THERMOSTAT
Owner's Guide
and
Installation Instructions
Domestic Mains Pressure
Electric Boosted Solar Water Heater
SE260 to SE415 Series
Warning: Use copper pipe ONLY. Plastic pipe MUST NOT be used.
It is a requirement of a solar water heater installation that all pipe work be in copper and not plastic, due to
the effects of high water temperatures and pressures.
This solar water heater must be installed and serviced by a qualified person.
Please leave this guide with the householder.
Advertisement
Table of Contents
Related Manuals for Aqua MAX SE260 series
Summary of Contents for Aqua MAX SE260 series
-
Page 1: Installation Instructions
THERMOSTAT Owner’s Guide Installation Instructions Domestic Mains Pressure Electric Boosted Solar Water Heater SE260 to SE415 Series Warning: Use copper pipe ONLY. Plastic pipe MUST NOT be used. It is a requirement of a solar water heater installation that all pipe work be in copper and not plastic, due to the effects of high water temperatures and pressures. - Page 2 Warning: Important notes for plumber. For installation requirements critical for correct operation of the solar water heater, refer to ‘Warning: Important Notes for Plumber’ on page 26.
- Page 3 Warning: Upon completion of the installation and commissioning of the solar water heater, leave this guide with the householder or responsible officer. DO NOT leave this guide inside the cover of the solar control unit or solar storage cylinder, as it may interfere with the safe operation of the solar water heater or ignite when the solar water heater is turned on.
-
Page 4: Table Of Contents
CONTENTS Householder: Read the section ‘About Your Solar Water Heater’ (page 4 to 15). The ‘Installation’ section is intended for the installer but may be of interest. ABOUT YOUR SOLAR WATER HEATER ......................4 Model Type ..............................4 Pipe Work, Insulation & Freeze Protection ....................6 Turning On the Solar Water Heater ....................... -
Page 5: About Your Solar Water Heater
ABOUT YOUR SOLAR WATER HEATER Product Application This solar water heater is designed for use in a single family domestic dwelling for the purpose of heating potable water. Its use in an application other than this may shorten its life. Warning: This solar water heater is only intended to be operated by persons who have the experience or the knowledge and the capabilities to do so. - Page 6 Electric Booster Operation The electric booster is an electric immersion heating unit (element) which is located behind the front access cover of the solar storage cylinder. Water stored in the solar storage cylinder is heated by the electric booster at times of low solar energy (low solar gain), such as during very cloudy or rainy weather, or during the colder months of the year.
-
Page 7: Pipe Work, Insulation & Freeze Protection
Children should be supervised to ensure that they do not play with the appliance. For early childhood centres, primary and secondary schools, nursing homes or similar facilities for young, aged, sick or disabled persons, please consult your local health authority for the correct temperature setting. Pipe Work, Insulation &... -
Page 8: Other Important Information
During periods of low solar energy gain, the water temperature in the solar storage cylinder will be automatically boosted by the thermostatically controlled electric booster (refer to ‘Electric Booster Operation’ on page 5). The booster thermostat setting can be set by a qualified person to a minimum of 60° C and a maximum of 70°... -
Page 9: Periodic Maintenance
How Long Will the Water Heater Last? The solar water heater is supported by a manufacturer’s warranty (refer to page 38). There are a number of factors that will affect the length of service the solar water heater will provide. These include but are not limited to the water chemistry, the water pressure, the water temperature (inlet and outlet) and the water usage pattern. - Page 10 prevailing weather conditions; however, the electric booster will provide a quantity of hot water after a period of 2 ~ 6 hours (boost quantity and time dependent upon solar storage cylinder size). Pressure Temperature Relief Valve (PTR Valve) The PTR valve is near the top of the solar storage cylinder and is essential for safe operation. It is possible for the PTR valve to release a little water through the drain line during each heating period.
- Page 11 Flushing the Solar Collectors It may be necessary to flush the solar collectors if there is sediment in the water supply. It is recommended that the solar collectors are flushed every five years. This will assist in keeping the solar collectors, solar cold pipe and solar hot pipe clear of sediment (refer to ‘Major Five Year Service’...
-
Page 12: Water Chemistry
Change of Water Supply The changing or alternating from one water supply to another can have a detrimental effect on the operation and / or life expectation of the solar storage cylinder and pressure temperature relief valve. Where there is a changeover from one water supply to another, e.g. a rainwater tank supply, bore water supply, desalinated water supply, public reticulated water supply or water brought in from another supply, then water chemistry information should be sought from the supplier or it should be tested to ensure the water supply meets the requirements given in these guidelines for the Aquamax warranty to apply. -
Page 13: Troubleshooting
Total dissolved solids 600 mg/Litre Total hardness 200 mg/Litre Chloride 300 mg/Litre Magnesium 10 mg/Litre 9.5 and not less than 6.5 Calcium 20 mg/Litre Sodium 150 mg/Litre Iron 1 mg/Litre Scaling Water & Saturation Index The saturation index is used as a measure of water’s corrosive or scaling properties. In a corrosive water supply, water can attack copper parts and cause them to fail. - Page 14 If the Solar Monitor green LED is off, or the red LED is flashing, switch off the electrical supply at the power outlet to the solar control unit for five (5) seconds and then switch back on again. If the green LED remains off or the red LED recommences to flash, count the number of flashes and phone Aquamax Service or their nearest Accredited Service Agent to arrange for an inspection.
-
Page 15: Solar Monitor Led Indication
Expansion Control Valve Running If an expansion control valve is fitted in the cold water line to the solar water heater, it may discharge a small quantity of water instead of the solar water heaters pressure temperature relief valve. This has the benefit of conserving energy as the discharged water is cooler (refer to the ‘Cold Water Supply Plumbing Arrangement’... - Page 16 The green LED will emit either a constant glow or a series of flashes, with a 2 second interval between each series. The red LED will emit a series of flashes, with a 2 second interval between each series, only if there is a particular fault condition with the system.
-
Page 17: Installation
INSTALLATION Installation Overview This solar water heater must be installed by a qualified person in accordance with the installation instructions. The installation must comply with the requirements of AS/NZS 3500.4, AS/NZS 3000 and all local codes and regulatory authority requirements. This solar water heater is comprised of the following components: Solar storage cylinder with integral electric booster. -
Page 18: Water Supplies
Hot Water Redundancy If this solar water heater is to be used where an uninterrupted hot water supply is necessary for the application or business, then there should be redundancy within the hot water system design. This should ensure the continuity of hot water supply in the event that this solar water heater was to become inoperable for any reason. -
Page 19: Installation - Components
INSTALLATION – COMPONENTS This section details the installation of the solar storage cylinder, solar controller kit and solar collector kit. To install the plumbing for these components refer to the ‘Installation – Plumbing & Plumbing Connections’ section on page 21. Solar Storage Cylinder Installation Solar Storage Cylinder Location The solar storage cylinder is suitable for either outdoor or indoor installation. -
Page 20: Solar Collector Kit Installation
The solar control unit is mounted on the side of the solar storage cylinder and controls system operation. The solar control unit has a power cord which connects to a 240 volt general purpose outlet (refer to ‘Installation – Electrical & Electrical Connections’ on page 29). The solar control unit incorporates a circulating pump which when energised circulates water from the solar storage cylinder through the collector circuit and back to the solar storage cylinder. - Page 21 Latitude of Some Australian Cities Adelaide 35°S Cairns 17°S Hobart 42°S Port Hedland 20°S Alice Springs 24°S Canberra 35°S Mildura 34°S Rockhampton 24°S Brisbane 27°S Darwin 12°S Melbourne 38°S Sydney 34°S Broken Hill 31°S Geraldton 28°S Perth 32°S Townsville 19°S Refer to the installation instructions supplied with the solar collector kit for details on the installation of the solar collector kit.
-
Page 22: Installation - Plumbing & Plumbing Connections
INSTALLATION – PLUMBING & PLUMBING CONNECTIONS This section details plumbing, plumbing connections and plumbing diagrams for the solar storage cylinder, solar controller kit and solar collector kit. To install these components refer to the ‘Installation – Components’ section on page 18. Solar Storage Cylinder Plumbing &... - Page 23 compliance with Clause 5.9.1 of AS/NZS 3500.4. Due to the high temperatures generated by solar water heaters, an additional effective back-flow prevention device also should be fitted as an extra safeguard. Valve manufacturer RMC recommends Dual Check Valve No N7150, as being suitable for this application. A pressure limiting valve and expansion control valve may also be required (for PLV requirements refer to ‘Water Supplies’...
-
Page 24: Solar Controller Kit Plumbing & Plumbing Connections
Relief Valve Drain(s) DN15 copper drain lines must be fitted to the pressure temperature relief valve and expansion control valve (if one is installed) to carry the discharge clear of the solar water heater. Connect the drain lines to the valves using disconnection unions. -
Page 25: Solar Collector Circuit Plumbing & Plumbing Connections
work from the bleed valve to the drain should be as short as possible and must have continuous fall from the valve to the drain with no restrictions. The drain line must have no more than three right angle bends. The outlet of a drain line must be in such a position that flow out of the pipe can be easily seen, but arranged so that discharge will not cause injury, damage, nuisance or splashing. - Page 26 The maximum recommended total pipe length of the solar circuit should not be exceeded and a minimum water supply pressure of 200 kPa should be available at the inlet to the solar water heater, otherwise system performance may be reduced or the solar circuit may not be purged of air during commissioning of the solar water heater.
- Page 27 WARNING: Important Notes for Plumber The solar hot and solar cold pipe work between the storage cylinder and the solar collectors and the • pipe work between this solar water heater and a temperature limiting device, or this solar water heater and a hot water outlet if a temperature limiting device is not installed MUST BE of copper.
-
Page 28: General Plumbing Arrangement & Plumbing Diagrams
General Plumbing Arrangement & Plumbing Diagrams Two Temperature Zones Using a Temperature Limiting Device This solar water heater can deliver water at temperatures which can cause scalding. It is necessary and we recommend that a temperature limiting device be fitted between the solar water heater and the hot water outlets in any ablution area such as a bathroom or ensuite, to reduce the risk of scalding. - Page 29 Two Temperature Zone Plumbing Diagram – Electric Boosted Solar System Circulated Flow & Return Plumbing Diagram – Electric Boosted Solar System...
-
Page 30: Installation - Electrical & Electrical Connections
INSTALLATION – ELECTRICAL & ELECTRICAL CONNECTIONS Warning: The power supplies to the solar water heater and solar control unit must not be switched on until the solar water heater is filled with water and a satisfactory megger reading is obtained. All electrical work and permanent wiring must be carried out by a qualified person and in accordance with the Wiring Rules AS/NZS 3000 and all local codes and regulatory authority requirements. -
Page 31: Commissioning
Switch off the circuit breaker or isolator marked ‘Hot Water’ or ‘Water Heater’ at the switchboard. This will turn off the electric booster circuit. Remove electrical access cover. Turn thermostat temperature adjustment dial clockwise to increase temperature setting or anticlockwise to decrease temperature setting. - Page 32 Plug in the solar control unit at the power outlet and switch on the electrical supply. Note: The power outlet must be switched on for the solar control unit to operate and for solar gain to be achieved. The solar control unit also provides additional freeze protection when energised. When the electrical supply is switched on to the solar control unit at start up: If there is no solar gain, the circulator will not activate and the •...
-
Page 33: Draining The Solar Collectors
Draining the Solar Collectors To drain the solar collectors and the solar hot and solar cold pipes: Warning: Exercise care when performing the following procedure as water discharged from the solar collectors and solar circuit may be of a very high temperature. Wear personal protective equipment to reduce the risk of scalding. - Page 34 Close the cold water isolation valve at the inlet to the solar storage cylinder. Close all hot water taps in premises. Operate PTR valve lever for a period of five seconds to release pressure in solar storage tank. Note: Operate lever gently and do not let lever snap back or you will damage relief valve seat. Undo union at cold water inlet to solar storage cylinder and attach a hose to solar storage cylinder side of union.
-
Page 35: Dimensions And Technical Data
Dimensions and Technical Data Solar Electric Boosted Solar Water Heater SE415 ~ SE260 Models Model SE415 SE325 SE260 Capacity (L) Empty Weight (kg) Full Dimensions A (mm) 1525 1535 1215 B (mm) C (mm) D (mm) H (mm) 1760 1755 1435 V (mm) Max Supply Pressure... - Page 36 This page is intentionally blank...
- Page 37 This page is intentionally blank...
- Page 38 This page is intentionally blank...
-
Page 39: Warranty
WARRANTY AQUAMAX SOLAR WATER HEATER SE415, SE325 & SE260 THE AQUAMAX WARRANTY – GENERAL This warranty is given by Aquamax Australia Pty Limited ABN 37 138 189 689 of 463-467 Warrigal Road, Moorabbin Victoria. Aquamax offer a trained and qualified service network who will repair or replace components at the address of the water heater subject to the terms of the Aquamax warranty. - Page 40 Subject to any statutory provisions to the contrary, this warranty excludes any and all claims for damage to furniture, carpet, walls, foundations or any other consequential loss either directly or indirectly due to leakage from the water heater, or due to leakage from fittings and/ or pipe work of metal, plastic or other materials caused by water temperature, workmanship or other modes of failure.
- Page 41 INSTALLER INFORMATION DEAR INSTALLER, Please provide the following information upon completion of the installation. This information should be provided to assist the customer in the event that a claim is made under the Aquamax warranty. Plumber (Name & Company): Plumber’s licence number: Compliance Certificate: (if applicable in your state) Installation date:...
