FS24X QuadBand Triple IR

Multi-Spectrum Infrared Electro-Optical Multi-Spectral Digital WideBand IR

Sensor

Radiant Energy Fire and Flame Detector

FSX

Fire and Flame Detectors

MODEL FS24X

Installation Guide

and

Operating Manual

____________________________________________________________________________________________________________________

Fire Sentry Corporation

Document No. 6178-001 - Rev. Q

Table of Contents

Need help?

Do you have a question about the FS24X QuadBand Triple IR and is the answer not in the manual?

Questions and answers

Summary of Contents for Fire Sentry FS24X QuadBand Triple IR

Page 1: Installation Guide
Telephone: 714-694-2700 23311 La Palma Avenue Tel.: 714-671-1100 Fax: 714-694-2701 Yorba Linda, California 92887 www.firesentry.com FS24X QuadBand Triple IR Multi-Spectrum Infrared Electro-Optical Multi-Spectral Digital WideBand IR Sensor Radiant Energy Fire and Flame Detector Fire and Flame Detectors MODEL FS24X Installation Guide...
Page 2 Sentry, COP-i, Complete Optical Path Integrity, CM1, CM1-A, DartLogic, FireLogic, Fire Signature Analysis, FireBusI, FireBusII, FirePic, FirePicII, FirePicIII, FirePix, FirePicture, FSC, Fire Sentry Corporation, Fire Sentry Corp., FSX, All FSX Nomenclature Variations (such as: FS2, FS2X, FS2X, FS3, FS3X, FS3X, FS4, FS4X, FS4X, FS5, FS5X, FS5X, FS6, FS6X, FS6X, FS7, FS7X,...
Page 3: Table Of Contents
™ Model FS24X Fire and Flame Detectors INSTALLATION GUIDE and OPERATING MANUAL TABLE OF CONTENTS PAGE SECTION 1: INTRODUCTION ........................... 1 Product Overview ............................1 Detector Technical Specifications ........................2 1.2.1 Mechanical Specifications ........................2 1.2.2 Electrical Specifications ........................2 1.2.3...
Page 4: Section 1: Introduction
The WideBand IR spectral radiant energy wavelengths sensed by the Quad (4) sensors span from approximately 0.4 to 7.0 microns for the FS24X. The Model FS24X Multi-Spectrum Fire and Flame Detectors are designed and Factory Mutual approved for use in Class , Div.
Page 5: Detector Technical Specifications
(128 choices).  Factory Use 3. The ten (10) position Rotary switch allows selection of the analog and digital communication protocol. Figure 1-3 FS24X and FS24X-9 Detector Puck, ( rear view Detector Technical Specifications 1.2.1 Mechanical Specifications Enclosure Material: Copper Free Aluminum...
Page 6: Performance Specifications
INSTALLATION GUIDE and OPERATING MANUAL Storage Temperature: -67° F to +221° F (-55° C to +105° C) 1.2.4 Performance Specifications Field of View: FS24X: 110° Horizontal and Vertical ( conical FS24X-9: 90° Horizontal and Vertical ( conical Sensitivity: One (1) sq. ft. heptane reference fire at 200 feet...
Page 7: Features & Benefits
 FSC Windows® based PC Interface User can perform remote FSX Detector diagnostics, real-time status, Real-Time Graphing (RTG), SnapShot data recording, and downloading FirePic’s with Fire Sentry’s exclusive FSIM-2 USB ® Interface Unit and easy to use Windows based PC Software.
Page 8: Section 2: Installation
™ Model FS24X Fire and Flame Detectors INSTALLATION GUIDE and OPERATING MANUAL SECTION 2: INSTALLATION Mounting Instructions Consider the following guidelines when selecting Detector location: 1. As with all flame and fire Detectors, avoid areas that contain radiant energy sources (such as radiant heaters, high intensity lamps, flare-stacks, etc.) in close proximity to the Detector’s field of view.
Page 9: Opening The Detector
™ Model FS24X Fire and Flame Detectors INSTALLATION GUIDE and OPERATING MANUAL Mounting Instructions ( continued Note the following Precautions: the sensors’ windows on the front of the Do not touch Detector electro-optical electronics module (puck). If touched accidentally, they should be cleaned following the instructions listed below (see Figure 2-4).
Page 10: Detector Connections
™ Model FS24X Fire and Flame Detectors INSTALLATION GUIDE and OPERATING MANUAL Opening the Detector ( continued 3. Loosen the three captive screws on the Detector Module puck (see Figure 2-7). Figure 2-7 4. Slide the Detector Module puck out of the enclosure base (see Figure 2-8).
Page 11: Installation Practices
Fire and Flame Detectors INSTALLATION GUIDE and OPERATING MANUAL Contacts shown with no power applied Figure 2-9 FS24X and FS24X-9 Detector Puck, ( rear view Note: Do not attempt to open the Detector Module puck as this voids all warranties. Detector Connections continued ATTENTION: FSX Power-Up –...
Page 12 ™ Model FS24X Fire and Flame Detectors INSTALLATION GUIDE and OPERATING MANUAL If the application for the Detector requires different settings, refer to Section 3.2 for detailed descriptions. Before applying 24 VDC power to the Detector, make sure 1. Wire connections are correct (Section 2.3). Each wire must be stripped properly to the correct length, loose wire strands must be removed and each wire must be securely and firmly screwed clockwise in the connector.
Page 13: Start-Up And Commissioning
Additionally, do not use these Test Lamps to activate other Fire Sentry Detectors (nor any other conventional fire and flame detectors). Do not use other Fire Sentry Test Lamps or non- Fire Sentry Test Lamps to test the FSX Detectors.
Page 14 ™ Model FS24X Fire and Flame Detectors INSTALLATION GUIDE and OPERATING MANUAL Start-Up and Commissioning ( continued Remember to disable the outputs, as a full functional test includes activating the ALARM outputs. A Fire Sentry Test Lamp must be used for this test (Section 4.4).
Page 15: Section 3: Operation
700 nanometers to 7000 nanometers (0.7 to 7.0 microns). Fire Sentry’s FS24X Fire Detectors utilize a NearBand IR™ portion of the spectrum from approximately 0.7 to 1.1 microns and a WideBand IR portion from approximately 1.1 to 7.0 microns. This allows the FS24X Detectors to sense over 80% of the total radiant “Blackbody Energy”...
Page 16 ™ Model FS24X Fire and Flame Detectors INSTALLATION GUIDE and OPERATING MANUAL Configuring the Detector ( continued Eight (8) position DIP Switch (SW2) - Figure 3-2 CAUTION - WARNING When the switches SW1, SW2, or SW3 are changed, the Detector’s input power...
Page 17: Led Status Indicators
INSTALLATION GUIDE and OPERATING MANUAL LED Status Indicators The Model FS24X Detector uses three (3) separate, bright LED’s to indicate the Detector’s status.  The Blue LED blinks (flashes) once every ten (10) seconds to indicate a Normal, safe operational condition (i.e.
Page 18: Fault Conditions
 Dirty Window Lens (Yellow LED flashes, the Yellow LED is ON [solid] for all other Faults). Maintenance After the FS24X Detector is installed and commissioned, there is little maintenance required. However, a complete “end-to-end” test of the entire fire detection system should be performed periodically depending on the application.
Page 19: Section 4: Appendix
Products shall become the property of Fire Sentry Corporation. This express limited warranty is extended by Fire Sentry Corporation to the original purchaser only and is not assignable or transferable to any other party. This is the complete warranty for the Products manufactured by Fire Sentry Corporation.
Page 20: Product Variations
1 = General Applications 2 = High Temperature Applications Manufacturer’s Code 2 = Standard Fire Sentry Detector - 110° Field of View (-1 has been replaced by -2) 9 = Standard Fire Sentry Detector - 90° Field of View EXAMPLES: FS24X-911-211 QuadBand Triple IR Detector, 90°...
Page 21: Digital Communication Options
For calibrated testing, in compliance with NFPA 72 Codes for flame detectors, as manufacturers of the FSX product line, our calibrated testing using our FT-2055X Test Lamp is as follows. If the FS24X set at Highest Sensitivity alarms to a fully charged FT-2055X Test Lamp at a distance between 1 and 25 feet, then the FS24X is in normal operating condition.
Page 22: Additional Performance Specifications
4.6.2 High Temperature Response The optional extended temperature range FS24X Detectors will respond to a one (1) sq. ft. n-heptane reference fire at a distance of 35 feet in 2 to 5 seconds, when the temperature exceeds 85°C. Page 19 Fire Sentry Corporation Document No.
Page 23: 4.6.3 False Alarm Immunity
™ Model FS24X Fire and Flame Detectors INSTALLATION GUIDE and OPERATING MANUAL Additional Performance Specifications ( continued 4.6.3 False Alarm Immunity The following tables represent the minimum distance at which the Detector did not false alarm or show any signs of instability during exposure to the sources listed below. Additionally, the sensitivity to a one (1) square foot n-Heptane reference pan fire in the presence of the false fire source is listed.
Page 24: Drawings
Fire and Flame Detectors INSTALLATION GUIDE and OPERATING MANUAL Drawings 4.7.1 Outline and Dimensions Figure 4-3 Outline & Dimesional Drawing for FS24X Figure 4-4 Outline & Dimesional Drawing for SM4 Page 21 Fire Sentry Corporation Document No. 6178-001 - Rev. Q ©...
Page 25: Wiring And Terminal Connections
™ Model FS24X Fire and Flame Detectors INSTALLATION GUIDE and OPERATING MANUAL Drawings ( continued 4.7.2 Wiring and Terminal Connections Figure 4-5 Typical Wiring for 4-20mA (Sourcing) Analog Output Figure 4-6 Typical Wiring for 4-20mA (Sinking) Analog Output NOTES: 1. Cable shield must be grounded at one end only, at the Control Panel. Coil and tape cable shield at the Detector end.
Page 26 ™ Model FS24X Fire and Flame Detectors INSTALLATION GUIDE and OPERATING MANUAL Drawings ( continued Wiring and Terminal Connections (continued) Fire Alarm Control Panel Alarm Input Fault N.C. Input Note 4 Alarm Relay Contacts N.O. (Note 2) Fault 24 VDC (+)
Page 27: Detector Label Drawings
INSTALLATION GUIDE and OPERATING MANUAL Drawings ( continued 4.7.3 Detector Label Drawings Figure 4-9 FS24X-9 Label for Hazardous Locations Figure 4-10 FS24X Label for Hazardous Locations Page 24 Fire Sentry Corporation Document No. 6178-001 - Rev. Q © Copyright 2011...
Page 28: Index
™ Model FS24X Fire and Flame Detectors INSTALLATION GUIDE and OPERATING MANUAL INDEX 4–20 mA ......... 3, 9, 11, 12, 13, 15 Additional Performance Specifications ...... 17 Labels ................ 22 Alarm Condition ............12 LED Status Indicators ..........12 Alarm LED ..............9 Alarm Relay .............
