Summary of Contents for Display 1510XC
- Page 1 User’s Guide For 1510 XC Designer Series LCD Display Document Number P1510XC-100-0409-Rev 2.0 © Copyright 2005 Display Werks - All rights reserved. U.S PATENT PENDING...
- Page 2 THESE PRODUCTS ARE NOT DESIGNED FOR USE IN LIFE SUPPORT APPLIANCES, DEVICES, OR SYSTEMS WHERE MALFUNCTION OF THESE PRODUCTS CAN REASONABLY BE EXPECTED TO RESULT IN PERSONAL INJURY OR DEATH. DISPLAY WERKS CUSTOMERS USING OR SELLING THESE PRODUCTS FOR USE IN SUCH APPLICATIONS DO SO AT THEIR OWN RISK AND AGREE TO FULLY INDEMNIFY DISPLAY WERKS FOR ANY DAMAGE RESULTING FROM IMPROPER USE OR SALE.
-
Page 3: General Description
2.1. The model 1510XC is an advanced TFT LCD that extends analog (RGBHV) computer graphics images over a single CAT 5e cable up to 500 feet from Display Werks, XC Transmitters. The display also has the capability of supporting serial touch screen (optional), internal speakers (standard), PS/2 mouse (standard), and PS/2 keyboard (standard), line level audio out (standard). - Page 4 Different options and configurations can be ordered to suit the specific needs of our users. Use our part numbering description codes listed below to determine the type of display that will suit your needs or to determine the model that you have received. Example P/N - 1510-TS-R-12-WB01-SN 15”...
-
Page 5: Specifications
3. Specifications (Subject to change without notice) Display Area – 15.0” Diagonal Driver Element – a-Si TFT Active ● ● Matrix Display Colors – 16.2M (True) Number of Pixels – 1024 x 768 ● ● Pixel Pitch – 0.297mm(H) x .0297mm (V) Contrast Ratio –... - Page 6 4. Connections and XC Adjustments 4.1. System Diagram for 12volt DC version D IS P L A Y W E R K S X C D IS P L A Y A U D IO O U T 1 2 V D C IN P U T P S /2 M O U S E (U S E IS O P T IO N A L )
-
Page 7: Personal Computer
N OTE (1) - KEYBOARD CABLE M UST BE CON N ECTED FOR TRAN SM ITTER TO OPERATE (POW ER TO TRAN SM ITTER IS SUPPLIED THROUGH THIS CON N ECTION ) N OTE (2) - SEE SECTION 2.2 OF USER'S GUIDE FOR A DESCRIPTION OF AVAILABLE DISPLAY CON FIGURATION S N OTE (3) - SEE SECTION 4.4 N OTE (1) OF USER'S GUIDE FOR KEYBOARD &... - Page 8 LIABILITY DISPLAY W ERKS IS N OT LIABLE FOR DAM AGES OCCURIN G FROM , BUT N OT LIM ITED TO; THE SELECTION OF IM PROPER CABLIN G, IN STALLATION OF CABLIN G, CON N ECTIVITY, CABLE M AN AGEM EN T, SELECTION OF POW ER SUPPLY.
- Page 9 Note (1): All display types support Keyboard and Mouse functionality. Neither the Keyboard nor the Mouse needs to be connected to the display during system boot-up, nor do they need to be present for normal operation. When Keyboard or Mouse functionality is needed either device maybe added or removed at anytime during normal system operation.
- Page 10 Twisted Pair Data Link RJ45 Jack (Female) – connector for transmitting signal to (CAT 5e) Display Werks XC monitor (No Network, No Power). (Terminated to EIA/TIA 568 Scheme B) Line In Stereo Phone Jack (Female) - jack for audio in.
- Page 11 PC, it is time to power up and adjust the system in the manner listed below. As previously mentioned, connection to or use of the Keyboard and/or Mouse port on the Display side is optional and can be put into use or taken out of use at any point. Just be sure that you have the Keyboard &...
- Page 12 One (1) tactile switch for on & off Status Monitor One (1) two color LED (Green / Amber) User Feedback On Screen Display (OSD) Language Support English 5.2. User Interface Note: This illustration depicts the user interface, located on the rear of the display. P1510XC-100-0409-Rev. 2.0 Page...
- Page 13 Manual Adjustment If the display does not optimize all the adjustments to the user’s preferences, the settings may be adjusted manually using the user interface buttons, on the front or rear of the display, and the OSD menus.
- Page 14 Out of Range If the input signal is out of the permitted frequency, the display will show an “Out of Range” error message. This feature also protects the internal circuitry. The system judges the input signal using the following: Normal Mode: If the input signal is in the permitted frequency as indicated it will be in Normal Mode.
- Page 15 6.1. In order for the touch screen to function, touch screen software (also referred to as a Driver) needs to be installed on the PC. Included with each touch-enabled display is a User’s Guide & Drivers disk, which contains the necessary touch drivers.
-
Page 16: Troubleshooting
7. Troubleshooting If you have troubles using this monitor, please refer to the following suggestions for troubleshooting. If you are still having difficulty, please contact Display Werks for assistance. Symptom Suggestions Screen is blank Ensure that the power cord is connected and the and power monitor is on (press “Power”... - Page 17 8. Wall Box Installation Supplement Display Dimension Details Installation steps 1&2 P1510XC-100-0409-Rev. 2.0 Page...
- Page 18 P1510XC-100-0409-Rev. 2.0 Page...
- Page 19 Installation step 3 P1510XC-100-0409-Rev. 2.0 Page...
- Page 20 Installation steps 4&5 P1510XC-100-0409-Rev. 2.0 Page...
- Page 21 Installation step 7 & Notes POST CONSTRUCTION INSTALLATION P1510XC-100-0409-Rev. 2.0 Page...
-
Page 22: Limited Warranty
CUTOUT DETAIL FOR POST CON STRUCTION IN STALLATION S 1'- 4" (2X 4 W ALL CO NSTR UCTIO N 16" O .C.) " " (W ALL BO X CUTO UT) (W ALL BO X CUTO UT) W ALL COVERIN G "... - Page 23 Display Werks warrants this product to be free from defects in material and workmanship and, subject to the conditions set forth below, agrees to repair or replace any part of the enclosed unit, which proves defective for a period of (1) year from the date of first purchase.
-
Page 24: Contact Information
10. Contact Information If you have any questions on this product or would like information on other Display Werks products please contact us. Display Werks 2747 29 Avenue SW Tumwater, WA 98512 Telephone 360-705-4112 Toll Free 877-705-1319 360-709-9552 Email Info@displaywerks.com Website www.displaywerks.com...
