- Page 1 H.264 4-Channel Mobile DVR User’s Manual ▪ H.264 4-Ch. Mobile DVR ▪ Anti Shock & Vibration control ▪ Built-in Heating System ▪ 2.5” Mobile HDD & SD Card ▪ GPS, G-Sensor...
-
Page 2: Preface
Preface We welcome you as a new user of the world's best digital video recorder (DVR), and the leading Digital Video Surveillance System. For effective usage, please read this manual carefully. For future reference, please keep this manual close to hand. Copyright/Authentication/Trademark/Limited Warranty Copyright This manual is produced under copyright law. - Page 3 Risk of death or serious injury. This is the highest priority danger warning. • RISK OF EXPLOSION IF BATTERY IS REPLACED BY INCORRECT TYPE. DISPOSE OF USED BATTERY ACCORDING TO THE INSTRCTIONS. • THIS EQUIPMENT IS INDOOR USE AND ALL THE COMMUNICATION WIRINGS ARE LIMITED TO INSIDE OF THE BUILDING.
- Page 4 Risk of minor injury or damage. • If a foreign substance is stuck to the product, remove it using a soft cloth or tissue. Do not use chemical agents (thinner, solvent, etc.) to remove the substance. • Do not operate or store the product in the following places. - An area that is either too cold or too hot - An area of high humidity, or in front of an air-conditioner, or in places subject to sudden temperature changes...
-
Page 5: Table Of Contents
Contents Preface ....................1 Copyright/Authentication/Trademark/Limited Warranty ..........1 Cautions ........................1 Contents..................... 4 Chapter 1. Introduction ..............6 1. The System ......................6 2. General Features ....................6 3. Specification ....................... 7 Chapter 2. System Installation ............8 1. Package Contents ....................8 2. - Page 6 2-5-4. MENU > NETWORK > Transmission ............33 2-6. EVENT ......................34 2-6-1. MENU > EVENT > Sensor ............... 34 2-6-2. MENU > EVENT > Motion ............... 35 2-6-3. MENU > EVENT > Video Loss..............37 2-6-4. MENU > EVENT > Text-In ............... 38 2-6-5.
-
Page 7: Chapter 1. Introduction
Chapter 1. Introduction 1. The System This DVR provides the cutting edge of mobile solutions for any types of mobile transportations. This DVR was built upon industrial specification that offers the most reliable mobile solutions ever. Its industrial specification allows withstanding any harsh conditions of shock, vibration and temperature. -
Page 8: Specification
3. Specification Model 4 Channel Mobile DVR 4 Ch Video 1 CVBS 4 Mic-in Audio 1 Line-out Sensor In 2 TTL Device Alarm Out 2 Relay I/O Interface RS232, RS485, USB2.0 x 1, USB1.1 x 1 for Mouse Speed Real Time Display Resolution 720 x 480 (NTSC), 720 x 576 (PAL) -
Page 9: Chapter 2. System Installation
Chapter 2. System Installation 1. Package Contents The following components are included in the product: DVR Unit Harness & Terminal Block Remote Controller (User's Manual & Network S/W) Quick Guide Bracket Screws & Keys GPS Antenna (Option / SMA type connector) -
Page 10: Installation
2. Installation 2-1. Bracket Disassembly Bracket Screws (6 points) Rear Cover Screws (3 points) Rear Cover Take the unit out of the box and disassemble the brackets as follow: - Unscrew Rear Cover Screws to remove Rear Cover - Unscrew Bracket Screws to remove installation (bottom) bracket. - The installation bracket has following sizes, and it must be bolt down on the bottom or top surface strongly using the 6 taping screws. -
Page 11: Unit Installation
2-2. Unit Installation Bracket Screws (6 points) Bolt Down Installation Bracket on the bottom or top surface using bracket screws. [The Bottom] [The Top] - To install the unit on the bottom, just use the bracket screws to bolt down the unit with the installation bracket as it is. -
Page 12: Connection Devices
2-3. Connection Devices The front & rear panel of the 4 channel premium DVR comprises the following: • Front USB: Two USB ports are provided to connect external devices like HDD, ODD, Flash memory for Backup, System upgrade or USB mouse on the front panel. A USB mouse can be connected only front panel USB port dedicated only for mouse. - Page 13 Power In The DVR will operate on both 12V and 24V systems. Two (+) pins should be connected to a fuse that is connected to the positive(+) power bus bar that is turned on when the ignition switch is in the Accessory position.
- Page 14 • GPS Antenna: The unit has built in GPS. SMA type GPS antenna needs to be set up separately for the proper reception of GPS data. • Reset: The DVR has a Reset switch that will only be used to return all the settings to the original factory settings.
-
Page 15: Cautions
3. Cautions • Avoid installing the product where there are direct rays or it is hot by locating near from heat generator. (May cause fire) • Do not put vase, flowerpot, cup, cosmetics, drug, and anything the contain water on product. (May cause fire or electric shock, and it may injure people by falling) •... -
Page 16: Chapter 3. Using Dvr
Chapter 3. Using DVR 1. Basic Operation 1-1. Front Panel & IR Remote Controller Front Panel Description Two USB ports are located on the front panel. A USB mouse USB Port can be connected USB port dedicated only for mouse as picture directed. - Page 17 Plays the video forward. Press the button repeatedly to increase play speed up to max 32 times (1, 2, 4, 8, 16, 32 PLAY Button times) faster. Use this button to move right when setting the menu. - Focus on far distance under PTZ mode. Plays the video backward.
-
Page 18: Turning On The System
1-2. Turning on the System The unit will start and run automatically when turn on the ignition if it is installed properly. It will take about 20-30 seconds for the boot up and start recording based on the pre set up options. If the temperature below -0°C (32°F), the unit will start recording after HDD is heat up by our built in heating sensor. -
Page 19: Display Icons
1-4. Display Icons No Recording Recording (Red) E.REC (Emergency Recording) Event Recording (Red) Pre Event Recording (Blue) Motion Detection Sensor Detection Text In PTZ Camera Instant Backup Clip Maker (Blue) Backup (Red) Video Loss 1-5. User or Admin Login Press MENU to enter main menu screen. Login in screen appears to enter ID (Administrator or User) and Password. -
Page 20: The Main Menu
1-6. The Main Menu The Main Menu of DVR consists of SYSTEM, DEVICE, DISPLAY, RECORD, NETWORK and EVENT. And each menu consists of various sub menus that allow detail set up of the system. Use Mouse, Remote Controller or Front Buttons to access to each menu. Note : Please make sure the system log out is done when the system setting or operation completed to prevent any unauthorized changes of system settings or operations. -
Page 21: Contextual Menu
1-7. Contextual Menu Additional Contextual Menu screen appears by pressing right button on the Mouse. Layout option allows changing Camera on the monitor. Select preferred camera display option on the monitor. Camera : Select camera no. Layout : Select display mode (8/16 ch. DVR Only) : Select OSD display option Text-In Info.: On/Off Text-In OSD. -
Page 22: Dvr Configuration
2. DVR Configuration 2-1. SYSTEM Under SYSTEM menu, System configuration options for general Information, Date &Time, User, Quick Setup and System Log can be selected. 2-1-1.MENU>SYSTEM>Information In the Information screen, DVR Name, System Version, Upgrade, Mac Address and Configuration options can be selected. Highlight and press DVR Name to enter or change DVR name. -
Page 23: Menu > System > Date & Time
2-1-2. MENU > SYSTEM > Date & Time In the Date & Time, Time Zone, Date, Time, NTP Server, Holiday options can be selected. Highlight and press Time Zone to select right Time Zone. Select ‘Use Daylight Saving Time’ if it is applicable. -
Page 24: Menu > System > Quick Setup
Auto Logout: Turn On or Off Auto Logout option. Press to add a new user. To remove an existing user, press next to it. User Name: Enter a user name Group: Select a Group which a new user will belong to Password: Set a new password or change a password. -
Page 25: Menu > System > System Log
2-1-5. MENU > SYSTEM > System Log In the System Log, full list of system logs can be searched. Press Reload button to refresh log list. USE button to search log list page by page. Log list can be export in txt format. -
Page 26: Device
2-2. DEVICE Under Device menu, Device configuration options for Camera, Audio, Alarm, Keyboard and RS232 & RS485 (POS/PTZ) can be selected. 2-2-1. MENU > DEVICE > Camera Set Camera display option. Camera display (video loss display) can be disabled by unmarking the box next to it if there is no camera connected. -
Page 27: Menu > Device > Audio
Covert Setting Covert setting allows the privacy on monitoring. If Covert is set, live image will not be displayed. Covert can be scheduled by day, time and mode by cameras. Covert Low Mode: No display of video image on screen but OSD still remains on screen. Covert High Mode: Neither of video image or OSD will be displayed on screen. -
Page 28: Menu > Device > Keyboard
2-2-4. MENU > DEVICE > Keyboard Press to find and select keyboard from the list. 2-2-5. MENU > DEVICE > RS232 & RS485 Press to select a device for each ports. RS232: Supports Text In (POS) device. PTZ and Keyboard RS485: Supports Text In (POS) device ,PTZ and Keyboard. -
Page 29: Display
2-3. DISPLAY Under Display menu, Display configuration options for OSD and Monitor can be selected. 2-3-1. MENU > DISPLAY > Display Language: Select system language. Press to find available language options. Hide Status Bar: Select On/Off and time to hide Status Bar when system is not in use. OSD margin: Set OSD margin (position) using Freeze: Display an image in either Field or Frame format when it is in still (freeze) mode. -
Page 30: Record
2-4. RECORD Under Record menu, Record configuration options for Storage, Record and Record Tools can be selected. 2-4-1. MENU > RECORD > Storage In Storage, it displays the installed/connected storage status such as Capacity, Type, Usage and Status. Format: Press Format to format selected HDD. Record: Displays the recording period and data stored on HDD. -
Page 31: Menu > Record > Record
2-4-2. MENU > RECORD > Record In Record, general recording options can be selected including overwrite, resolution, speed, recording quality and etc. Overwrite: Select Overwrite to overwrite recorded HDD data when it is full. Audio Record: Select Audio Record to record audio with video image. Resolution: Select recording resolution. -
Page 32: Menu > Record > Record Tools
Use Default Setting: Check Use Default Setting to follow main recording setting under Record menu. 2-4-3. MENU > RECORD > Record Tools In Recording Status, current recording options and status are displayed. -
Page 33: Network
2-5. NETWORK Under Network menu, Network configuration options for network Address, DDNS, Remote Notification and Transmission can be set up. 2-5-1. MENU > NETWORK > Address In Address, Information such as Type, IP address, Subnet Mask, Gateway Port and DNS can be set for network connections. -
Page 34: Menu > Network > Notification
2-5-3. MENU > NETWORK > Notification In Callback, set up IP addresses of client sites so that Events detected in local system can be notified to multi remote client sites simultaneously. Enter IP addresses of client sites to receive events notifications on remote sites. -
Page 35: Event
2-6. EVENT Under Event menu, events can be set in synchronization with Sensor, Motion, Video Loss, Text-In, System, 2-6-1. MENU > EVENT > Sensor In Sensor, each sensor can be selected for activation and its type. Select Sensor Type using button. -
Page 36: Menu > Event > Motion
PTZ can be sync with Event using its preset function. If Event occurs, PTZ moves to the position where event and positions are pre set. The above menu shows, Sensor 1 is set to sync to cameras 1,2. If you click PTZ section, PTZ preset (position) can be set for cameras in the event of Sensor activation. - Page 37 In Record, each camera can be synchronized with single and multi motion detections from other cameras. Press to select cameras to be synchronized with motions detections. In Alarm, each camera with motion can be synchronized with single and multi alarms. Press to select alarms to be synchronized with cameras for motion events.
-
Page 38: Menu > Event > Video Loss
2-6-3. MENU > EVENT > Video Loss In Video Loss, single or multi cameras can be synchronized for event recording when there is a video loss. Press to select single or multi cameras to be synchronized with cameras for video loss. In Alarm, each camera with video loss can be synchronized with single and multi alarms. -
Page 39: Menu > Event > Text-In
2-6-4. MENU > EVENT > Text-In The system allows Text In from POS/ATM machines. Note : For use of POS/ATM, the system must support general ASCI code. Text-In Model: Select Text-In model from the list Transaction Begin: Enter a word which the transaction info to be displayed on screen as a start. Any Character: Check Any Character to start display a text with any character as a start. -
Page 40: Menu > Event > System
In Notification, text event can be synchronized with single and multi callback or emailing sites. Press to enter callback or email address to be synchronized with text event. 2-6-5. MENU > EVENT > System In System, S.M.A.R.T function monitors storage conditions such as Temperature, Conditions and Recording. -
Page 41: Menu > Event > G-Sensor
2-6-6. MENU > EVENT > G-Sensor Built-in G-Sensor, it detects, Quick Start, Quick Stop and Traffic Accident. It allows to associate with Recording, Alarm and Event Notification using detected information. Use G-Sensor : Enable or Disable to use G-Sensor Sensitivity : Setup the sensitivity of G-Sensor. There are five level of Sensitivity. Record: Associate with G-Sensor, select the camera that you will record. -
Page 42: Playback
3. Playback The system provides various playback menu to search recorded data. Please press right mouse button on mouse or press playback button on the front panel. Note : To see the GPS information during playback, Contextual Menu -> Text Data -> Select GPS Info. -
Page 43: Event Search
detail display of recorded data please press Detail. Once desired settings are completed, press Go To to begin playback. 3-3. Event Search Event Search provides easy search by event list recorded. Select the date and type of event to find specific data. Press Event: All section on the tope of the list to display event search options. All: System displays every event Motion: System displays every events related to Motion Sensor: System displays every events related to Sensor... -
Page 44: Backup Data Playback
3-5. Backup Data Playback Backup files on backup medias can be played on DVR. Insert the media with backup files and select a file to playback it on DVR. 3-6. Playback Control R.Play: Reverse Playback Step Backward: Go to the previous image Pause: Freeze or Stop current image Step Forward: Go to the next image Play: Play the data at normal speed... -
Page 45: Backup
4. Backup 4-1. Backup In the BACKUP, the recorded data can be selected for backup to USB devices. Press USB Device to select the type of USB Device connected to the system. Select date & time period of data to be backup using button. -
Page 46: Instant Backup
4-2. Instant Backup Press backup button to start Instant Backup during the playback. Instant Backup window will appear when press backup button during the normal playback mode. Select Device, File Name, Audio and press Start to continue the playback and backup. The Backup Icon will appear on the screen during the Instant Playback. -
Page 47: Chapter 4. Remote Software Nemon
Chapter 4. Remote Software NEMON 1. Using NEMON 1-1. Starting the Software Double click on ‘Nemon2’ icon on PC to run the software. Main screen of the remote software appears as shown below. Note : A minimum resolution should be more than 1024 x 620; and a recommendable one is over 1280 x 1024. - Page 48 Change Display Page: Change Display Mode to Previous or Next page in camera order. Voice Transmission: Click button to transmit remote voice to the local DVR. Screenshot: Capture the current screen and save it as a image file. Sequence: Display images on pre selected sites in sequence mode. Setup: To change set up on Nemon S/W or a remote DVR.
-
Page 49: Site Set Up
1-2. Site Set Up Click Connect button to display registered remote locations or add new locations. Click button to add remote location and required information. Name: Enter Site Name Address: Enter IP address or domain name of the site Port: Enter port number if there is a specific port to be set for the software Description: Enter the description of the site Auto Login: If do not want the Log In window to be popped up every time starting the remote S/W, check Auto Login to skip User/Password authentication process... - Page 50 Click to save information and complete the registration. Double click the location or Highlight it and click Connection button to get connected to the site. The DVR and Client program on PC start searching each other once they are on the same local network.
-
Page 51: Favorite Set Up
Note : Auto Detecttion finds DVRs on the local network automatically. To use this function, Apple® Bonjour® needs to be installed in PC. Please refer to http://www.apple.com/bonjour for more details and download. 1-3. Favorite Set Up Favorite function allows multi site management. Up to 64 different cameras and sites can be monitored and managed on one screen. -
Page 52: Site List Panel
1-3. Site List Panel The remote sites also can be registered on Site List Panel. Use EDIT REMOVE buttons on the bottom to register and managed the remote sites and favorite sites. Drag and Drop the listed sites on to the display section to connect the sites. Each camera can be dragged and dropped to arrange independent displays. -
Page 53: Tool Panel
1-4. Tool Panel 1-4-1. PTZ The first tap of Tool Panel is PTZ controller. Once DVR is connected in Live mode and select the PTZ view CH, it will display the site info and activate the PTZ controllers. Set Preset: Save PTZ camera’s current location. -
Page 54: Text-In
1-4-3. TEXT-IN Displays recorded TEXT-IN info. TEXT-IN tap is activated under playback mode only. 1-4-4. GPS GPS is for Mobile DVR tracking under playback mode. GPS data is recorded with images using built in GPS on Mobile DVR. This data will be displayed on Google Map under playback mode. -
Page 55: Remote Playback
2. Remote Playback 2-1. Calendar Search Calendar Search Panel appears when a site is connected under playback mode as shown below. Time bar will appear once the date is selected and the image preview will appear when the specific time is selected on the time bar. Fold Calendar Search Panel Calendar Search Use below buttons to control the playback image. -
Page 56: Event Search
2-2. Event Search Select Event Search on the bottom of the screen to open Event Search Panel. Enter Date, Event Type and etc and select SEARCH button to retrieve the search results. Fold Event Search Panel Event Search Select an event from the list for playback. Search trough the list using < > buttons. Select the date of event search for from the Date list. -
Page 57: Text-In Search
3-3. Text-In Search Select Text-In Search on the bottom of the screen to open TEXT-IN Search Panel. Enter Date and Text and select SEARCH button to retrieve the search results. Fold Text-In Search Panel Text-In Search Select an text-in event from the list for playback. Search trough the list using < > buttons. -
Page 58: Saving The Recorded Data
3-4. Saving the recorded data Screenshot Select button to capture the current image during the playback as show below. Select Save... button to save the image. The Image can be saved in JPEG, BMP and PNG format. Save as MP4 Select button during the playback and select “Save as MP4”... -
Page 59: Play Backup Data
Backup Select button during the playback and select “Backup” to open the window as shown below to save data in own video format. • Enter file name and select Location. • Select the time period. • Select Camera number. Press Start to create Backup file. 3-5. -
Page 60: Play Independent Hdd Data On Pc
3-6. Play Independent HDD Data on PC Independent HDD (removed from a DVR) data can be played on PC using Nemon S/W. Have the HDD connected to PC using a SATA to USB connector cable. Make sure the HDD is connected to PC properly Select button during the playback. -
Page 61: Setup
4. Setup 4-1. Nemon Setup Click on Setup to enter Nemon setup menu. Product: Displays general information of the S/W Software Version: Displays current S/W version Secondary Monitor: Select the secondary monitor when using multi monitors on PC Reconnect Automatically: Set auto reconnection on Live if the connections is ended by any chances. - Page 62 Click on Display tap to enter display setup menu. Maintain Aspect Ration (4:3): Keep 4:3 ration on Nemon display screen Use Alpha-Blending: Enables alpha-blending effect to S/W UI Video Acceleration: Video Acceleration option enhances natural live image display on the client S/W.
- Page 63 Click on Sequence tap to enter sequence setup menu. Set sequence mode and sequential sites from registered individual or Favorite sites. Click the site and select > button to add the site into the sequencing list. >> button will move the all sites to into the sequencing list.
- Page 64 Click on User tap to enter user setup menu. Register Nemon Software users. Each user needs to use the password they set in registration when they log in. Select Add to start new user registration.
-
Page 65: Remote Setup
4-2. Remote Setup Click on Remote Setup to enter remote setup menu. Select a DVR for setup and select Connection button. Setup menu will appear as show below once it is connected Note : The remote software provides interactive setup system that allows easy local DVR settings from remote sites. -
Page 66: Remote Upgrade
4-3. Remote Upgrade The system upgrade can be done through Nemon program on PC. • Click on Remote Setup to enter remote setup menu. • Select Information under System. • Click Upgrade next to S/W version to find a file for upgrade •... -
Page 67: Nemon Callback
5. Nemon Callback Start-> Program -> Nemon2 -> Nemon Callback2 Nemon Callback icon will be displayed on the bottom right of Window once the program starts. Callback message will be displayed/notified as shown above. Click Nemon Callback icon to display main window of Callback as shown below. - Page 68 Select a log from the list and click Live or Playback icon image to connect related DVR. Clear: Clear all the logs listed on Nemon Callback window Log: Click Log button to display log search window as shown below. Up to 100,000 log can be saved. 1,000 log lists will be displayed per search. Click More button to display next 1,000 logs.
-
Page 69: Appendix A. Remote Access Using I.e
Appendix A. Remote Access Using I.E. DVR can be accessed remotely using Internet Explore. Execute internet explore program and enter DVR address (e.g. IP) to get connected. Remote Log In page appears once connected to DVR. Enter ID, PW and Port information, and select Live or Playback mode to display desired remote control option. -
Page 70: Appendix B. How To Set Ddns Using Router
Appendix B. How to set DDNS using router (Except using public IP or connect with ADSL directly) Make it easy to understand through the example as below. Please refer the Diagram and follow this instruction. For example, If you connect 3 DVRs through local Network. DVR 1 Public IP : 203.208.1.150 IP: 192.168.1.10... - Page 71 - Fill out the registration information as below. - Click ‘Submit’ to make the account. - Enter your domain name and click ‘Request Domain’ to create the domain name. - You can see the registered dome name “dvr1.dvr-ddns.com”...
-
Page 72: Router Configuration
- You can create 3 domain names for one account. - Click “Create additional domain names” to make another domain name. 2. Router Configuration - Insert the gateway address on the explorer to connect the homepage for the Router. - Go to “Port Forwarding” Menu. (The picture below is for particular Router.) - Please insert the IP address and Port number for DVR in the Port Forward menu. -
Page 73: Dvr Configuration
3. DVR Configuration Example of DVR Network setting. Select Static IP option and enter following options accordingly. The system should be allocated with individual IP address. Make sure the ports for DVR are all set accordingly or set network ports according to DVR port settings. -
Page 74: Compliance Notice Of Fcc
COMPLIANCE NOTICE OF FCC: THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES. THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A COMMERCIAL ENVIRONMENT.
