Proconx MBRG-300 User Manual

Modbus router/gateway
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MBRG-300
Modbus Router/
Gateway
User manual
UMMBRG300-1101

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MBRG-300 and is the answer not in the manual?

Questions and answers

Summary of Contents for Proconx MBRG-300

  • Page 1 MBRG-300 Modbus Router/ Gateway User manual UMMBRG300-1101...

  • Page 2: Document Revision History

    Disclaimer proconX Pty Ltd makes no warranty for the use of its products, other than those expressly contained in the Company’s standard warranty which is detailed in the Terms and Conditions located on the Company’s Website. The Company assumes no responsibility for any errors which may appear in this document, reserves the right to change devices or specifications detailed herein at any time without notice, and does not make any commitment to update the information contained herein.

  • Page 3: Table Of Contents

    IP setup using a terminal program like HyperTerminal ........12 Temporarily changing the IP settings on your PC ..........13 5 Web browser based management ................. 15 Connecting to the MBRG-300 ................15 Monitoring and diagnostic ................16 Device status ....................16 Modbus connection status ................
  • Page 4 5.5 Ethernet and IP settings page ................18 5.6 IP settings changed confirmation ............... 19 5.7 Modbus settings page ..................19 5.8 Restart device page .................... 20 5.9 Restart confirmation page .................. 20 A.1 Enclosure dimensions ..................27 Tables 2.1 LED diagnostic codes .................... 4 3.1 Power supply connector pinout ................

  • Page 5: Important User Information

    • Apply appropriate personal protective equipment and follow safe electrical practices. • Turn off all power supplying the equipment in which the MBRG-300 is to be installed before installing, wiring or removing the MBRG-300. • Always use a properly rated voltage sensing device to confirm that power is off.

  • Page 6: Document Conventions

    Document conventions Throughout this manual we use the following symbols and typefaces to make you aware of safety or other important considerations: Indicates a potentially hazardous situation that, if not avoid- ed, could result in death or serious injury. Indicates a potentially hazardous situation that, if not avoid- ed, could result in damage to equipment.

  • Page 7: Introduction

    Introduction Chapter 1. Introduction The MBRG-300 is a Modbus/TCP to Modbus RTU gateway. The gateway features one serial port which can be configured as either RS-232, RS-485 or RS-422 and an Ethernet port. It can be mounted on a DIN rail.

  • Page 8: Features

    Features The MBRG-300 gateway provides the following key features: • Modbus/TCP protocol (Ethernet) • Modbus RTU protocol (either RS-232, RS-485 or RS-422, software configurable) • Embedded web server for easy configuration and commissioning using a web browser • Firmware upgradeable via Ethernet •...

  • Page 9: Description

    Description Chapter 2. Description The power and RS-485/RS-422 terminals are placed on the top side of the unit. The RS-232 and Ethernet connectors are placed on the bottom side of the unit as shown in the following illustration: TOP VIEW BOTTOM VIEW FRONT VIEW Figure 2.1: Location of connectors  ...

  • Page 10: Led Diagnostic Codes

    The following table outlines the indicator condition and the corresponding status after the power-on self test has been completed: Function Condition Indication No power applied to the device. Power Power Green Power supply OK No Ethernet link Link Ethernet link Green Ethernet link OK The device has an unrecoverable fault;...

  • Page 11: Installation

    Regulatory notes 1. The MBRG-300 is suitable for use in non-hazardous locations only. 2. The MBRG-300 is not authorized for use in life support devices or systems. 3. Wiring and installation must be in accordance with applicable electrical codes in accordance with the authority having jurisdiction.

  • Page 12: Din Rail Mounting And Removal

    DIN rail mounting and removal The MBRG-300 gateway is designed to be mounted on a 35 mm DIN rail according to DIN/EN 50022. The enclosure features a 35 mm profile at the back which snaps into the DIN rail. No tools are required for mounting. Please observe the rules outlined in the section called “Mounting rules”.

  • Page 13: Powering The Mbrg-300

    Wiring the RS-485/422 interface The RS-485/422 port is used for integrating the MBRG-300 into a two-wire or four-wire Modbus over Serial Line network. The use of either the RS-485 or RS-422 interface must be configured using the web interface (See the section called “Configuring serial line Modbus”).

  • Page 14: Connecting Ethernet

    • The shield must not be connected to the GND pin. To connect the MBRG-300 to a PC (Personal Computer) or any other device with data terminal equipment (DTE) pinout you need a null-modem or cross-over cable.
  • Page 15 Installation • Maximum cable length is 100 m (3000 ft). UMMBRG300-1101...
  • Page 16 This page intentionally left blank UMMBRG300-1101...

  • Page 17: Ethernet & Ip Configuration

    “Temporarily changing the IP settings on your PC”). In order to connect to the MBRG-300 via TCP/IP, your PC must be on same IP subnet as the gateway. In most situations this means that the first three numbers of the IP address have to be identical.

  • Page 18: Ip Setup Using A Terminal Program Like Hyperterminal

    IP setup using a terminal program like HyperTerminal 1. Connect a null modem RS-232 cable between your PC and the MBRG-300’s Serial Port 1. 2. In Windows XP, click Start, point to All Programs, point to Accessories, point to Communications, and then click HyperTerminal.

  • Page 19: Temporarily Changing The Ip Settings On Your Pc

    This method involves manually assigning an IP address to your PC in the same subnet as the gateway. The default subnet of the gateway is 169.254.0.0/16. 1. Connect the MBRG-300 to your Ethernet network. 2. On a Windows PC, open the Control Panel and double-click on Network Connections.
  • Page 20 8. Click Configuration… and then Ethernet & IP in the menu on the left side of the page. 9. Enter the IP address, subnet mask, and gateway address assigned to your MBRG-300, then click Save. 10.Restore your computer’s original settings.

  • Page 21: Web Browser Based Management

    Once you made sure that your PC is configured to be on the same subnet as the MBRG-300, start your web browser. In the address box, type the IP address of your device (169.254.0.10 is the default), and then press Enter. (See Chapter 4, Ethernet &...

  • Page 22: Monitoring And Diagnostic

    In order to connect to the MBRG-300 via TCP/IP, your PC must be on same IP subnet as the gateway. In most situations this means that the first three numbers of the IP address have to be identical. Monitoring and diagnostic The MBRG-300 offers several web pages which allow monitoring of the status of the different communication networks and the device performance.

  • Page 23: Modbus Status Page

    Web browser based management Figure 5.3: Modbus status page This page shows accumulated readings since the MBRG-300 was last activated or reset. If power to the MBRG-300 is lost, all cumulative values are reset to zero. The following statistics are maintained: TCP status Status of the TCP/IP connection as per TCP finite state machine (refer to RFC 793).

  • Page 24: Finding The Firmware Version And Serial Number

    The firmware version that is installed on the MBRG-300. Serial number The serial number of the MBRG-300. The serial number is specific to your device. Configuring and commissioning The configuration pages are accessed by clicking on the Configuration… menu entry on the menu bar which then expands a configuration sub-menu.

  • Page 25: Configuring Serial Line Modbus

    Depending on this setting either the D-sub (RS-232) connector or the terminal block connector (RS-485/422) of the MBRG-300 is utilized. The (RS-485 + RS-422) mode is a special mode which allows operating one RS-422 device and a RS-485 bus one the same serial interface.

  • Page 26: Remote Restarting The Device

    Baud rate 9600 and 19200 are the most common baud rates for Modbus. 19200 is the default setting. Data bits Only 8 data bits can be selected here which is a requirement for RTU. Stop bits Can be configured to be 1 or 2. The Modbus standard mandates that 2 stop bits are configured when using no parity.
  • Page 27 Web browser based management Please allow a few seconds before continuing working with the device as it has to fully start-up first, before being able to respond to further web browser requests. After a remote restart a Watchdog reset alarm is shown on the device' home page. This is a side-effect of the remote restart procedure and the alarm shall be ignored and cleared.
  • Page 28 This page intentionally left blank UMMBRG300-1101...

  • Page 29: Decommissioning

    1. Ensure that the system power and external supplies have been turned off. 2. Disconnect power supply plug. 3. Disconnect all I/O cables. 4. Remove the MBRG-300 from the DIN rail following the procedure described in the section called “DIN rail mounting and removal”. Disposal This product must be disposed of at a specialized electronic waste recycling facility.
  • Page 30 This page intentionally left blank UMMBRG300-1101...

  • Page 31: A Specifications

    Specifications Appendix A.  S pecifications Product name MBRG-300 Interfaces Ethernet Serial ports 2, software configurable as either 2 x RS-232 or 2 x RS-485 or 1 x RS-232 + 1 x RS-485 or 1 x RS-422 User interface LED indicators Power (green), Ethernet link (green), 2 status (bi-color red/green) Monitoring &...
  • Page 32 Speed 10 Mbit/s Max. cable length 100 m (328 ft) Ethernet frame types 802.3 Protocols Modbus/TCP slave, HTTP , IP , TCP , ARP Concurrent connections 4 Modbus/TCP slave, 2 HTTP Power supply Connector 3.81 mm 2-pin pluggable terminal block header Voltage 10-30 V DC Current...

  • Page 33: Dimensions

    Specifications Dimensions 120.0 mm 22.5 mm 4.72 in 0.89 in Figure A.1: Enclosure dimensions UMMBRG300-1101...
  • Page 34 This page intentionally left blank UMMBRG300-1101...

  • Page 35: Glossary

    Glossary Glossary Electromagnetic interference Electrostatic discharge. ESD can damage electronic equipment. 10BASE-T Ethernet 10 Mbit/s twisted pair Ethernet standard. The standard for local area networks Standardized in IEEE 802.3i developed jointly by Digital Equipment Corp., Xerox, and Intel. Ethernet is used as APIPA the underlying transport vehicle by several Automatic Private IP Addressing...
  • Page 36 NEMA National Electrical Manufacturers Association. NEMA defines standards for various grades of electrical enclosures. Node A communications device on the network. PC/ABS Polycarbonate-ABS. Widely used thermoplastic material. Programmable Logic Controller RS-232 See EIA-232. RS-422 See EIA-422. RS-485 See EIA-485. Subnet mask A numeric address used in conjunction with an IP address to segment network traffic;...

  • Page 37: Index

    Index Index settings, 19 faults, 16 features, 2 About, 18 Firmware version, 18 Accumulative connections, 17 APIPA, 11 Gateway address, 19 grounding, 5 Baud rate, 20 Brown out reset, 16 Hardware version, 18 HyperTerminal, 12 cable RS-232, 8 cable length Invalid frames, 17 Ethernet length, 9 RS-232, 8...
  • Page 38 Requests, 17 Reset to factory defaults, 16 restart, 20 RJ-45, 8 RS-232, 8 run-time faults, 16 Rx time-outs, 17 Serial number, 18 settings Ethernet, 19 IP, 11, 19 Modbus, 19 shield, 8 shielding, 5 shock, 7 Slave ID for RS-422 node, 20 Specifications, 25 Stop bits, 20 storage, 5...
  • Page 39 Notes Notes UMMBRG300-1101...
  • Page 40 This page intentionally left blank UMMBRG300-1101...
