Summary of Contents for DAGE-MTI HR120
- Page 1 User’s Manual DAGE-MTI HR120 DAGE-MTI HR120 Monochrome Monitor...
- Page 2 Purchaser’s Record Model Name: DAGE-MTI HR120 Serial Number: Dealer’s Name: Dealer’s Address: Dealer’s Phone Number: Date Purchased: P.O. Number:...
-
Page 3: Installation
Installation The HR120 is equipped with rubber feet and may be installed on any horizontal surface such as a desk, bench, or table. Connection of the monitor to the video source is with... -
Page 4: Front Panel Operation
Front Panel Operation DAGE-MTI HR120 Figure 1: HR120 Front Panel Power Switch This push-button switch turns the monitor on and off. To turn the monitor on, push the switch button. The green LED above the switch lights to indicate that the monitor is on. -
Page 5: Vertical Hold
Vertical Hold This control permits the adjustment of vertical stability. If the monitor picture is “rolling” up or down, adjust the control for a stable picture. VERTICAL HOLD Brightness This control adjusts the overall brightness of the picture. Adjust the control for optimum darkness in BRIGHTNESS the blackest portion of the picture. -
Page 6: Rear Panel Operation
VIDEO IMPEDANCE V-LINEAR V-SIZE FOCUS SUB-BRIGHT 75Ω⇔Hi Figure 2: HR120 Rear Panel Power The AC input power cord accepts voltages in the range of 108 to 132VAC, 60Hz. If the monitor is going to be used with 220VAC, an auto transformer must be used in order to step down the 220VAC supply to 120VAC. - Page 7 switch provides convenient selection IMPEDIANCE of a 75Ω termination when the video signal only goes to the monitor, or when the monitor is the last video component attached to the video line. When the video signal is looping through the monitor, the switch must be set in the position and the last video component must be terminated into 75Ω.
-
Page 8: Specifications
Specifications: Viewing Area: 93.5 in Resolution: >800 TVL Scan Rate: RS-170 & CCIR Input Signal: Composite 1Vpp into 75Ω term. Input/Output Connector: BNC Input Voltage: 108VAC to 132VAC Input Power: 19 Watts Operating Temp: 0°C to +40°C Dimensions: Height: 12½” Width: 12”... -
Page 9: Troubleshooting
Troubleshooting No Picture (Check or try the following) 1. Monitor Power On? a. Power cord attached to live AC source? b. Power switch on? c. Power LED on monitor front on? 2. Correct Signal to Monitor? a. Camera or video source connected correctly? b. -
Page 10: Warranty
Warranty is warranted to be free of defects DAGE-MTI HR120 in material and workmanship in normal use for a period of one year from the original date of purchase from DAGE-MTI. This warranty does not apply to units which have been subject to abuse, neglect, accident, improper installation, or on which the serial number has been removed or damaged. - Page 11 1. This warranty is valid only if the malfunctioning unit is returned to service depot, This warranty does DAGE-MTI not cover on-location service. If warranty work is needed, the following should be contacted: DAGE-MTI, INC. Customer Service 701 N. Roeske Ave. Michigan City, IN 46360 (219) 872-5514 Fax: (219) 872-5559 service@dagemti.com...
- Page 12 DAGE-MTI Inc. 701 N. Roeske Ave. Michigan City, IN 46360 (219) 872-5514 Fax: (219) 872-5559 E-mail: dage@dagemti.com http://www.dagemti.com 970210-02 8/6/02...
