Grifo Tele Web User Manual

Telecontrol module through the web tele web controller

Advertisement

Quick Links

Tele Web Controller
Telecontrol Module through the WEB
USER MANUAL
®
grifo
ITALIAN TECHNOLOGY
http://www.grifo.it
Tel. +39 051 892.052 (a. r.) FAX: +39 051 893.661
Tele Web Controller
, GPC
Via dell' Artigiano, 8/6
40016 San Giorgio di Piano
(Bologna) ITALY
E-mail: grifo@grifo.it
http://www.grifo.com
Rel. 5.00
®
grifo
®
,
, are trade marks of
Edition 27 October 2004
grifo
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Tele Web and is the answer not in the manual?

Questions and answers

Summary of Contents for Grifo Tele Web

  • Page 1 Tele Web Controller Telecontrol Module through the WEB USER MANUAL Via dell' Artigiano, 8/6 ® grifo 40016 San Giorgio di Piano (Bologna) ITALY E-mail: grifo@grifo.it ITALIAN TECHNOLOGY http://www.grifo.it http://www.grifo.com Tel. +39 051 892.052 (a. r.) FAX: +39 051 893.661 Tele Web Controller Rel.
  • Page 3 Tele Web Controller Telecontrol Module through the WEB USER MANUAL Can be driven through Internet using a normal Web Browser (e. g. Internet Explorer, Netscape, ecc.) from anywhere in the world. Access to all the on-board resouces through Password protected Web pages.
  • Page 4 ® DOCUMENTATION COPYRIGHT BY grifo , ALL RIGHTS RESERVED No part of this document may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, either electronic, mechanical, magnetic, optical, chemical, manual, or ®...
  • Page 5: Table Of Contents

    ® grifo ITALIAN TECHNOLOGY GENERAL INDEX INTRODUCTION ........................1 FIRMWARE VERSION ......................3 GENERAL INFORMATION ...................... 4 INTERNET INTERFACE ...................... 6 OUTPUT SECTION OF ZBR ....................6 OUTPUT SECTION OF ZBT ....................6 INPUT SECTION OF ZBT AND ZBR .................. 6 POWER SUPPLY SECTION ....................
  • Page 6 ® grifo ITALIAN TECHNOLOGY FIGURE INDEX 1: B ......................5 IGURE LOCKS DIAGRAM 2: P ...................... 7 IGURE HOTO OF 3: S ................11 IGURE NAPSHOT OF ICRO ERVER 4: S ZBR 168 ....................11 IGURE NAPSHOT OF 5: M ..............
  • Page 7: Introduction

    To be on good terms with the products, is necessary guarantee legibility and conservation of the manual, also for future references. In case of deterioration or more easily for technical updates, consult the AUTHORIZED TECHNICAL ASSISTANCE directly. Tele Web Controller Rel. 5.00 Page 1...
  • Page 8 After this reading, the user can use the general index and the alphabetical index, respectly at the begining and at the end of the manual, to find information in a faster and more easy way. Tele Web Controller Rel. 5.00 Page 2...
  • Page 9: Firmware Version

    FIRMWARE VERSION The present handbook is reported to the firmware installed on Tele-Web. The firmware name is Tele Web Controller, so this manual describers version 1.0 of Tele Web Controller. In addition, this manual describes the basic version of the firmware, that is the version without the several options like Real Time Clock, data logger, analog inputs, etc.
  • Page 10: General Information

    Here follows a description of the board's functional blocks, with an indication of the operations performed by each one. To easily locate such section on verify their connections please refer to figure Tele Web Controller Rel. 5.00 Page 4...
  • Page 11 (TTL serial line) 4 Lines 2 Lines RS 232 DRIVER protection ±15 kV 8 Lines 23 Lines WORKING MODE SELECTOR (RUN/DEBUG) WIDE RANGE POWER SUPPLY SECTION 2.6 ÷ 20 Vdc 1: B IGURE LOCKS DIAGRAM Tele Web Controller Rel. 5.00 Page 5...
  • Page 12: Internet Interface

    +5 Vdc voltage to supply output and logic sections in every load condition and also generates the +Vopto voltage required by the Input optocouplers. Please refer to ZBx manual for further information. Tele Web Controller Rel. 5.00 Page 6...
  • Page 13 ® grifo ITALIAN TECHNOLOGY 2: P IGURE HOTO OF Tele Web Controller Rel. 5.00 Page 7...
  • Page 14: Technical Features

    0 to 50 centigrad degreeses Relative humidty: 20% up to 90% (without condense) ® (*) For further information, please refer to manual of GPC ordered (**) For further information, please refer to manual of ZBx ordered Tele Web Controller Rel. 5.00 Page 8...
  • Page 15: Electric Features

    ® Analog inputs impedance: optional feature, depends on GPC ordered ® (*) For further information, please refer to manual of GPC ordered (**) For further information, please refer to manual of ZBx ordered Tele Web Controller Rel. 5.00 Page 9...
  • Page 16: Installation

    To supply the structure, it is enough to connect CN2 of ZBx peripheral module to the power supply source. According to the ZBx model and its configuration, power supply source can be quite different. Please refer to ZBx manuals for further information. Tele Web Controller Rel. 5.00 Page 10...
  • Page 17 ® grifo ITALIAN TECHNOLOGY 3: S IGURE NAPSHOT OF ICRO ERVER 4: S ZBR 168 IGURE NAPSHOT OF Tele Web Controller Rel. 5.00 Page 11...
  • Page 18: Software Installation

    Tele-Web includes the complete delivery of Micro Web Server, shown in figure 5. This delivery includes the Micro Web Server development CD and the sources of Tele Web Controler firmware (TWC11.c, TWC11.mak, TWC11.pwp, IP plus all the files with *.htm and *.gif extension).
  • Page 19 ® grifo ITALIAN TECHNOLOGY 5: M IGURE ICRO ERVER COMPLETE DELIVERY Tele Web Controller Rel. 5.00 Page 13...
  • Page 20 Disconnect the plug cable to the PC, reconnect the cable already present before and supply the Tele-Web GPC® Enable configuration mode Enable normal working mode CARD GPC® J1 Open J1 Connected 324D 6: L IGURE OW LEVEL CONFIGURATION Tele Web Controller Rel. 5.00 Page 14...
  • Page 21: Zbx Mapping Address

    Table of correct addresses is: GPC® Base Address JAddr Jumpers group CARD of ZBx GPC® All jumpers connected 324D 7: ZB IGURE X MAPPING ADDRESS ® 8: S 324D IGURE NAPSHOT OF A Tele Web Controller Rel. 5.00 Page 15...
  • Page 22: High Level Configuration

    IP addres is assigned executin the SETIP command in the DOS window or command prompt of a PC connected to the same network of Tele-Web and changing the content of the file called IP in the sources folder of Tele Web Controller. For example, if the free IP obtained is 192.168.168.123, the command to type is: SETIP 0:1:2:3:4:5 192.168.168.123...
  • Page 23: Utilization

    If the password is not typed correctly, the Tele-Web enters in a idle mode for about one minute, during which any command is ignored. This way, illegal access attempts are heavily obstacolated. 9: L IGURE OGIN Tele Web Controller Rel. 5.00 Page 17...
  • Page 24: Output Commands

    When an input is disabled (contact open), it is indicated showing the image stored in the file called “off.gif”. By default, the image shows the writing “OFF”. To modify the images “on.gif” and “off.gif” please refer to paragraph “PERSONALIZATIONS”. Tele Web Controller Rel. 5.00 Page 18...
  • Page 25 ® grifo ITALIAN TECHNOLOGY 10: C IGURE OMMANDS PAGE OF 11: L IGURE ABELS MANAGEMENT Tele Web Controller Rel. 5.00 Page 19...
  • Page 26: Labels Management

    PC. In detail, content of memory can be saved in a Excel compatible format, with cell names decideable by the user. Tele Web Controller Rel. 5.00 Page 20...
  • Page 27 ® grifo ITALIAN TECHNOLOGY 12: C IGURE HANGE SIGNALS NAMES Tele Web Controller Rel. 5.00 Page 21...
  • Page 28: Analog Inputs Management (Optional)

    Shortly, the above mentioned Web page allows to read the inputs, to enable or disable the saving of the inputs to the (optional) ring buffer memory and to save the contente of this memory in a Excel compatible format, with cell names decideable by the user. Tele Web Controller Rel. 5.00 Page 22...
  • Page 29: Personalizations

    Other two files contain several comments that explain how the modules work, allowing to understand and so to change their behaviour. Further information about compiler µC/51 can be found at: http://www.wickenhaeuser.de. Further information about Micro Web Server firmware development system can be found at: http://www.picoweb.net and http://www.achatz.nl. Tele Web Controller Rel. 5.00 Page 23...
  • Page 30: Personalization Of Icons

    In specific, name enclose in back-quotes (for example: `list_lables.cgi`) are required for the project correct working and must never be changed. For further information, please refer to PDF documents pwproj.pdf and pw1_pcode.pdf, in subfolder /docs of Micro Web Server installation folder. Tele Web Controller Rel. 5.00 Page 24...
  • Page 31: Appendix A: Alphabetical Index

    ® grifo ITALIAN TECHNOLOGY APPENDIX A: ALPHABETICAL INDEX SYMBOLS +VOPTO 6 10BASET 10 A/D CONVERTER, OPTIONAL 8 ANALOG INPUTS 9 ANALOG INPUTS MANAGEMENT (OPTIONAL) 22 CLOCK 8 CONNECTORS 8 CPU 8 CURRENT CONSUMPTION 9 DARLINGTON 6 DATA LOGGER MANAGEMENT (OPTIONAL) 20...
  • Page 32 ® grifo ITALIAN TECHNOLOGY LABELS MANAGEMENT 20 LED 6 LOGIN 17 LOW LEVEL CONFIGURATION 12 MICRO WEB SERVER 6, 10 MOV 6 NPN 6, 10 OPEN COLLECTOR 6 OPTOCOUPLERS 6 OUTPUT 6 OUTPUT COMMANDS 18 PASSWORD 12, 14, 17 PERSONALIZATION OF HTML PAGES 24...
  • Page 33 ® grifo ITALIAN TECHNOLOGY TEMPERATURE RANGE 8 TRANSISTOR 6, 8 VERSION 3 WEIGHT 8 ZBR 6, 10, 18 ZBT 6, 10, 18 GMB HR168 & GMM AC0 Rel. 5.00 Page A-3...
  • Page 34 ® grifo ITALIAN TECHNOLOGY GMB HR168 & GMM AC0 Rel. 5.00 Page A-4...
