Summary of Contents for LinkQage Linkqage KVM Switch

  • Page 1 PRODUCT CATALOGUE...
  • Page 2 INTRODUCTION Linkqage - the IT distribution company that specialises in KVM, networking, cables, converters and LCD brackets. The company is young and has a very dynamic team, with directors and staff that have been active within the field of KVM switches and related products for more than fifteen years.

  • Page 3: Table Of Contents

    CONTENTS Switches - Rextron Switches - Rose Switches - Minicom Extenders DIGITAL SIGNAGE NETWORKING Racks Accessories Cabling CONVERTERS CABLES HDMI/DVI/VGA USB 2.0/Firewire Computer Cables Computer Adapters Audio/Video Specialised - RapidRun POWER AUDIO & VIDEO CONVERTERS BRACKETS...

  • Page 4: Kvm Switches

    PS/2 console. With the Sync-EmuTM Technology, the advanced KAG104D is designed to meet the special requirements from USB-ready HP Unix systems and Sun servers. Engineered for servers of the highest level, the range guarantees flawless switching with zero tolerance.
  • Page 5 Revolutionized video enhancement technology ensures superb quality up to 1920 x 1440. For secured connection and space saving, all NovaView KVM switches require just one HDB15 connector for each computer connection. PS/2 KVM Switch with two access points KNV-201 [REX-KNV201]...
  • Page 6 KNV-2166D [REX-KNV2166D] OVERVIEW This 2-console-8-computer KVM switch enables one user to operate up to eight computers from one of two different locations. While in idle, both consoles show the same computer information; but only one console has control at a time. For security reasons, only one console has the information when it takes control and the other console's screen is blanked leaving the keyboard LEDs (Num/Caps/Scroll Lock) flashing.
  • Page 7 It offers the revolutionized remote server management by combining our industry-leading remote control technology with a proven Enterprise class digital KVM switch, managing up to 16 computers remotely from anywhere in the world. Signal Converter RS485 to RS232...

  • Page 8: Switches - Rose

    Local analog access to multiple servers at the rack Compatible with KVM.net centralized management system Innovative CAT5 ROC technology- eliminates cable clutter at the rack Extends distance between servers and switch up to 30 meters/100ft Space saving - sleek, 1U rack mountable Multi-platform - PS/2, and USB support...
  • Page 9 Smart KVM Extender Control your computer from up to 110m away OVERVIEW Extends KVM control over 110m/360ft from your computer or KVM switch Dual-user function - double the power of your computer by allowing 2-user access 2 port KVM switch function...

  • Page 10: Switches - Minicom

    Available in 4, 8, or 16 CPU port models, expandable to as many as 1,000 CPUs Connect to a remote computer, server, serial device, or KVM switch directly or remotely over IP using any supported† Internet browser Local KVM port for configuring the UltraConsole 2...
  • Page 11 CrystalView USB2 USB 2.0 and Video Extender CrystalLink USB Fiber USB Fiber extender CrystalView Pro Fiber Fiber KVM Extender OVERVIEW Extend video and USB 2.0 peripheral (including keyboard and mouse) up to 150 feet (50m) from the controlling computer Supports USB 1.1 (low/ full speed) and USB 2.0 high speed devices at 480 Mbps Advanced automatic video compensation and equalization with optional skew...

  • Page 12: Extenders

    Station Unit that is suitable to locate a keyboard/monitor/mouse set up to 150 meters away from a computer or KVM switch using an inexpensive Category 5 UTP (unshielded twisted pair) cable. It provides an ideal and convenient way to remotely access the computer which is located in a secure, clean or dirty, harsh environment.
  • Page 13 Rack Mount accessories enable you to mount Rextron KVM switches to standard 19” rack cabinet. A specially designed cable support bar unloads most of the cables weight from the switch and makes cable management easy. Also available for 8-port and 16-port KVM switches.

  • Page 14: Digital Signage

    DIGITAL SIGNAGE Audio Video Display System Distribute multimedia content to hundreds of digital signage displays in real time DS Vision 3000 The ultimate player-to-screen distribution and control OVERVIEW Distribution to hundreds of display screens over flexible CAT5 cable High resolution (1200x1600@75Hz) support Extend displays up to 110m/360ft from the player/computer Out-of-band - frees network from heavy image...

  • Page 15: Video Splitter

    Video Splitter VSA-12 [REX-VSA12] VSA-14 [REX-VSA14] VSA-18 [REX-VSA18] VGA Splitter VSA-108 [REX-VSA108] VSA-116 [REX-VSA116] VGA Selector VSA-401 [REX-VSA401] VSA-801 [REX-VSA801] OVERVIEW Simultaneously broadcast one VGA signal up to 8 different monitors can never be easier with Rextron's high-end video splitters. With breakthrough video enhancement technology, Rextron once again pushes the bandwidth to 350Mhz for crisp clear video...

  • Page 16: Networking

    NETWORKING RACKS Network Server Cabinets 37U 600 x 800mm [RCK-SH-05A-37U] 42U 800 x 1000mm [RCK-SH-05A-42U] MODEL W x H CAPACITY RCK-SH-05A-37U 600 x 800 RCK-SH-05A-42U 800 x 1000 Mesh Doors Non-tinted glass doors optional MODEL INCLUDES RMD37-600 600mm wide, 37RU Server cabinet RMD42-800 800mm wide, 42RU Server cabinet INCLUDES...
  • Page 17 Swing Frame Wall Mounted Cabinets 6U 600 x 550mm right open [RCK-SH-02BC-6USF] 9U 600 x 550mm right open [RCK-SH-02BC-9USF] 18U 600 x 550mm left open [RCK-SH-02BC-18USF] MODEL W x D x H CAPACITY RSFWM6 600 x 550 x 368 RSFWM9 600 x 550 x 501 RSFWM18L 600 x 550 x 901...
  • Page 18 NETWORKING RACKS Wall Mount Cabinets 6U 600 x 450mm [RCK-SH-DSFF-6UWB] 9U 600 x 450mm [RCK-SH-DSFF-9UWB] MODEL W x D x H CAPACITY RWM6 600 x 450 x 368 RWM9 600 x 450 x 501 INCLUDES Glass front door, 1 x fan, 1 x fixed shelf, 30 x cage nuts Glass front door, 1 x fan, 1 x fixed shelf, 30 x cage nuts OVERVIEW Includes fixed shelf &...

  • Page 19: Accessories

    Cantilever 1U shelf SH-J017 [RCK-SH-JO17] Blanking panel SH-J019 [RCK-SH-JO19-1U] [RCK-SH-JO19-2U] LINKQAGE IMPORTS A FULL RANGE OF SERVER CABINETS AND ACCESSORIES. PLEASE CALL US FOR MORE INFORMATION. Fixed shelf SH-J018 for 800mm depth cabinet [RCK-SH-JO18] for 1000mm depth cabinet [RCK-SH-JO18-1000] Heavy Duty Castor SH-J021 [RCK-SH-JO21] Sliding shelf...

  • Page 20: Cabling

    NETWORKING CABLING CAT5 NETWORKING CABLING Easypull Box - 305m Solid cable [NETCAT5SOLCAB305] Stranded cable [NETCAT5STCAB305] CAT6 NETWORKING CABLING Solid cable [NETCAT6SOLCAB305] Stranded cable [NETCAT6STCAB305] CABLE TIES Large variety available - please enquire CAT5 FLY LEADS We manufacture any length of fly lead required. CAT6 FLY LEADS We manufacture any length of fly lead required.

  • Page 21: Patch Panels

    SPIRAL BINDING Small Transparent Spiral Binding [NET-SPIRAL-TR-SM] Small Black Spiral Binding [NET-SPIRAL-BL-SM] Big Transparent Spiral Binding [NET-SPIRAL-TR-B] Big Black Spiral Binding [NET-SPIRAL-BL-B] PATCH PANELS CAT5 and CAT 6 available OVERVIEW Linkqage provides the cutting edge of augmented Category 6 Patch Panel to meet tomorrowís most advanced and performance-critical applications.

  • Page 22: Cable Tester

    NETWORKING CABLING CABLE TESTERS Cable Tester Network/Datacom/Telecom [NET-TEST-ENT] TOOLS Modular Crimping Tool HT-N5684 [NET-CRIMP-RJ11RJ45] OVERVIEW For crimping modular plug 8P8C(RJ45), 6P6C(RJ12), 6P4C(RJ11), 4P4C & 4P2C PLUGS. 4P crimper located on the back side of the tool Cut & strip by one operation. Easy & effective. Economic type, light weight.
  • Page 23 BOOTS [NET-BOOT] RAW CABLE VGA Cable ( CAB-RAW-SVGA] Serial Cable (7/12/25 core) INLINE CONNECTORS RJ11 Inline Connectors [NET-RJ11INLINE] UTP CONNECTORS CAT5 - solid [NET-CAT5SOLCON] CAT6 - solid [NET-CAT6SOLCON] WALL BOXES CAT5 [NET-CAT5WALL] CAT6 [NET-CAT6WALL] MODULAR CABLE & CONNECTORS Mod 4 Telephone Cable Connectors [NET-RJ11CON] and stranded...

  • Page 24: Converters

    CONVERTERS USB to PS/2 Adapter [CNV-USB-PS2-ADA] OVERVIEW 2 downloadstream PS/2 Connector High power device on a currrent 500mA Based on USB specification 1.1 compatibility PS/2 keyboard and PS/2 mouse work together under one adapter USB v2.0 5M (16ft) Extension Cable [CNV-USB-EXTA-5M] OVERVIEW Compliant with USB specificatin v2.0...
  • Page 25 UNITEK HDMI Extender [CAB-Y-5115] OVERVIEW One pair as a full functional module, no need of setting. Use CAT-5E cable to substitute HDMI Cable to achieve long distance transmission. Follow the standard of IEEE-568B Transmission distance reaches up to 60 meters Auto-adjustment of feedback, equalization and amplify, the user does not need to care about the length of the cable Compact size...

  • Page 26: Cables

    CABLES HDMI / DVI /VGA HDMI Male to Male cable Available in 1.8m, 3m, 5m, 10m, 20m, 25m [CAB-HDMI-MM-3M] [CAB-HDMI-MM-5M/24] [CAB-HDMI-MM-10M/24] [CAB-HDMI-MM-20M/24] [CAB-HDMI-MM-25M/24] Digital DVI-D cables Coaxial Shielded VGA Extension cable Available in 1.8m, 5m, 10m, 20m, 30m, 40m HDMI to Mini HDMI cable Available in 2m, 5m [CAB-MHDMI-HDMI-2M] [CAB-MHDMI-HDMI-5M]...

  • Page 27: Usb 2.0/Firewire

    USB 2.0 / FIREWIRE USB 2.0 Type A / Type B cable [CAB-USB-1.8M] [CAB-USB-5M] Firewire 6P Male/Male [CAB-FW-6-6-1.8M] Firewire2 9P Male/Male [CAB-FW-9-9-1.8M] USB 2.0 Type A Extension cable [CAB-USB-EXTP-3M] Firewire 6P Male to 4P Male [CAB-FW-6-4-1.8M] Firewire2 9P Male to 6P Male [CAB-FW-9-6-1.8M] USB 2.0 Type A /...

  • Page 28: Computer Cables

    CABLES COMPUTER CABLES Parallel Printer cable 25 Wire [CAB-PAR=DB25M-CEN-1.8M] DB9 Extension Cable [CAB-SER-9M9F-1.8M] Serial ATA Serial ATA Power Data Cable cable/splitter [CAB-SATA-IDE-46CM] DB25 Male/Male cable [CAB-SER-DB25M-M-1.8M] PS/2 Extension Cable [CAB-PS2-6M6F-1.8M] IDE Internal Data cable [CAB-IDE-46CM] DB25 Male/Female Cable [CAB-SER-DB25M-25F-1.8M] PS/2 Male/Male Cable [CAB-PS2-6M6M-1.8M] Integrated Power cables...

  • Page 29: Computer Adapters

    COMPUTER ADAPTERS DVI TO VGA adapter [ADA-DVIF15M] [ADA-DVIM15F] Serial ATA to IDE converter [CAB-MF420] VGA Gender changer [ADA-9F9F] HDMI to DVI-I adapter [CAB-SADA-HDMIF/DVIM] DB9 to D25 adapter [ADA-9M25F] DB15 Gender changer [ADA-25F25F] HDMI to DVI-D Adapter [CAB-ADA-HDMIM/DVIF] DB9 Gender changer [ADA-9M9M] DB25 Gender changer [ADA-25M25M]...

  • Page 30: Audio/Video

    CABLES AUDIO / VIDEO CABLES RCA Audio Cables RCA Extension cable S-Video Cable RCA Audio/Video Cables RCA to Stereo Plug cable S-Video to RCA cable RCA Audio/RG59 Video Cables RCA Digital Audio cable Stereo plug cables...

  • Page 31: Custom Cabling

    custom cabling LINKQAGE MANUFACTURES A WIDE VARIETY OF COMPUTER AND POWER CABLES TO YOUR INDIVIDUAL SPECIFICATIONS. PLEASE CONTACT US FOR MORE INFORMATION...

  • Page 32: Specialised - Rapidrun

    CABLES SPECIALISED RapidRun is the first modular cabling system built from the ground up to save installation time, accommodate last–minute changes, and reduce the likelihood of return service calls due to faulty field terminations. It truly is an evolutionary product, designed to evolve with customers’...
  • Page 33 Installers benefit from powerful performance advantages, including: Uncompromised signal integrity: pin pitch and insulator material make our connector virtually transparent to the delicate video signal, resulting in minimal signal loss. Dirt and damage protection: the pulling caps protect the delicate contacts within the connector from the dirt, dust and damage –...
  • Page 34 CABLES SPECIALISED RapidRun™ Runner™ Technology Imagine pulling a VGA cable through 3/4'' conduit with a 90° sweep – and not worrying about all those small pins when you’re done. Ever better, imagine switching the installed cable from VGA to component video or switching DVI™ to HDMI™ in less than a minute.
  • Page 35 Break Away From Rigid Connection Choices with Adaptable, Efficient Break-Away Terminations. You’ll select from two Break-Away termination options: Decora*-compatible Break-Away wall plates and Break-Away Flying Leads. Just choose the right termination for your application – without having to worry about performance variation or installation barriers.

  • Page 36: Power

    POWER 3 Port multi-plug [PWR-MP-3P] 10 Way Multi Extension (5x16a, 4x5a+din) [PWR-MP-5P] 10m Extension lead [PWR-LEAD-5M] [PWR-LEAD-10M] 3 Port multi-plug with switches [PWR-MP-3PS] 5 Port muti-plug with switches [PWR-MP-5PS] 20m Extension lead [PWR-LEAD-20M]...

  • Page 37: Power Sockets

    3-prong Standard Plug [PWR-N-PLUG] [PWR-D-PLUG] Normal and dedicated SA plugs 1.8m Power Extension Cable [CAB-PWR-KMKF-1.8M] 1.8m kettle power extension cable. Extend your existing kettle power connection. Custom lengths can be manufactured. Y-Power splitter Cable (2x hard drives) [CAB-PWR-Y-HDD] Internal Y-Power splitter. Connect 2 hard drives to one power connection.

  • Page 38: Audio & Video Converters

    AUDIO AND VIDEO CONVERTERS PC/Component to HDMI Converter CP-261H [CNV-CP-261H] OVERVIEW The CP-261H converts analog PC/RGB or HD YPbPr and their associated audio source to digital HDMI format. It enables you to connect your PC VGA out or DVD YPbPr out to the HDMI input of the new HD ready HDTV.
  • Page 39 CV/SV to WXGA Converter CM-396 [CNV-CM-396] OVERVIEW The CM-396 is a low cost video to PC converter that converts CV/SV (NTSC or PAL system) to 3 PC resolutions-XGA, SXGA and WXGA. It allows you to view your DVD, VCR or game video source on your PC monitor.

  • Page 40: Brackets

    LCD BRACKETS Plasma Bracket PLB-13 [BRK-PLB-13] Strengthening wall bracket, 30”-63”, max 75kg Plasma Bracket PLB-14 [BRK-PLB-14] Strengthening wall bracket, 15 tilt, 30”-63”, max 75kg Plasma Bracket PLB-WA3A [BRK-PLB-WA3A] Wall mount, extending arm for single LCD/Plasma, 30”-63”, max 80kg (should be mounted with strengthening wall bracket) LCD bracket LCD-401AB [BRK-LCD-401AB]...
  • Page 41 LCD Bracket LCD-T1 / LCD-T2 [BRK-LCD-T2] Plasma Bracket PLB-CE3 [BRK-PLB-CE3] Roof mount arm for single LCD/Plasma, swivel, 30-63”, max 150kg (should be mounted with strengthening wall bracket) Plasma Bracket PLB-CE3D [BRK-PLB-CE3D] Roof mount arm for dual LCD/Plasma, swivel, 30-63”, max 150kg (should be mounted with strengthening wall bracket) Projector Bracket PRB-3...

  • Page 42: Contact Details

    CONTACT DETAILS LINKQAGE CAPE TOWN UNIT 33-34 NORTHGATE BUSINESS PARK NORTHGATE ESTATE CAPE TOWN 7405 SOUTH AFRICA T +27 [0]21 514 4800 F +27 [0]21 511 1433 LEGAL DISCLAIMER: All care has been taken to ensure the accuracy of all technical and specification information. No responsibility can be accepted for any errors or omissions.
  • Page 44 T +27 [0]21 514 4800 F +27 [0]21 511 1433 UNIT 33-34 NORTHGATE BUSINESS PARK NORTHGATE ESTATE, CAPE TOWN 7405, SOUTH AFRICA...
