D-MAX 27X User Manual

Auto focus, day&night zoom color camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

AUTO FOCUS, DAY&NIGHT
ZOOM COLOR CAMERA
USER MANUAL
사용 설명서
27X / 33X / 37X
용 서

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 27X and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for D-MAX 27X

  • Page 1 AUTO FOCUS, DAY&NIGHT ZOOM COLOR CAMERA USER MANUAL 사용 설명서 27X / 33X / 37X 용 서...

  • Page 2: Table Of Contents

    Contents Precautions Features Products Components Name and Functions of Each Parts 1) Front 2) Back Connection 1) Connecting to Monitor 2) Connecting to Connection Operating Your Camera 1) Menu Configuration 2) Menu Setup Trouble Shooting Specifications...

  • Page 3: Precautions

    1. Precautions Cautions This information is provided to ensure your safety and to prevent any loss, financial, Please read it carefully and use the products accordingly. - Warning - Installation of this product by unqualified personnel is strictly prohibited, Please consult an experienced installer or authorized retailer for proper installation to avoid possible fire or electric shock.

  • Page 4: Features

    2. Features High Magnification Zoom Lens High 432 x zoom function. (x27 Optical zoom, x16 Digital zoom) High 528 x zoom function. (x33 Optical zoom, x16 Digital zoom) High 592 x zoom function. (x37 Optical zoom, x16 Digital zoom) High resolution 600TVL Color : more than 600TVL, B/W : more than 700 TVL.

  • Page 5: Products Components

    3. Products Components 구성물 1. Color zoom camera 2. Instruction Manual...

  • Page 6: Name And Functions Of Each Parts

    4. Name and Functions of Each Part 1) Front ①Tripod Mounting Bracket Screw Hole Used to fix tripod mounting bracket on top of the camera. Tripod mounting is attached on bottom of the camera but it can install the mounting in the top of camera when the user need.
  • Page 7 2) BACK ① Key Buttons ▪ UP (TELE button): To move the arrow indicator to up - To close in on a far object. (ZOOM IN) ▪ DOWN (WIDE button): To move the arrow indicator to down - To widen the view. (ZOOM OUT) ▪...
  • Page 8 ☞ Notes • If the Adaptor Power Line is extended improperly, it may cause malfunctions since the camera is affected by unstable voltage condition. • Ensure Power Supply Source: DC 12V ± 10%, 500㎃ • The wire is polarized. Match “+” and “-“terminals properly ③...

  • Page 9: Connection

    5. Connection 1) Connecting to Monitor Connect Video Out Jack to the monitor's Video In jack as shown below. • Connect cables with the unit powered down. 2) Connecting to connection ▪ External Control Connector...
  • Page 10 Focus and Zoom functions can be controlled by using external signals. * It can be broken by using Overvoltage. * MD (Motion Detection) Output Signal Level (less than 10mA) ▪ Communication Control Connector...

  • Page 11: Operating Your Camera

    6. Operating Your Camera 1) Menu Configuration MAIN SETUP MENU SSNR ▪ OFF ▪ ON WHITE BALANCE ▪ ATW ▪ MANUAL ▪ AWC → SET ▪ OUTDOOR ▪ INDOOR BACKLIGHT ▪ OFF ▪ BLC ▪ HLC MOTION DET ▪ OFF ▪...
  • Page 12 1. Press the SET button for 2 seconds to access the main setup mode. • Main setup menu is displayed on the monitor screen. MAIN SETUP SSDR ON ↙ WHITE BAL BACKLIGHT MOTION DET FOCUS ↙ EXPOSURE ↙ SPECIAL ↙ RESET EXIT 2.
  • Page 13 SSDR(Super Dynamic Range) SSDR illuminates darker spots of an image while retaining the same light level for brighter spots to even out the overall brightness of images with high contrast between bright and dark spots. 1. When the SETUP menu screen is displayed, select ‘SSDR’ by using the button so that the arrow indicates ‘SSDR’.
  • Page 14 ※ The five white balance control modes are as follows. ▶ ATW (Auto Tracking White Balance): Select This when the color temperature is between 1800°K and 10500°K ▶ AWC→SET (Auto White balance Control): To find the optimal setting for the current luminance environment in this mode, set the point the camera towards a sheet of white paper and press the SET button.
  • Page 15 BACKLIGHT When there is a strong backlight behind the object, clear images of the Background as well as the object can still be obtained by using the BACKLIGHT function. MAIN SETUP SSDR ON ↙ WHITE BAL BACKLIGHT MOTION DET FOCUS ↙ EXPOSURE ↙...
  • Page 16 Enhancement level. Select ‘HLC’ to adjust the HLC MASK TONE and LEVEL. ☞ Notes Since the following symptoms may occur according to the ambient illumination when BLC is selected, set it to OFF. ○ 1 Color or screen changes unnaturally. ○...
  • Page 17 2. Please select the mode you wish to operate by pressing the LEFT or RIGHT button. MAIN SETUP SSDR ON ↙ WHITE BAL BACKLIGHT MOTION DET FOCUS ↙ EXPOSURE ↙ SPECIAL ↙ RESET EXIT ① Please press the SETUP button. - OFF : MOTION DETECTION mode is cancelled.
  • Page 18 • START ZOOM : Use the left or right button in the ‘START ZOOM’ item to select the zoom position from 1x to 27x (or 33x) to be returned after the ‘SMART ZOOM’ action is over. • TARGET ZOOM : Use the left or right button in the ’TARGET ZOOM’ item to select the zoom position from 1x to 27x (or 33x) to be used during motion detection.
  • Page 19 • AUTO : • ONE PUSH : Select AUTO and press the SET button to Focus is automatically adjusted just once, after confirm. Increase or decrease optical zoom zoom position is changed. Select 'ONE PUSH' (ZOOM) or digital zoom (D-ZOOM) positions by and press the SET button to confirm.
  • Page 20 • AUTOTRACK: Zooming in while deciding or adjusting the status of the focus. • TRACK: Zooming in with no relevance to the focus. • OFF: Only the zoom lens moves. ▶ ZOOM SPEED : Configure zoom tracing speed by using this feature. Position the indicator over 'ZOOM SPEED' by using the UP or DOWN button and then set todesired mode by using the LEFT or RIGHT button.
  • Page 21 AUTO : If you turn the power off and on, the zoom magnification level is set to the previous level that was set before the power went off. MANUAL : The zoom magnification level can be set from 1x to 27x (or 33x, 37x). ☞ Notes When the DIS is enabled, you cannot use the D-ZOOM and the zoom position is saved after 5 seconds when you set zoom function.
  • Page 22 ● PRESET NO : Up to 128 preset configurations are supported. ● PRESET SAVE : Save configured preset. ● PRESET CLEAR : Clear configured preset. ● END : Revert to the FOCUS SETUP menu. LENS INIT : Use the left or right button in the ‘Lens initialization’ item to select ▶...
  • Page 23 MAIN SETUP SSDR ON ↙ WHITE BAL BACKLIGHT MOTION DET FOCUS ↙ EXPOSURE ↙ SPECIAL ↙ RESET EXIT ▶ BRIGHTNESS : Use this feature to adjust image brightness. Position the indicator over 'BRIGHTNESS' using the UP or DOWN button. Then increase or decrease brightness level by using the LEFT or RIGHT button while verifying the changes on screen.
  • Page 24 • AUTO: The iris is automatically activated upon illumination. • MANUAL: Manual iris configuration. Set 'IRIS' to 'MANUAL' by using the LEFT or RIGHT button and then press the SET button. Increase or decrease iris level by using the LEFT or RIGHT button while verifying the changes on screen. ▶...
  • Page 25 • A.FLK (NTSC: 1/100, PAL: 1/120): Flicker-free mode. • ESC : Automatic shutter speed setting (optimal). Auto operation is possible only when the IRIS is set to MANUAL. • MANUAL : Manual shutter speed setting. ② If you choose ‘MANUAL’, select the optimal shutter speed. ·...
  • Page 26 • MEDIUM : MEDIUM range gain value adjustment • LOW : Narrow range gain value adjustment • MANUAL : Selecting gain value range.(5dB~41dB) • OFF : Disabled ▶ SSNR3 : On screen noise reduction. ① Position the indicator over 'SSNR' by using the UP or DOWN button. ②...
  • Page 27 • SSNR function is disabled in AGC mode ‘OFF’. ▶ Sens-UP: This feature ensures clear images at night or under low lighting conditions. ① Position the indicator over 'SENS-UP' using the UP or DOWN button. ② Set 'SENS-UP' to the desired mode using the LEFT or RIGHT button. ③...
  • Page 28 SPECIAL 1. Press the SET button to access the main setup menu and then position the indicator over 'SPECIAL' using the UP or DOWN button. 2. Press the SET button to confirm. SPECIAL SETUP PRIVACY DAY/NIGHT AUTO↙ SYNC COMM ADJ ↙ IMAGE ADJ ↙...
  • Page 29 • AREA MODE Mask area display. TOP : To move the mask area up. BOTTOM : To move the mask area down. LEFT : To move the mask area left. RIGHT : To move the mask area right. • MASK COLOR Adjust desired mask color level.
  • Page 30 'COMMUNICATION' by using the UP or DOWN button. • PROTOCOL : Select the communication PROTOCOL. (D-max/STW/PELCO-D/PELCO-P) • CAM ID : Assign an ID number to the camera (1 to 255). Identification number zero is used for Remote controller setup.
  • Page 31 IMAGE ADJ : Includes image quality or special function factors. ▶ ○ 1 When the SETUP menu screen is displayed, select ‘IMAGE ADJ’ by using the Up and Down buttons so that the arrow indicates ‘IMAGE ADJ’. ○ 2 Selected a desired mode using the Up and Down buttons. •...
  • Page 32 DISPLAY: Includes image quality or special function factors. ▶ • CAM TITLE : Use this feature to designate a name for the camera, which will display on the monitor screen. ①Press the SET button to display the main setup menu and move the arrow indicator to 'CAM TITLE' by using the UP or DOWN button.
  • Page 33 ⑤Select on screen position of the CAM TITLE. a. Move the cursor to 'POS' and press SET button. b. The CAM TITLE is displayed on the top-left of the monitor screen. (Default position) c. Select the position by using the 4-directional buttons, then press the SET button to confirm the position.
  • Page 34 • LANGUAGE : You ca n select the menu language according to your requirements (ENGLISH, Chinese, DEUTSCH, ITALIANO, FRANCAIS, ESPANOL, Korean, Japanese, PORTUGUESE ) • END : Select this to save the DISPLAY menu settings and return to the SPECIAL menu. RESET To reset your camera to factory default condition.

  • Page 35: Troubleshooting

    7. Troubleshooting Problem Solution No display • Check the power cable and the wiring between the camera and the monitor. • Ensure proper video cable connection (Video Out Jack). Dim display • The lens could be dirty. Clean with a soft, clean piece of cloth. •...

  • Page 36: Specifications

    ATW / Manual / AWC→SET / OUTDOOR/ INDOOR SSNR LOW / MEDIUM / HIGH / OFF Built-in Flip / Mirror On / Off Communication RS 485, Multi Protocol (D-max, STW, Pelco) S/N Ratio 52dB (AGC Off) Video Output Composite video output 75 ohm terminated Sync. System Internal...
