Summary of Contents for Cerio DT-200N
- Page 1 User’s Manual DT-200N Wireless N-Series Streamlining Router CERIO Corporation DT-200N Wireless N-Series Streamlining Router User’s Manual V1.2...
-
Page 2: Table Of Contents
Package Contents..........................4 Hardware Installation ...........................5 System Requirement ........................5 Hardware Installation Procedures.....................5 Login ..............................6 Configure your PC/NB to connect with DT-200N................6 Additional Settings for Wireless Client ....................13 Checking PC’s IP and Connection with the Router ................13 Login to DT-200N ........................14 System configuration..........................16 Convenient Setup. - Page 3 User’s Manual DT-200N Wireless N-Series Streamlining Router Product Specification..........................52...
-
Page 4: Introduction
This DT-200N Wireless N-Series Streamlining Router is a cost-effective IP Sharing Router that enables multiple users to share the Internet through an ADSL or cable modem. The DT-200N Wireless N-Series Streamlining Router is embedded with a IEEE 802.11b/g/n access point that allows you to build up a wireless LAN. With the support of new emerged 802.11n standard, the access point provides data transfer of up to 150Mbps, up to 6 times faster... -
Page 5: Hardware Installation
N-Series Streamlining Router. Connecting the power adapter Connect the single DC output connector of the power adapter to the power jack on the side of the DT-200N Wireless N-Series Streamlining Router. Then plug the Power Adapter into an AC outlet. -
Page 6: Login
Please make sure your network interface card configuration has been completed and activated on your operating system and connected to one of the LAN port of DT-200N through Cat.5 or Cat.5e cable. Please make sure the LED on DT-200N is already on and the LED corresponds with the port which you connected. - Page 7 User’s Manual DT-200N Wireless N-Series Streamlining Router Click Network and Internet Connections Click Network Connections Highlight the icon Local Area Connection, right click your mouse, and click Properties...
- Page 8 User’s Manual DT-200N Wireless N-Series Streamlining Router Highlight Internet Protocol (TCP/IP), and then press Properties button Choose Obtain an IP address automatically and Obtain DNS server address automatically, and then press OK to close the Internet Protocol (TCP/IP) Properties window...
- Page 9 User’s Manual DT-200N Wireless N-Series Streamlining Router Press OK to close the Local Area Connection Properties window Windows Vista Please follow the steps below to setup your computer: Go to Start Settings Control Panel Click Network and Sharing Center...
- Page 10 User’s Manual DT-200N Wireless N-Series Streamlining Router Click Manage Network Connections Highlight the icon Local Area Connection, right click your mouse, and click Properties...
- Page 11 User’s Manual DT-200N Wireless N-Series Streamlining Router Highlight Internet Protocol Version 4 (TCP/IP) and then press Properties button Choose Obtain an IP address automatically and Obtain DNS server address automatically, and then press OK to close the Internet Protocol (TCP/IP) Properties window...
- Page 12 The "Windows Command-Line" will show you the "Network Interface Card" information in the window, please take notice of the value of "IP Address" and "Default Gateway". The value of "Default Gateway" is the IP address of DT-200N. Linux / Unix-Like At first please make sure that your NIC are already enable and works property.
-
Page 13: Additional Settings For Wireless Client
After configuring the TCP/IP protocol, use the ping command to verify if the computer can communicate with the Router. To execute the ping command, open the DOS window and ping the IP address of the DT-200N Wireless N-Series Streamlining Router at the DOS prompt: For Windows 98/Me: Start ->... -
Page 14: Login To Dt-200N
WEB browser installed. Please follow up the steps listed below. 3.4 Login to DT-200N Now, we will going to setup DT-200N through your WEB browser that installed on your PC/NB, please do as follow: Startup Internet Explorer and enter http://192.168.1.254, then press Enter... - Page 15 Internet illegally. After successful login, in the home page of the DT-200N, the left navigation bar shows the main options to configure the system. In the right navigation screen is the summary of system status for viewing the...
-
Page 16: System Configuration
User’s Manual DT-200N Wireless N-Series Streamlining Router 4 System configuration 4.1 Convenient Setup Providing you the convenient and simplest method for configure the router, the purpose of this item is to provide an easy way for you to use it and configure your router to access the Internet quickly; including “DHCP”, ”PPPoE”, ”Static IP”... - Page 17 User’s Manual DT-200N Wireless N-Series Streamlining Router PPPoE user (ADSL) If your ISP provides you the PPPoE service (all ISP with DSL transaction will supply this service, such as the most popular ADSL technique), please select this item. In the “Convenient configuration” You can input your PPPoE username and password to access the Internet.
- Page 18 User’s Manual DT-200N Wireless N-Series Streamlining Router Static User This item should only be used when users use a static IP address to access Internet, you should input your “WAN IP address”, ”subnet mask”,” default gateway” and “DNS server (domain name server) IP address”...
-
Page 19: System Information
User’s Manual DT-200N Wireless N-Series Streamlining Router The SSID is your wireless network's name shared among all points in a wireless network. The SSID must be identical for all devices in the wireless network. It is case-sensitive and must not exceed 32 characters. - Page 20 User’s Manual DT-200N Wireless N-Series Streamlining Router field is blank. Subnet Mask The Subnet mask you obtained after connect to the Internet, if you haven’t connected to Internet yet, this field is blank Default Gateway The IP address of Default gateway you obtained after connect to the Internet, if you haven’t connected to Internet yet, this field is blank.
- Page 21 User’s Manual DT-200N Wireless N-Series Streamlining Router Primary AP Info Wireless status Display wireless interface status is enabled or not Number of Wireless Client Display the current number of wireless stations associated with router Wireless Mode Current wireless mode of wireless router ，the default setting is “AP(Access Point)” mode.
- Page 22 User’s Manual DT-200N Wireless N-Series Streamlining Router System Info This item provides current running information of System Statistics Info This item provides statistics information about the bits router sends and received...
-
Page 23: System Log
User’s Manual DT-200N Wireless N-Series Streamlining Router 4.3 System log Examine system log, there are most ten logs can be showed in one Page... -
Page 24: Internet Setup
User’s Manual DT-200N Wireless N-Series Streamlining Router 4.4 Internet Setup The purpose of this item is to provide an easy way for you to use it and configure your router to access the Internet quickly, DHCP User (Cable Modem) After select this item, you will obtain an IP address from your ISP automatically, those ISP who supply Cable... - Page 25 User’s Manual DT-200N Wireless N-Series Streamlining Router PPPoE User(ADSL) If your ISP provides you the PPPoE service (all ISP with DSL transaction will supply this service, such as the most popular ADSL technique), please select this item. In the “Convenient Setup” You can input your PPPoE...
- Page 26 User’s Manual DT-200N Wireless N-Series Streamlining Router You can select three modes: connect to Internet automatically (Default), auto disconnect when idle or time out, connect to Internet manually Static user This should be used only you are connecting through a static IP address. You should input your “WAN IP address”, ”subnet mask”,”...
-
Page 27: Wireless Management
You can select radio mode of wireless router, the default setting is AP mode SSID You can input the wireless network name of “DT-200N” here, The default value is “default” SSID Broadcasting You can choose “enable” or “disable” to enable or disable the “SSID broadcasting”... - Page 28 User’s Manual DT-200N Wireless N-Series Streamlining Router problems. 40MHz: Setting the Router to this mode allows only 40MHz operation. This mode is compatible only with router, draft 802.11n compliant devices. It may affect legacy 802.11b/g devices. Use only when you have a pure router, draft 802.11n wireless network...
- Page 29 WPA-PSK or WPA2-PSK If you want to extend your wireless coverage and you also have two DT-200N, you can combines two DT-200N into same subnet with same SSID, channel, subnet and add both MAC address of your router to extend your wireless signal.
- Page 30 User’s Manual DT-200N Wireless N-Series Streamlining Router Host Filter You can filter wireless users by enabling this function; thus unauthorized users can not access the network. To disable “Wireless Host Filter”, keep the default setting “Disable”. To enable “Wireless Host Filter”, follow these steps to set “Wireless Host Filter”.
- Page 31 By default, the WPS function will enabled, DT-200N will help you to set a SSID and WPA-PSK encryption automatically, to connect wireless network card and router through WPS function, please follow below step to...
- Page 32 If you using a wireless adapter connected to a computer, “WPS authentication” screen will appear. Wait until the screen show up “Authentication successful.” This procedure may take a few minutes. Once WPS connection successful, please try to check your wireless connect status to make sure you also got an IP address from DT-200N.
- Page 33 For many adapters the WPS button will flash. Make sure to press the button within 120 seconds (2 minutes) after pressing the DT-200N “connect” button. If you using a wireless adapter connected to a computer, “WPS authentication” screen will appear. Wait until the screen show up “Authentication successful.”...
- Page 34 Select “Shared Key” if you only want to use “Shared Key” authentication (the sender and recipient use a WEP key for authentication) Beacon Interval The interval time of this DT-200N Wireless N-Series Streamlining Router broadcast a beacon. Beacon is used to synchronize the wireless network. The valid interval is 20-1000, the default is 100...
-
Page 35: Lan Setup
DHCP server, set the range of DHCP address pools LAN IP address The IP address is for LAN port that connect by your PC/NB with DT-200N directly; here you can set IP address you need. and default IP address is 192.168.1.1, the default subnet mask is 255.255.255.0. -
Page 36: Applications And Gaming
User’s Manual DT-200N Wireless N-Series Streamlining Router DHCP Server DHCP Server Status Keep the default setting “Enable”, so router is able to use DHCP function. If a DHCP server has already existed in the network, please select “Disable”. IP Address Pool The IP Address pool is used for allocate IP address by DHCP server;... - Page 37 User’s Manual DT-200N Wireless N-Series Streamlining Router Protocol The protocol item supplies several protocols. For example, if you have web server within LAN, you can select the HTTP template then the router will input port number 80 automatically External Port...
-
Page 38: Application Gateway
User’s Manual DT-200N Wireless N-Series Streamlining Router 4.8 Application gateway VPN Pass-through VPN is commonly used for encapsulate and encrypt data across the public network. For VPN tunnel, the router supports IPSEC pass-through, PPTP pass-through and L2TP pass-through PPTP Pass-through PPTP means the “Point to Point Tunneling Protocol”, you can select “enable”... -
Page 39: Security Management
User’s Manual DT-200N Wireless N-Series Streamlining Router 4.9 Security management This feature provides security and network protection by using “Internet access control”, “Firewall” and some other options MAC Filter You can filter wired users by enabling this function; thus unauthorized users can not access the network. Follow these steps to set MAC filter: Add MAC address you want to control in the “MAC address”... - Page 40 User’s Manual DT-200N Wireless N-Series Streamlining Router Internet Access Control The rules of “Internet access control” based on source IP, port number and protocol. Follow these steps to set Internet Access Control: You can select “Default IP Firewall Rule” and click “Save Settings” to enable “Internet Access Control”...
-
Page 41: Dns Filter
User’s Manual DT-200N Wireless N-Series Streamlining Router DNS Filter “DNS filter” is able to filter certain domain name such as www.sina.com Follow these steps to set DNS filter: You can select “Default DNS filter rule” and click “Save Settings” to enable “DNS Filter” function. This is only the first step, you should continued to create appropriate rules for “DNS Filter”. -
Page 42: Ddns
After register an DDNS account from DDNS service providers, you will get “User Name”, “Password”, ”Dynamic Domain Name”, Input information in appropriate field Status If your account and other information is correct, the DT-200N will try to connect with the DDNS service provider that you specify, here will show you the connect status. -
Page 43: Routing
User’s Manual DT-200N Wireless N-Series Streamlining Router 4.11 Routing Most of broadband router and wireless router are using NAT mode, so this feature is designed for most common network environment Destination Network or IP Address Specify a certain destination Network or IP address which static route forward to... -
Page 44: System Management
Web Setup This function will allow you login to DT-200N Web management page from remote side, by default DT-200N will not allow you login as your global IP address (WAN side IP address) from remote for security reason. If you want to enable this function please choice “Enable”... - Page 45 User’s Manual DT-200N Wireless N-Series Streamlining Router Restart system Click” Restart System” button to restart the router Restore default Click "Restore Default" button, the Router will erase all of your settings and replace them with the factory defaults, make sure you have backup current settings before click this button Wake up PC Input host MAC address, and then click button of "Wake up"...
-
Page 46: How To Extend Your Wireless Coverage With Wds
User’s Manual DT-200N Wireless N-Series Streamlining Router 5 How to extend your wireless coverage with WDS 5.1 Introduction WDS (Wireless Distribution System) creates a wireless backbone link between multiple Wireless APs. This allows a wired network to be expanded using Wireless APs without a wired backbone to link them. Separated wired networks (e.g. -
Page 47: Howto
User’s Manual DT-200N Wireless N-Series Streamlining Router 5.3 HowTo Please follow the next steps, you’ll find the configuration is rater easy: Mary uses the AP that the IP address is 192.168.1.254 and the MAC address is 00:02:10:09:00:45, refer to Picture 2 and Picture 3. Jane uses the AP that the IP address is 192.168.1.200 and the MAC address is 08:10:74:82:ca:62, refer to Picture 4 and Picture 5. - Page 48 User’s Manual DT-200N Wireless N-Series Streamlining Router Picture 4 Picture 5...
- Page 49 User’s Manual DT-200N Wireless N-Series Streamlining Router They both need to select WDS or AP+WDS as the radio mode, and select the same channel, refer to Picture 6 Picture 6 For Mary, she should enter the AP’s MAC address of Jane and enter description for WDS mode (the description may be the same, but they had better configure a different one for distinguish), and then click add, the current wireless bridge information will appear in the list, refer to Picture 5 and Picture 6.
- Page 50 User’s Manual DT-200N Wireless N-Series Streamlining Router Picture 8 Picture 9...
- Page 51 User’s Manual DT-200N Wireless N-Series Streamlining Router Picture 10 Then the configuration of WDS mode is successful...
-
Page 52: Product Specification
User’s Manual DT-200N Wireless N-Series Streamlining Router 6 Product Specification Hardware Specifications Wireless Radio 802.11nbg Antenna 2dBi Antenna Standards Conformance IEEE 802.11b, IEEE 802.11g, IEEE 802.11n IEEE 802.11e, IEEE 802.11h, IEEE 802.11k, IEEE 802.11i, IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX... -
Page 53: Industry Canada Statement
(e.g., cordless telephones and microwaves) as well as network overhead lower actual data throughput rate. Specifications are subject to change without notice. All products and trademarks are the property of their respective owners. Copyright ©2009 CERIO Corporation®...
