Summary of Contents for Combi A7LA50D Mini 0803
- Page 1 A7LA50D Mini 0803 Dashcam User’s Manual For Portable Car Video Recorder Please Read This Manual Carefully Before Using The new 0803. For Accessories & Sales Go to: http://www.combi.org.uk/...
- Page 2 Preface Precautions General precautions · Do not expose this product to dusty, dirty or sandy areas to reduce the risk of damaging components. · Do not expose the recorder to high temperature. High temperature may shorten the life span of electronic device, damage the battery and wind or melt specific plastic parts.
- Page 3 1.2 Recorder appearance and feature icons 1. GPS tracker box also bracket ,3M sticker put here and then stick to car front window. If no GPS ,it is as a bracket only, 2.Micro USB port 3. AV port 4.Up button/menu/mute hot button 5.
-
Page 4: Operation
Operation Read this chapter to know how to operate the recorder. 2.1 Inserting a TF card (Micro SD Card) Inserting a TF card into the recorder provides more space to store videos, images or other files. Please use high-speed TF card meeting the specification of TFHC. （ CLASS 4 or 6, Class 10 may cause some problem because the speed of card is too fast, it is better not to use class 10 card ) 2.2 Turning on your recorder Press Power button to turn ON/ OFF the power. - Page 5 2.When the loop setting mode is "1 min","3min",5min" automatically a. Power on , the device will record b.if the space is full, the previous saved file will be automatically cover and overwrite. 2.5.4 Setting other features Read this chapter to know how to configure the setup and fine-tune the functions Power on the recorder.
-
Page 6: Recording Mode
2.5.6 GPS: Open/close GPS tracking ( effective with GPS-IN function) For the model with GPS ,If NO GPS ,NO this function 1. Plug in the GPS module to the DVR, satellite searching will be start automatically . 2. When GPS signal is located, will be showed on the display . -
Page 7: Playback Mode
Super HD Resolution Date and Time 2008/01/01 01：07AM Segmented loop recording time 3.2 Playback mode Using Play back mode to display all the video files saved in the DVR . About the indication of each icon and symbol, see the table below 000:00:15 Playback time Play... -
Page 8: Specification
Appendix Specification Image Sensor 3.2M CMOS Chip Ambarella , A7L50D Lens 135 Wide angle External memory Built-in TF card (up to 32 G) Internal memory None Auto Display 1.5″TFT Still images Format：JPEG Quality：Auto Videos Format：H.264 (MOV) Resolution：2304x1080 30fps ,1944×1080 30fps、1920×1080 30fps、 1280×720 30fps、... -
Page 9: Troubleshooting
Troubleshooting Question Possible reasons Solutions The camcorder is suddenly Auto Off Function is On. ·Turn on again the recorder turned off Low battery Charge battery Captured images are not Power is off before the Charge battery saved into memory images are saved. Memory card cannot be used Memory card is protected.
