

    Menu-> EDIT CHANNEL ->Sort Channels Highlight the option you want and press the OK button to sort the channel list. You can sort by LCN, Alphabet, Transponder, FTAToCAS, Default, Favor and FTAToCAS+ Alphabet. 5.4 User Channel List User Channel List allows you to save or load all the data and settings. 1.
  • Page 20 language. 7. LCN: Set the LCN ON or OFF. 8.Digital Audio: If a channel has AC3 and PCM audio language at the same time, when you select RAW it will set AC3 audio language as default output and when you select PCM it will set PCM audio language as default output.

  • Page 21: Osd Setup

    17.CH List type: You can set the Channel List type Wide or Simple. 6.2 OSD Setup Menu->SETTINGS->OSD Setup 1. Menu Transparency: Set the transparency of all menus. 2. TXT Transparency: Set the transparency of teletext. 3. Display Mode: Set the HD format between 1080p, 1080i, 720p, 576i Or 576p.

  • Page 22: Time Settings

    Menu-> SETTINGS ->Times 6.4.1 Time Settings Menu-> SETTINGS ->Times->Time Settings Time Settings will set the time mode, time zone and summer time. 1.Time Mode You can switch the Time Mode to Auto or Manual by pressing ◄/► button. If the Time Mode is Manual you can change the current time and current date.

  • Page 23: Sleep Timer

    save the timer after setup. Channel Select the Channel from Channel List. Date Input start date of the timer. Start/Stop Set Start and Stop time of the timer. Repeat <1X> only one time. <Day> Repeat every day. <Weekly> Repeat the channel weekly. <1-5>...

  • Page 24: Ca Menu

    6.4.4 Standby Hour Standby hour can set the time display on front panel when standby. 1. Menu-> SETTINGS ->TIMES-> Standby hour. 2. Press the ◄/► button to select the option. If set ON, the current time will shown on the front panel when standby. 3.

  • Page 25: Connecting To The Lan

    Module to the CI slot. 2.You can read the detail information about the smart card and CI module after it initialize OK. 3. The Pay-TV which correspond to CI module standard can be decoded. 6.7 Connecting to the LAN 6.7.1 IP Setting Connect one end of the Ethernet cable to the product and the other end to the LAN...

  • Page 26: Usb Update

    list. Press the OK button, then input the right password. And you can press YELLOW button to disable/enable the WI-FI. Enter Menu-> SETTINGS->Wireless Setting->IP Setting. If the Network is connected, it will get the correct IP address and display the “Connect”.

  • Page 27: X-Tras

    7. X-tras 7.1 Calendar Menu->X-tras-> calendar Calendar can get the date information. And you can add the memo of the day. 7.2 Games Menu->X-tras-> games Games offer 9 funny games you can play. 7.3 Network Apps 7.3.1 FTP Download You can Download S/W, music, photo and other media files from the FTP.

  • Page 28: Multimedia

    7.3.2 Weather Forecast Menu->X-tras ->Network Apps->Weather Here you can input the city name to browse the weather of this city in future 5 days. RED: Change the city and unit of temperature. 7.3.3 RSS Menu-> X-tras->Network Apps ->RSS You can press the RED button to add the RSS websites and then you can read content of the websites.

  • Page 29: Basic Operations

    playback it and you can do various operations when using USB HDD or USB disk. Note: It supports FAT, FAT32 and NTFS format USB disk or USB HDD. 8.1 Basic Operations 1. Tool Rename Files Highlight the file or folder. Press the RED button and Rename Highlight the...

  • Page 30: Setting

    Sort Press the RED button and Highlight the Sort. Select the sort type. (Default/First Name/Date/Size) Press the OK button to sort by sort type which you selected. Format Disk Highlight a disk partition or enter a disk partition. Press the RED button and Highlight the Format Disk. Press the OK button and then select a format mode (Fat and NTFS).

  • Page 31: Play Files

    Photo View Mode Set the Photo View Mode state on Full Screen, 2x2 Thumbnail or 2x3 Thumbnail. 2. PVR Setting Record Partition Select the Partition where save your record or other result of your operation. Record Type Set the Record Type TS or PS. Record Time Set the Record Default Time off, 30, 60, 90, 120 minute or input...
  • Page 32 OK: Play the selected file. ▲/▼: Change the highlighted item. ►: Play the file. ■ : Stop playing file. ◄◄: Fast rewind. ►►: Fast forward. PAUSE/||: Pause. VOL+/VOL-: Adjust volume. EXIT: Exit playing state and return to file list menu. 2.
  • Page 33 3. Movie 1) Press the ◄/► to highlight the Movie. 2) Press the ▲/▼ to change the folder or file and press the OK button to open the folder or play the movie file. OK: View play list or play the highlighted file in the play list. ►: Play the file.

  • Page 34: Basic Operation

    AUDIO: Set the audio language. SUB: If the file has subtitle, press the SUB button can change the subtitle. TXT：If the file has teletext, press the TXT button can display the teletext. CH+: Mark on current time when info bar display. CH-: Jump to mark when info bar display.

  • Page 35: Epg

    You can select the language you prefer in Audio if the current program is available in multiple audio languages. Press the AUDIO button 2. Press ▲/▼ button and then press the OK button to select the audio language you prefer. 3.

  • Page 36: Subtitle

    Highlight the EPG event which you want, press the RECORD button to enter Timer Setup menu. After setup, press the OK button can add the EPG event to the Timer. 4) Press the RED button to switch EPG language. Day EPG: 1) Press the ▲/▼button to change channel.

  • Page 37: Find Channel

    information of this program. 1. Press the TXT button. 2. Press the ▲/▼ button to page up or page down. 3. Press the NUMERIC(0-9) buttons can go to the designated page directly. 4. Press the color button can back to the previous page. 9.5 Find channel You can find the channels you want quickly just by pressing the FIND button directly.

  • Page 38: Channel List

    : Current program has teletext information. : Current program is unlocked. : Current program is locked. : Current program is not a HD program. : Current program is a HD program. 2. EPG Information Press the INFO button twice to view detailed EPG information, press ◄/►...

  • Page 39: Favorite List

    Channels/Scramble Channels/HD Channels) 3) Press the GREEN button to list the channels by Provider. 4) Press the YELLOW button can help you find the channel quick by the first character of name. 5) Press the BLUE button to enter the Quick Find menu. 10.2 Favorite List 1) If you have set several favorite lists, press the FAV button can...

  • Page 40: Usb Control

    11. USB Control 11.1 Recording and Timeshift 1. Start Recording 1) You can press the ● button to start recording while watching program. 2) If you have set the timer, and set the Time Record on, it will start recording automatically according to the start time of the timer.

  • Page 41: Pvr List

    can play the program, press the INFO button can display the recording information, press the PAUSE/|| button can pause or play the program, press the ◄◄/►► button can fast rewind or fast forward. Press the ■ button to stop timeshift. If you change to another program or do other operations, it will stop timeshift but still record.
  • Page 42 1. No message displayed on the front display. (The product will not switch on.) • Check the main power cable and make sure it is plugged into a suitable power outlet. • Check that the mains supply is switched on. •...
  • Page 43 • Make sure the Wi-Fi can work on other device. • Input the Wi-Fi password again. • Get auto IP again. • Restart the receiver again.
  • Page 48 CryptoBox 550HDC HD Digital Cable Receiver...
