2522-7216-00 (900-0233):_

Carbon Monoxide Alarm

User's Guide

Model: KN-COB-B-LS-UK (900-0233)

• Peak Level Memory

• 3-AA Battery Operation

ATTENTION: Please take a few minutes to thoroughly read this

user's guide which should be saved for future reference and passed

on to any subsequent owner.

Manual P/N 2522-7216-00

2011.10.21

5:10 PM

KM 98848

EN50291:2001

KN-COB-B-LS-UK

(900-0233)

Page 1

Table of Contents

Need help?

Do you have a question about the KN-COB-B-LS-UK and is the answer not in the manual?

Questions and answers

Summary of Contents for PSA Products KN-COB-B-LS-UK

Page 1: Carbon Monoxide Alarm
5:10 PM Page 1 KM 98848 EN50291:2001 Carbon Monoxide Alarm User’s Guide Model: KN-COB-B-LS-UK (900-0233) KN-COB-B-LS-UK (900-0233) • Peak Level Memory • 3-AA Battery Operation ATTENTION: Please take a few minutes to thoroughly read this user’s guide which should be saved for future reference and passed on to any subsequent owner.
Page 2: What To Do When The Alarm Sounds
2522-7216-00 (900-0233):_ 2011.10.21 5:10 PM Page 2 What to do When the Alarm Sounds! Carbon Monoxide Alarm Procedure WARNING: Actuation of your CO Alarm indicates the presence of Carbon Monoxide (CO) which can kill you. When the CO alarm senses a dangerous level of CO, the unit will emit a loud alarm pattern.
Page 3: Important Warning Statements
This manual and the products described are copyrighted, with all rights reserved. Under these copyright laws, no part of this manual may be copied for use without the written consent of PSA Products.. If you require further information, contact our Consumer Hotline, or write to us at:...
Page 4 Local Authority or retailer for recycling advice. Contents of This User’s Guide 1. Information About Carbon Monoxide 2. Product Features and Specifications 3. Installation Locations 4. Installation Instructions 5. KN-COB-B-LS-UK(900-0233) Operating Characteristics 6. Alarm Characteristics 7. Maintenance 8. Limited Warranty...
Page 5: Information About Carbon Monoxide
2522-7216-00 (900-0233):_ 2011.10.21 5:10 PM Page 5 1. Information About Carbon Monoxide General Carbon Monoxide Information Carbon monoxide is a colourless, odorless and tasteless poison gas that can be fatal when inhaled. CO inhibits the blood’s capacity to carry oxygen. Periodically review this alarm manual and discuss your CO alarm emergency procedure with all the members of your family.
Page 6 2522-7216-00 (900-0233):_ 2011.10.21 5:10 PM Page 6 1. Information About Carbon Monoxide Carbon Monoxide PPM Levels Dangerous Levels: When someone is experiencing symptoms of CO poisoning and CO readings are generally above 100 PPM. Anytime someone is experiencing the symptoms of CO poisoning this should be treated as an emergency. See “What to do When the Alarm Sounds”...
Page 7 2522-7216-00 (900-0233):_ 2011.10.21 5:10 PM Page 7 1. Information About Carbon Monoxide Conditions That Can Produce Carbon Monoxide The following conditions can result in transient CO situations: • Excessive spillage or reverse venting of fuel-burning appliances caused by outdoor ambient conditions, such as, wind direction and/or velocity, including high gusts of wind, heavy air in the vent pipes (cold/humid air with extended periods between cycles).
Page 8 2522-7216-00 (900-0233):_ 2011.10.21 5:10 PM Page 8 your unit has alarmed and you’ve provided ventilation by leaving your windows and doors open, the CO buildup may have dissipated by the time help responds. Although your problem may appear to be temporarily solved, it’s crucial that the source of the CO is determined and that the appropriate repairs are made.
Page 9: Product Features And Specifications
Power LED Red, Alarm LED Model KN-COB-B-LS-UK (900-0233) WARNING: After seven (7) years from initial power up, this alarm will “beep” every 30 seconds to indicate that it is time to replace the alarm. Replace the alarm immediately! It will not detect CO in this condition.
Page 10: Installation Locations
2522-7216-00 (900-0233):_ 2011.10.21 5:10 PM Page 10 3. Installation Locations Recommended Installation Locations CO alarms should be mounted in or near bedrooms and living areas. It is KITCHEN BEDROOM BEDROOM DINING recommended that you install a PSA CO alarm on each level of your home. When choosing your installation LIVING ROOM BEDROOM...
Page 11: Installation Instructions
2522-7216-00 (900-0233):_ 2011.10.21 5:10 PM Page 11 4. Installation Instructions Battery Installation and Replacement This CO alarm must be installed by a competent person. To install or replace the batteries in this Lifesaver CO alarm, please perform the following steps. 1.
Page 12 2522-7216-00 (900-0233):_ 2011.10.21 5:10 PM Page 12 4. Installation Instructions Mounting This CO alarm can be either wall mounted or placed on a tabletop. For wall mounting, follow these steps: 1. Mark the location of the two holes needed on the wall using the battery door as a template.
Page 13 2522-7216-00 (900-0233):_ 2011.10.21 5:10 PM Page 13 5. Model KN-COB-B-LS-UK(900-0233) Operating Characteristics Whenever the alarm is operating, the green Power LED flashes every 30 seconds to indicate the unit is monitoring for CO. If the alarm senses dangerous levels of CO, the red Alarm LED will flash and the alarm will emit an audible alarm pattern.
Page 14: Alarm Characteristics
2522-7216-00 (900-0233):_ 2011.10.21 5:10 PM Page 14 6. Alarm Characteristics Carbon Monoxide Alarm Indicator When the alarm senses a dangerous level of CO, the unit will emit a loud alarm pattern. The alarm pattern is a series of ON/OFF beeps as long as dangerous CO conditions exist.
Page 15 2522-7216-00 (900-0233):_ 2011.10.21 5:10 PM Page 15 7. Maintenance • Using aerosols or adhesives WARNING: Reinstall the CO Alarm as soon as possible to assure continuous protection. Accommodation spaces should be well ventilated when household cleaning supplies or similar contaminants are used. The following is a list of substances that at high levels can damage the sensor or cause temporary readings that are not CO readings: •...
Page 16 For Warranty Service: In many cases the quickest way to exchange your CO alarm is to return it to the original place of purchase. If you have questions, call the PSA Products customer service department on 1300 772 776 Thank y ou for purchasing and installing the most trusted brand in fire, security and intercoms.

This manual is also suitable for:

Lifesaver kn-cob-b-ls-uk Lifesaver 900-0233
