Edwards Signaling 2412 Installation Instructions & Owner's Operation Manual

2400 series fire alarm control panels
Hide thumbs
Table of Contents

Advertisement

Quick Links

Installation Instructions &
Owner's Operation Manual
for Two to Eight Zone
2400 Series
Fire Alarm Control Panels
P/N 46000-1320, Rev. 1.6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2412 and is the answer not in the manual?

Questions and answers

Summary of Contents for Edwards Signaling 2412

  • Page 1: Installation Instructions

    Installation Instructions & Owner’s Operation Manual for Two to Eight Zone 2400 Series Fire Alarm Control Panels P/N 46000-1320, Rev. 1.6...
  • Page 2 © Edwards This product has been designed to meet the requirements of NFPA Standard 72, 1990 Edition; Underwriters Laboratory, Inc., Standard 864, May 2, 1991 Edition; and Underwriters Laboratory of Canada, Inc. Standard ULC S527. Installation in accordance with this manual, applicable codes, and the instructions of the Authority Having Jurisdiction is mandatory.
  • Page 3 FCC Information The dialer complies with Part 68 of the FCC rules. The Dialer’ FCC registration number and the Ringer Equivalence Number (REN) are on the back of the dialer. This information must be provided to the telephone company, if requested. An FCC compliant telephone cord and modular plug cord is supplied with the dialer.
  • Page 4 FOR TECHNICAL ASSISTANCE PLEASE CALL YOUR LOCAL REPRESENTATIVE LISTED ON THE FOLLOWING PAGE. Effectivity Page for P/N 46000-1320, Edwards 2400 Manual Revision Description Initial Release Editorial Corrections Add 2400-ADM, 2400 -ADS, & 2400-RTU Module Information Renamed Table 2.1 to Table 1.1. Add Table 1.2. Correct Cat. # 2245 to 2445.

  • Page 5: Table Of Contents

    Table of Contents 1.0 DESCRIPTION ....................1-4 Components .....................2 2.0 APPLICATION ......................5 Fire Alarm System Limitations................5 3.0 THEORY OF OPERATION ................5-8 Initiating Device Circuits (IDCs)................5 Indicating Appliance Circuits (IACs) ..............8 4.0 INSTALLATION ....................9-15 Codes and Standards..................9 Site Storage......................9 Drawing References..................9 Installation Instructions ...................10 5.0 PROGRAMMING...
  • Page 6 8.0 PREVENTIVE MAINTENANCE ............... 29-32 Preventive Maintenance Schedule ..............29 Testing Procedures for the Dialer Module ............. 31 Testing Procedures for Compatible 2-Wire Smoke Detectors ....... 31 Replacement Parts ..................32 9.0 SPECIFICATIONS ..................33-36 10.0 APPENDICES................37-59 10.1 Appendix 1 - Battery Calculations..............37 Using the Battery Tables ................
  • Page 7 List of Tables, Figures, & Illustrations Table 1.1 Base Panel Capacity................. 2 Table 1.2 2400-RCT Battery Standby Requirements ..........3 Table 3.1 IDC Operation ................... 5 Table 4.1 Drawing References ................. 9 Table 5.1 Programmable Features ................. 16 Table 5.2 Programming Step Indications ..............
  • Page 8 Table 10.11 ULC Device & Panel Compatibility - Initiating Devices......50 Table 10.12 ULC Compatible Signaling Appliances ........... 51 Table 10.13 ULC Compatible Accessories ..............51 Table 10.14 Mixed Ion/Photo Detector Maximum Devices per Circuit......52 Figure 3.1 Unsustained Alarm Operation ..............7 Figure 3.2 Verified Alarm Operation................

  • Page 9: Description

    Eight Zone, Six Expansion Space Panel, Cat. # 2418(R) 1.0 DESCRIPTION The 2412, 2414, & 2418 Fire Alarm Control Panels are protective signaling systems which feature modular construction and installer programmable microprocessor technology. m Panel Supervisory Features include: continuous internal testing; a CPU watchdog timer; and module placement supervision.

  • Page 10: Components

    1.1 Components 2412 Two Zone Base Panel w/3 Option Module Expansion Spaces, Gray Enclosure (Cat.# 2412) Two Zone Base Panel w/3 Option Module Expansion Spaces, Red Enclosure (Cat.# 2412-R) This panel provides two Class B (Style B) Initiating Device Circuits (IDCs) and two Class B (Style Y) Indicating Appliance Circuits (IACs).

  • Page 11: Table 1.2 2400-Rct Battery Standby Requirements

    Relay contacts are rated for 24 VDC @ 1A. The module has a disconnect switch and an amber Trouble LED. The module requires one option module expansion space. Off premise power failure trouble signaling using this module has a 6 hour delay. Table 1.2 - 2400-RCT Battery Standby Requirements Feature 2412 2414 2418 Dialer Up to 60 Hrs.
  • Page 12 2400-ADS Four Circuit Annunciator Driver Slave Module (P/N 240463) The Four Circuit Remote Annunciator Driver Slave Module is used to supervise and operate the connection to four additional alarm zone LEDs on a conventional zone annunciator. The -ADS is automatically configured for IDC zones 5 to 8. The Remote Annunciator Driver Slave Module mounts on the 2400-ADM Master, module and does NOT require any expansion module space.

  • Page 13: Application

    2.0 APPLICATION The 2412, 2414, and 2418 panels are suitable for small to medium size buildings, requiring from two to eight Initiating Device Circuits (IDCs), and two Indicating Appliance Circuits (IACs). 2.1 Fire Alarm System Limitations Fire Alarm Systems provide the occupants of a facility with early warning of smoke and fire conditions. Fire alarm systems use a variety of components to meet the requirements of each installation.
  • Page 14 When an IDC is programmed as a waterflow zone, the IACs DO NOT respond to the ALARM SILENCE switch or automatic alarm silence until the waterflow device is no longer active. Both an alarm initiating device and a supervisory contact may co-exist on the same circuit by putting a 1.1K Ω in series with the supervisory contact.
  • Page 15 Figure 3.1 - Unsustained Alarm Operation Figure 3.2 - Verified Alarm Operation...

  • Page 16: Indicating Appliance Circuits (Iacs)

    3.2 Indicating Appliance Circuits (IACs) Two supervised Indicating Appliance Circuits (IACs) operate using compatible 24 VDC (nominal) polarized signaling appliances. Each circuit is rated at nominal 24 VDC @ 2.5 Amps, with a total of 4.0 Amps available for both circuits. An IAC may be programmed as either silenceable or non-silenceable. Signal rate selection is independently programmable for each IAC as shown in Figure 3.3.

  • Page 17: Installation

    4.0 INSTALLATION 4.1 Codes and Standards Install this panel in accordance with all applicable codes and standards to the satisfaction of the Authority Having Jurisdiction (AHJ). A partial list of codes and standards appears in the Appendix. US Installations: For Class B (Style B/Y) circuits, the End-Of-Line resistor is installed on the last device. Canadian Installations: For Class B (Style B/Y) circuits, purchase End-Of-Line resistor plates separately from your Distributor.

  • Page 18: Installation Instructions

    4.4 Installation Instructions Mounting the Backbox Install backbox per drawings Control Panel INSTALLATION 1 and Control Panel INSTALLATION 2. If a 2400- BATBOX Battery Cabinet is required, refer to the CONTROL PANEL APPLICATIONS 2 drawing for information. Utility or Primary Power Circuit NOTE Install primary power conduit on lower left side or left bottom of backbox.
  • Page 19 Base Panel Assembly CAUTION The electronic components used in this system are sensitive to static electricity. Always discharge any static buildup on your body by touching the panel enclosure before handling any electronic components. WARNING The System Power Supply (the printed circuit board on the back of the Base Panel Assembly) handles 170 VDC when powered.
  • Page 20 1. Refer to the CONTROL PANEL INSTALLATION 1 or CONTROL PANEL INSTALLATION 2 drawings. If a 2400-BATBOX Battery Cabinet is required, refer to the CONTROL PANEL APPLICATIONS 2 drawing for information. 2. Lift wiring up and away from the backbox, and install the Base Panel Assembly using the four quick fasteners.
  • Page 21 3. Fill-in the Panel Configuration & Programming Worksheets (located in the Appendix) and program the panel for the desired operation. Save the Panel Configuration Worksheets for future reference. 4. Remove, label, and re-insert the IDC, Relay/City-Tie, and Anunciator Driver Module insert cards. Use the Panel Configuration Worksheets in this manual to assist in labeling.
  • Page 22 The telephone jacks must be installed by an authorized representative of the telephone company. Phone lines must be loop start on the public switched network. PBX, ground start, and party lines are not acceptable 5. Using the supplied 7Ft. (2.13 M) phone jack extension cables, connect J1 & J2 to the RJ31X, or RJ38X (CA31A or CA38A in Canada) telephone jacks.

  • Page 23: Installation

    2400-ADM & 2400-ADS Field Wiring Connections 1. Refer to the REMOTE ANUNCIATOR drawing for wiring details. 2. Dress all wires to allow "hinging" the Base Panel Assembly on the left by dressing your connections from right to left. This allows you to rotate the Base Panel Assembly out of the enclosure for access to system modules, facilitating additions or changes.

  • Page 24: Programming

    5.0 PROGRAMMING Panel Configuration Worksheets may be found at the end of this manual. These worksheets should be filled out prior to programming the panel, and saved with this manual should further programming be required at a later date. Refer to the PANEL PROGRAMMING drawing during the programming process. The reverse side of the base panel identification labels are programming templates.

  • Page 25: Programming Initiating Device Circuits (Idcs)

    Table 5.2 - Programming Step Indications Program Step Power LED Flash Phase Module Placement & Verification PAUSE PAUSE Initiating Device Circuits (IDC) PAUSE PAUSE Indicating Appliance Circuits (IAC) PAUSE PAUSE YYYY YYYY YYYY Timer Settings PAUSE PAUSE YYYYY YYYYY YYYYY Auxiliary Power Setting PAUSE PAUSE...

  • Page 26: Programming Indicating Appliance Circuits (Iacs)

    2. Use the switch to step through the various IDC zone types, until the desired IDC TROUBLE SILENCE type code is displayed by the LEDs. 3. Select the IAC circuit to be operated by this zone by pressing the switch until the ALARM SILENCE desired configuration is reached.

  • Page 27: Configuring System Timers

    5.3 Configuring System Timers 1. The configure System Timers step is indicated by the 4-phase flashing green Power LED. The status of the panel’s Alarm Silence Inhibit Timer is indicated by the zone disabled LED as shown in Table 5.6. Table 5.6 - Alarm Silence Inhibit Timer Status Alarm Silence Inhibit Timer Setting Zone Disabled LED...

  • Page 28: Returning To Panel Default Settings

    5.5 Returning to Panel Default Settings To restore the panel to system default settings, before exiting the programming mode, press the TROUBLE switches simultaneously for one second. This will return all parameters to default SILENCE RESET settings (Table 5.1), and return the panel to the beginning of the programming sequence. 5.6 Dialer Module Programming Refer to the drawing...
  • Page 29 Enter the daily supervisory message delay time. The module sends a supervisory message to the CMS once every 24 hours to verify the communications path and message receipt. The delay is used to set the time the daily message is transmitted based on a delay from the time the panel is powered EXAMPLE: If the CMS requires the daily supervisory message to be sent at 0300 (3 AM) and the current time is 1400 (2 PM), set the delay for 13 hours, power down, then power up.

  • Page 30: Operation

    6.0 OPERATION Table 6.1 - Panel Indicators Indicator Function Zone Disabled LED PAUSE PAUSE ... - One or more zones disabled PAUSE PAUSE ... - Audible test mode YYYY YYYY YYYY PAUSE PAUSE ... - Silent test mode Power LED ON - AC power normal OFF - AC power fail Zone Alarm (Red) LED...

  • Page 31: Reset Mode

    Reset Mode When the facility is safe to re-enter, the panel may be Reset. Manual stations and other manually restorable devices must be returned to their normal condition. Non-restorable devices which have been activated by the fire must be replaced. In the event replacement is not immediately feasible, disable the affected zone using its disable switch.

  • Page 32: Supervisory Mode

    Supervisory Mode When the panel is in the Supervisory Mode, a portion of the building fire protection system (not the panel) is in an abnormal condition and its proper operation is affected. If an alarm occurs while in the supervisory mode, the panel will enter the alarm mode and sound an alarm.

  • Page 33: Test Mode

    Test Mode The Test Mode is used to verify the operation of the panel, alarm initiating devices, and the integrity of field wiring. WARNING Fire detection capability on the zone(s) under test is NOT functional in the Test Mode. The panel will leave the test mode, enter the alarm mode, and sound an alarm if a zone not selected for testing detects an alarm.

  • Page 34: Dialer Module

    NOTE When verifying the operation of strobe lights using the Test Mode, the strobe lights may not receive enough energy to successfully charge. Use independent test methods such as Drill Mode to verify strobe lights and field wiring. NOTE Before exiting Test Mode, be sure to Enable the zone(s) that were Disabled for testing. CAUTION If there is no activity on the system for 30 minutes, the system will exit the Test Mode and the Disabled zone(s) will remain Disabled.

  • Page 35: Troubleshooting

    7.0 TROUBLESHOOTING CAUTION Disconnect AC and battery power before installing or removing modules. WARNING Lethal voltages from other equipment may be present within the panel even with the alarm system AC power source disconnected. Table 7.1 - Trouble LEDs Condition Possible Cause 3 or 4-Phase flashing Amber ZONE DISABLED LED 1.

  • Page 36: Dialer Module

    Table 7.3 - Dialer Module LED Trouble Codes Condition Possible Cause Trouble 1. Retry count exceeded, unable to communicate. (› PAUSE › PAUSE ›...AMBER) 2. Phone line open or shorted. Disabled 1. Disable switch activated. (›› PAUSE ›› PAUSE ››... AMBER) (dialer will automatically re-enable in 24 Hrs.

  • Page 37: Preventive Maintenance

    8.0 PREVENTIVE MAINTENANCE Before commencing testing, notify all areas where the alarm sounds and off premise locations that receive alarm and trouble transmissions that testing is in progress. m Records of all testing and maintenance shall be kept on the protected premises for a period of at least five (5) years.
  • Page 38 Table 8.1 - Preventive Maintenance Schedule (Continued) Component Testing Test Procedure Interval Supervisory Semi-annually 1. Put zone in test mode Signal Initiating 2. Operate valve Devices 3. Test pressure, temperature, and water level sensors per the sprinkler system test procedure Remote Annually 1.

  • Page 39: Testing Procedures For The Dialer Module

    8.2 Testing Procedures for the DL1 Dialer Module Every Six months (or as required by the Authority Having Jurisdiction): • Verify that the dialer module is connected to two separate phone lines. • Activate an alarm initiating device and verify the alarm is received at the Central Monitoring Station (CMS).

  • Page 40: Replacement Parts

    ULC Listed End-Of-Line Resistor on 1-Gang Plate 46229-0107 4.7KΩ UL Listed End-Of-Line Resistor 46097-0110 Battery Cabinet 8 Amp Fuse 46063-1065 2412 Replacement Door 46063-1066 2412-R Red Replacement Door 46063-1067 2414 Replacement Door 46063-1068 2414-R Red Replacement Door 46063-1069 2418 Replacement Door 46063-1070...

  • Page 41: Specifications

    9.0 SPECIFICATIONS Table 9.1 - Specifications Base Panel Assemblies Dimensions (HWD) 2412 & 2414 Panels Back box 12" x 14" x 2.75" [30.5 cm x 35.6 cm x 7.0 cm] Finished 14" x 15.75" x 1.125" [35.6 cm x 40.0 cm x 2.9 cm]...
  • Page 42 Table 9.1 - Specifications Base Panel Assemblies Environment Relative Humidity 85% @ 86°F (30°C) Operating Temperature 32°F to 120°F (0°C to 49°C) Table 9.2 - Specifications 2400-BPA Base Panel Class A (Style D/Z) Converter Module (P/N 46199-1072) Expansion Space None IDC Wiring Converts two Style B Circuits into two Style D Circuits IAC Wiring...
  • Page 43 Table 9.6 - Specifications 2400-ADM Annunciator Driver Master Module (P/N 240461) Expansion Space Circuit Rating 30 V @ 15 mA Max. Weight 0.4 lbs (0.18 Kg) Table 9.7 - Specifications 2400-ADS Annunciator Driver Slave Module (P/N 240463) Expansion Space Circuit Rating 30 V @ 15 mA Max.

  • Page 44: Specifications

    Table 9.10- Specifications DL1 Dialer Module Expansion Space Phone Line: Two Loop Start lines on Public switched telephone network, Pulse or DTMF dialing. Wall Connector Standard RJ-31X jack Line Supervision Trouble when line voltage < 10 V & line current < 5 Communications Protocol SIA pulse format P3, 20 PPS, 4/2, double round, 1400 Hz handshake,...

  • Page 45: Appendices

    10.0 APPENDICES 10.1 Appendix 1 - Battery Calculations 10.1.1 Battery Tables Maximum battery size is 8.0 AH. Maximum battery size with optional 2400-BATBOX(R) Battery Cabinet is 10 AH. Refer to Replacement Parts Section for part numbers. The battery tables allow quick battery selection. Three battery tables are provided for the three most common Supervisory and Alarm Time combinations.

  • Page 46: Table 10.2 60 Hours Supervisory, 5 Minutes Of Alarm

    Table 10.2 - 60 Hours Supervisory, 5 Minutes of Alarm Signal Circuit Alarm Current for 5 Minutes Aux. Circuit Current: 0-0.5 Amps for 5 Minutes Panel Current Load Signal Circuit Alarm Current (A) Aux. Sup Current Zones Option Modules 0 mA Amp/Hour Battery Size “...

  • Page 47: Table 10.3 24 Hours Supervisory, 30 Minutes Of Alarm

    Table 10.3 - 24 Hours Supervisory, 30 Minutes of Alarm Signal Circuit Current for 30 Minutes Aux. Circuit Current: 0-0.5 Amps for 30 Minutes Panel Current Load Signal Circuit Alarm Current (A) Aux. Sup Current Option Modules 0 mA Amp/Hour Battery Size “...

  • Page 48: Using The Battery Tables

    Using the Battery Tables Having selected the proper table, you must know the number of option modules installed in the panel, any auxiliary current required, and when using Tables 10.2 and 10.3, the signal current required. Option modules are 2400-2IDC Two Zone Initiating Device Circuit Modules, 2400-RCT Relay/City-Tie Modules, and 2400-ADM Annunciator Driver Master Modules.

  • Page 49: Example #1

    Battery Calculation Example #1 A panel with one (1) option module is to be installed in accordance with the Canadian National Building Code (NBC) requirement of 24 hours standby, 30 minutes alarm. The IAC requires 2.5 Amps, and there is no auxiliary power used.

  • Page 50: Example #2

    Battery Calculation Example #2 A two zone panel with two (2) option modules requires 24 hours of standby, 5 minutes of alarm. The IAC requires 2.5 Amps. The 4-wire smoke detectors require 25 mA of auxiliary power. Calculate the minimum battery capacity that will meet these requirements.

  • Page 51: Battery Calculation Worksheets

    10.1.2 Battery Calculation Worksheets If the panel parameters exceed the values in the battery calculation tables, or if detailed battery calculations are required, the battery calculation worksheets should be used. 1. Enter the quantity of each module installed in the "Quantity" column, next to the appropriate module description.

  • Page 52: Example #3

    Battery Calculation Example #3 A panel with two (2) Two Zone Initiating Device Circuit Modules requires 24 hours standby, 5 minutes alarm. The Indicating Appliance Circuit requires 2.5 Amps. The remote trouble unit to be installed with the panel requires 15 mA in the Supervisory mode and 15 mA in the Alarm mode. Calculate the minimum required battery capacity that will meet these requirements.

  • Page 53: Example #4

    Battery Calculation Example #4 A panel with a Two Zone Initiating Device Circuit Module is to be installed in accordance with the Canadian National Building Code (NBC) requirement of 24 hours standby, 30 minutes alarm. The Indicating Appliance Circuit requires 2.5 Amps, and there is no auxiliary power used. Calculate the minimum required battery capacity that will meet these requirements.

  • Page 54: Appendix 2 - Compatible Devices

    Standby Ripple Maximum Standby Detector Load Detector Voltage @ Voltage Compatibility ID Detector Style B Style D 2412 17.85 -26.4 VDC 400 mV 2.5 mA @ 22.3 VDC 4.7KΩ 2 zone-3 space P/N 46299-0107 panel 2414 17.85 -26.4 VDC 400 mV 2.5 mA @ 22.3 VDC...

  • Page 55: Table 10.6 Uli Device & Panel Compatibility - Initiating Devices

    Table 10.6 - ULI Device & Panel Compatibility - Initiating Devices Cat. # Description UL Identifier Max. # Devices Options per IDC Zone 2420 Ionization Smoke Detector c/w Base 2430 Photoelectric Smoke Detector c/w Base 2432B Photoelectric Smoke Detector c/w Base 2435P Duct Housing w/Photoelectric Detector 6424...
  • Page 56 Table 10.8 - ULI Compatible Accessories Cat. Number Description *MR-101/C 1-SPDT Relay w/LED *MR-101/T 1-SPDT Relay w/LED *MR-104/C 4-SPDT Relay w/LEDs *MR-104/T 4-SPDT Relay w/LEDs *MR-201/C 1-DPDT Relay w/LED *MR-201/T 1-DPDT Relay w/LED *MR-204/C 4-DPDT Relay w/LEDs *MR-204/T 4-DPDT Relay w/LEDs PAM-1 1-SPDT w/LED, Adhesive Mt.

  • Page 57: Ulc Compatibility Listings

    Standby Ripple Maximum Standby Detector Load Detector Voltage @ Voltage Compatibility ID Detector Style B Style D 2412 17.85 -26.4 VDC 400 mV 2.5 mA @ 22.3 VDC 4.7KΩ 2 zone-3 space P/N EOL-P1 panel 2414 17.85 -26.4 VDC 400 mV 2.5 mA @ 22.3 VDC...
  • Page 58 Table 10.11 - ULC Device & Panel Compatibility - Initiating Devices Cat. # Description Max. # Devices Options Identifier per IDC Zone 291C 135ºF (57ºC) Heat Detector 292C 197ºF (92ºC) Heat Detector 293C 135ºF (57ºC) Heat Detector 294C 197ºF (92ºC) Heat Detector 5956A Fire Alarm Indicator - LED 6249C...
  • Page 59 Table 10.12 - ULC Compatible Signaling Appliances Cat.# Description Cat.# Description 2440S-15-R Strobe, Red 2452HS-15/75-R Strobe/Horn, Red 2441S-15-R Strobe, Red 2452HS-15/75-W Strobe/Horn, White 2440S-15-W Strobe, White 2452HS-110-R Strobe/Horn, Red 2441S-15-W Strobe, White 2452HS-110-W Strobe/Horn, White 2440S-30-R Strobe, Red 2453BSA-30-R Bell/Strobe Adapter 2441S-30-R Strobe, Red 2453BSA-15/75-R...
  • Page 60 Table 10.14 Mixed Ion/Photo Detector Maximum Devices per Circuit Refer to Compatibility Tables 10.4 & 10.8 ION Detectors PHOTO Detectors...

  • Page 61: Appendix 3 - Glossary

    10.3 Appendix 3 - Glossary Alarm Silence/Reset Inhibit Timer - A panel option which prevents silencing Indicating Appliance Circuits or resetting the panel for a programmed period after the last alarm. Alarm Silence Timer - A panel option which automatically silences the Indicating Appliance Circuits (IACs) after a programmed time limit after the last alarm.
  • Page 62 Non-Silenceable - An indicating appliance circuit (IAC) which remains active after initiation, independent of the alarm silence features. One-Man Test - Maintenance mode to test initiating and indicating circuits. Creating an alarm on the Initiating Device Circuit (IDC) under test causes both Indicating Appliance Circuit (IAC) to pulse out the zone number of the zone under test (i.e., three rings for zone 3).

  • Page 63: Appendix 4 - Standards Relevant To The Installation Of This Product

    10.4 Appendix 4 - Standards Relevant to the Installation of this Product National Fire Protection Association Underwriter Laboratories of Canada (ULC) (NFPA) 7 Crouse Road 1 Batterymarch Park Scarborough, Ontario M1R 3A9 PO Box 9101 ULC S527, Standard for Control Units For Fire Quincy, MA 02269-9101 Alarm Systems NFPA 70, National Electric Code...

  • Page 64: Appendix 5 - Fire Alarm Trouble & Maintenance Log

    10.5 Appendix 5 - Fire Alarm Trouble & Maintenance Log Date Time Event Initial...
  • Page 66 Panel Configuration and Programming Worksheet Page 2 of 3 Project Name: _______________________________ IAC Programming Worksheet IAC Programming IAC #1 IAC #2 Class B Class A Silenceable (Signal Trouble Circuit #2 LED ON AND Alarm Silenced LED = PAUSE PAUSE ...) Non-Silenceable (Signal Trouble Circuit #2 LED ON AND Alarm Silenced LED OFF) Continuous...
  • Page 67 Panel Configuration and Programming Worksheet Page 3 of 3 Project Name: _______________________________ Description Quantity Supervisory Total Supervisory Alarm Total (mA) (mA) Alarm Base Panel 2 Zone input module Relay Modules Style D IDC Converter Dialer Annunciator Master Remote Trouble Unit Auxiliary Power (mA) Number of Detectors 0.050...
  • Page 68 CONTROL PANEL DIMENSIONS CONTROL PANEL ASSEMBLY BATTERY CONNECTION TOP VIEW TOP VIEW FINISHED WALL (SURFACE MOUNT) BLACK COVER FINISHED WALL TO CONTROL PANEL 1"(2.54 cm) (FLUSH MOUNT) 15.75"(40.0 cm) POWER SUPPLY FRONT VIEW C A R D N D E R ALL KNOCKOUTS E X P A E R T E R...
  • Page 69 CONTROL PANEL DIMENSIONS CONTROL PANEL ASSEMBLY TOP VIEW FINISHED WALL (SURFACE MOUNT) COVER FINISHED WALL (FLUSH MOUNT) 22"(55.9 cm) C A R D IN S E R FRONT VIEW N D E R E X P A E R T E R C O N V M O D U ALL KNOCKOUTS...
  • Page 70 4.7K EOL RESISTOR NOTES REFER TO TYPICAL INDICATING APPLIANCE P/N 46229-0107 POWER LIMITED INDICATING 0R EOL-P1 APPLIANCE SUPERVISED REFER TO CIRCUIT WIRING INITIATING DETAILS SHOWN IN NORMAL CONDITION. CIRCUIT #1 DEVICE MAX.OUTPUT POWER LIMITED. (USE AUX. POWER CIRCUIT WIRING BOTH CIRCUITS OR LISTED FIRE PROTECTIVE = 4.0 A.
  • Page 71 MANUAL PULL COMPATIBLE SMOKE HEAT 4.7K EOL RESISTOR MANUAL PULL COMPATIBLE SMOKE HEAT STATION DETECTOR DETECTOR P/N 46229-0107 STATION DETECTOR DETECTOR 0R EOL-P1 STYLE D/Z CONVERTER CAT. NO. 2400-BPA ADDITIONAL CIRCUITS WIRED SAME AS INP1. ADDITIONAL CIRCUITS WIRED SAME AS INP1. STYLE D IDC CONVERTER CAT.
  • Page 72 LOCAL ENERGY SHUNT CONNECTION/ MASTER BOX DRY CONTACT MASTER BOX WIRE JUMPER NC/O NC/O MUNICIPAL CIRCUIT 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 SET JUMPERS 1-5 AS SHOWN SET JUMPERS 1-5 AS SHOWN NOTES NOTES 1.
  • Page 73 INSTALLATION STEP 1 PROGRAMMING ITEM 08 - AC FAILURE DELAY LED LEGEND INSTALL DIALER MODULE IN PANEL. SEE PANEL INSTALLATION DRAWING. 0 - 18 HOURS ARE VALID ENTRIES LED OFF (DEFAULT = 0) SLOW FLASH INSTALL BUS INTERFACE BOARD ON BACK OF DIALER MODULE. AMBER ON STEADY RAPID FLASH...
  • Page 74 NOTES 1. IF USING 4-WIRE SMOKE DETECTOR, CONFIGURE AUXILIARY POWER AS NON-RESETTABLE. 2. REFER TO BATTERY CALCULATION SECTION FOR NC NO POWER REQUIREMENTS. 3. ALL WIRING POWER LIMITED. CONTACTS SHOWN IN NORMAL CONDITION. POSITIVE ANNUNCIATOR POWER WIRING: 18 AWG MIN.=7,500’ (2,300 M) MAX. 22 AWG MIN.=3,000’...
  • Page 75 MR-101 (MR-104) MR-201 (MR-204) SPDT CONTACTS DPDT CONTACTS 10 AMPS @ 10 AMPS @ 115 VAC 115 VAC DOOR HOLDERS EDWARDS ULI LISTED 1500 SERIES DOOR HOLDERS 24 VAC @ .11 AMPS (9 DEVICES MAX.) TROUBLE ALARM SIG1 SIG2 INP1 INP2 TROUBLE ALARM...
  • Page 76 BATTERY CABINET DIMENSIONS EOL RELAY P/N 6254A-003 TOP VIEW MOUNTED IN A 4" SQ. BOX FINISHED WALL 6251B-003 BASE (U.S.) WITH 1 GANG PLASTER RING. (SURFACE MOUNT) 6251C-003 BASE (CAN.) COVER FINISHED WALL (FLUSH MOUNT) 22"(55.9 cm) 24 VDC RELAY SHOWN IN ALL KNOCKOUTS 24 VDC ENERGIZED STATE...
  • Page 77 PROGRAMMING TEMPLATE ON STEP 1 REVERSE SIDE OF FRONT PANEL INSERT MODE STEP 4 SET PROGRAM MODE SWITCH TO ON. TROUBLE SIGNAL BEEPS. POWER LED DISPLAYS 4- PHASE FLASH (CONFIGURE TIMERS). PRESS RESET SELECT ALARM SILENCE INHIBIT TIMER. ZONE DISABLED LED INDICATES TIMER SETTING.
  • Page 78 SYSTEM TROUBLE SUPERVISORY CONDITION ALARM SILENCE POWER AC VOLTS POWER SYSTEM TROUBLE ALARM ALARM SILENCE SILENCE POWER AC VOLTS ALARM ALARM SILENCED SILENCED IDC ZONE LED AC VOLTS SYSTEM ACTIVE FIRE ALARM PANEL TROUBLE ZONE DISCONNECT ZONE SYSTEM RESET DISABLED AMBER ALARM RESET...
  • Page 79 DISCONNECT MODULE SWITCH ENABLE DISABLE DIALER INSTALLED IN PANEL AUTOMATIC GREEN DIALING SENT CENTRAL MONITORING FIRE STATION ALARM FIRE ALARM SENT & ACKNOWLEDGED SENT CENTRAL MONITORING SUPV. STATION ALARM AMBER SUPERVISORY ALARM SENT & ACKNOWLEDGED SENT CENTRAL MONITORING SUPV. STATION AMBER RESTORE SUPERVISORY RESTORE SENT &...
