INTERNET RADIO & MEDIA PLAYER

User's Guide

After Sales Support

Now you have purchased a Internet Radio & Media Player you can rest

assured in the knowledge that as well as your 3 year parts and labour

warranty you have the added peace of mind of dedicated helplines and

web support:

Table of Contents

Need help?

Do you have a question about the INTERNET RADIO & MEDIA PLAYER and is the answer not in the manual?

Questions and answers

Summary of Contents for Tevion INTERNET RADIO & MEDIA PLAYER

Page 1 INTERNET RADIO & MEDIA PLAYER User’s Guide After Sales Support Now you have purchased a Internet Radio & Media Player you can rest assured in the knowledge that as well as your 3 year parts and labour warranty you have the added peace of mind of dedicated helplines and web support:...
Page 2: Table Of Contents
Contents Introduction General Information and Safety Instructions Assembly and Parts List Getting Started – Internet Radio Getting Started – Media Player Features Instructions Other Useful Information Warranty Card Fault Report Card Helpline No.: UK/N. Ireland: 08000 324976 Rep. of Ireland: 1800 523188 Web Support: www.unisupport.net...
Page 3: Introduction
INTRODUCTION INTERNET RADIO QUICK START GUIDE What you need before you can use your Internet radio Before you can use your Internet radio, you need the following: • A broadband Internet connection. • A wireless access point (Wi-Fi) connected to your broadband Internet, preferably via a router.
Page 4 Control Internet Radio mode Media Player mode IR/FM Press to switch between Internet Radio and FM mode. Press and hold to turn on/off the Internet Radio Browse No function Display Queue information Reply No function at present No function at present Press and hold to save Preset Previous Track station P1...
Page 5: Assembly And Parts List
Please read this before installation. If this Internet radio has been moved from a cold place to a warm place, DO NOT plug it in for 2-3 hours (e.g. from a cold car boot to a warm room). There is a possibility that moisture may have condensed in the Internet radio, which can cause damage to your Internet radio.
Page 6: Getting Started – Internet Radio
GETTING STARTED – INTERNET RADIO Steps for connecting your radio to your wireless network Step 1 - Power up the radio First, connect to the AC Power. In use, the radio can be switched on or off with the standby button.
Page 7 When the radio finds your wireless network, it displays the ESSID for the access point on the screen - this is a name that is allocated to the access point by the person who set up the network - for example: <...
Page 8: Getting Started – Media Player
Only the person who set up the network in the first place knows this code; if that person is not you then you need to find out what it is. After 3 seconds, the display goes into the code entry mode. To enter the code, use the < and > button to select each character of the code in turn, pressing the SELECT button after each character.
Page 9: Features
FEATURES Two line display. Supports RealAudio, MP3 and Windows MediaTM streams. FM radio. Speakers: 2 off. Full range. Stereo. WI-FI security is supported by WEP or WPA encryption. Output power (RMS): 2 watts. Total power: 4 watts. Radio presets: 10 with station name display. INSTRUCTIONS Internet Radio Choosing a radio station to listen to...
Page 10 Press the < or > button until the display shows the station you want. Press the SELECT button and wait until the radio connects to that station. Note that some radio stations do not broadcast 24 hours per day, and some stations are not always on-line.
Page 11 Storing a radio station in a preset Whilst a radio station is playing, hold down one of the preset buttons (numbered 1 to 5) until the screen says Assigned to Preset # Where # is the number of the button you held down. To assign a radio station to one of the presets numbered 6 to 10, press SHIFT and then press and hold one of the preset keys.
Page 12 Press the < or > button to choose <Live> or <On Demand>, then press the SELECT button. If you choose <Live> then the radio plays the current output from this station as normal. If you choose <On Demand> then more screens are displayed where you choose what you want to listen to.
Page 13 Setting the clock Press the SELECT button. (Note: if you make a mistake at any point, press the BACK button to go back to the previous screen.) Press the < or > button until the display says <Configure>. < Configure >...
Page 14 Setting the alarm Press the SELECT button. (Note: if you make a mistake at any point, press the BACK button to go back to the previous screen.) Press the < or > button until the display says <Configure>. < Configure >...
Page 15 Press the < or > button until the hour setting is correct, then press the SELECT button. Set Alarm 07:06 10. Press the < or > button until the minute setting is correct, then press the SELECT button. Alarm Set: 07:45 The display says Alarm Set with the time of the alarm shown beneath for 3 seconds and then returns to the radio station display.
Page 16 Listening to a single shared track Press the < or > button until ‘By Artist’ is displayed. Press the SELECT button. Press the < or > button until the required artist is displayed. Press the SELECT button. Press the < or > button until the required album name is displayed. Press the SELECT button.
Page 17 Controlling playback Use the STOP button to stop playback. Use the PLAY/PAUSE button to either pause a currently playing track or to restart a currently paused track or to restart a stopped track. Use the SKIP TO PREVIOUS TRACK button to start playback of the previous track in the queue.
Page 18 Playing tracks in random order Select the individual tracks as described previously. Navigate to top-level menu item 'Media Player' using the SELECT and BACK buttons. Press the SELECT button. Press the < or > button until 'Playback Mode' is displayed. Press the SELECT button.
Page 19 Set up a Windows PC to allow the radio to access your audio files via a UPnP server If your PC is running Microsoft Windows XP or Windows Vista, then you can use Windows Media Player 11 (WMP11) to act as your UPnP (Universal Plug and Play) media server 1.0.
Page 20 Selecting ‘Media Sharing…’ for Windows Media Player 11: From the ‘Media Sharing’ window, the radio will be listed as an unknown device. Click on the unknown device listed, then click the ‘Allow’ button and then click ‘OK’. Helpline No.: UK/N. Ireland: 08000 324976 Rep. of Ireland: 1800 523188 Web Support: www.unisupport.net...
Page 21 Allowing the Radio to Connect: Locating and playing media files using the radio and UPnP Once the UPnP server is configured to share media files with the Internet radio, you can play the files by doing the following on the radio. Keep pressing BACK to get to the radio’s top-level menu and then press the <...
Page 22 Browsing the list of tracks currently queued up for playback Press the BROWSE button. The currently playing track name will be displayed. Press the < or > button to see which tracks are queued up for playback. If you want to jump to a particular place in the queue then press the SELECT button when the required track is displayed.
Page 23 Removing tracks from the queue Press the BROWSE button. The currently playing track name will be displayed. Press the < or > button to select the track you want to remove from the queue. Press and hold the STOP button for 2 seconds. Press the <...
Page 24 CONFIGURE MENU Choosing the option you want from the Configure menu Press the SELECT button. (Note: If you make a mistake at any point, press the BACK button to go back to the previous screen.) Press the < or > button until ‘Configure’ is displayed. Press the SELECT button.
Page 25 <FACTORY RESET> Puts all the settings back to their defaults as they were when they left the factory. If you perform a factory reset on your radio you will lose all your presets and your wireless network connection. <REGISTER> This will display a key that can be used to register the radio on the Reciva Customer portal: http://www.reciva.com/ LISTENING TO FM RADIO Switching to FM mode...
Page 26 SYSTEM MENU Setting the Bass Press and HOLD the SELECT button for approx 2 seconds. (Note: if you make a mistake at any point, press the BACK button to go back to the previous screen.) Press the SELECT button to select <Set Bass>. <...
Page 27 Setting the clock Press and HOLD the SELECT button for approx 2 seconds. (Note: If you make a mistake at any point, press the BACK button to go back to the previous screen.) Press the < or > button until the display says <Set Clock>. <...
Page 28 Setting the alarm Press and HOLD the SELECT button for approx 2 seconds. (Note: if you make a mistake at any point, press the BACK button to go back to the previous screen.) Press the < or > button until the display says <Set Alarm>. Press the SELECT button. <...
Page 29 Press the SELECT button and press < or > button to set the alarm mins. Set Mins < 02:05 > 10. Press the SELECT button and press < or > button to set the alarm mode. Set Hour < 02:00 >...
Page 30 Setting the Backlight Selecting this option will alter the radio’s backlight values. After selecting the ‘Backlight’ menu item, the radio will display its list of two menu modes: ‘Timed and Always on’. Timed: The backlight will dimmed when there is no user activity for 10 seconds. •...
Page 31 If you experience any trouble with your wireless Internet radio, then you may find it useful to visit the help section on our webpage: http://www.reciva.com. If you have trouble connecting the radio to your wireless network, these steps may help to resolve the problem: Confirm that a Wi-Fi connected PC can access the Internet (i.e.
Page 32: Other Useful Information
OTHER USEFUL INFORMATION Configuring ‘My Stuff’ Registering an account on Reciva’s website Open the website, http://www.reciva.com, from your Internet browser. Click on the ‘My Account’ link and follow the on-screen instructions to register an account. Please note, during the registration process, a validation code will be sent to you via email. Please enter this code when prompted to do so.
Page 33 Configuring ‘My Streams’ Once logged into your Reciva website account, you can add your own Internet radio streams to the ‘My Streams’ section, which is listed under the ‘My Account’ section Clicking on ‘My Streams’ will prompt you to enter the station’s name and its media stream URL.
Page 34: Warranty Card
Internet Radio & Media Player WARRANTY CARD Congratulations! You have made an excellent choice with the purchase of this quality product. Our commitment to quality also includes our service. Should you, contrary to expectations, experience defects due to manufacturing faults during private use within 36 months of the date of purchase we shall be liable for warranty in accordance with statutory warranty regulations provided that:: - the device was not put to any use other than the intended - was not overloaded...
Page 35: Fault Report Card
Internet Radio & Media Player FAULT REPORT CARD Name Address E-mail Daytime Tel No Fault Description If you have previously contacted our helpline please provide us with the reference (RMA) number you were issued. In order to deal with your enquiry as quickly and efficiently as possible, we ask you to send your enquiry by e-mail.
