Kortex KX EASYBACKUP User Manual

Wireless wan mobile broadband router
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
KX EASYBACKUP
Wireless Wan Mobile
Broadband Router
User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KX EASYBACKUP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kortex KX EASYBACKUP

Summary of Contents for Kortex KX EASYBACKUP

  • Page 1 KX EASYBACKUP Wireless Wan Mobile Broadband Router User Guide...

  • Page 2: Fcc Interference Statement

    Copyright The contents of this publication may not be reproduced in any part or as a whole, stored, transcribed in an information retrieval system, translated into any language, or transmitted in any form or by any means, mechanical, magnetic, electronic, optical, photocopying, manual, or otherwise, without the prior written permission.

  • Page 3: Table Of Contents

    Table of Contents FCC Interference Statement ..................2 System Requirements for Configuration ............... 4 Introduction......................4 1.1. Connections ..................4 1.1.1. Wireless WAN Mobile Broadband Router (Rear View) ..4 1.1.2. LEDs– Wireless WAN Mobile Broadband Router (Front View) ........................5 1.2.

  • Page 4: System Requirements For Configuration

    Package Contents Importance: Check your product package contents FIRST. The Wireless WAN Mobile Broadband Router package should contain the items listed below. If any of the items are missing, please contact your reseller. Description Quantity Wireless WAN Mobile Broadband Router RJ-45 Cable Power adapter 5V 3.0A Quick Installation Guide...

  • Page 5: Leds- Wireless Wan Mobile Broadband Router (Front View)

    Antenna Receptor for Power adapter Reset Button Restore to Original factory defaulted setting Auto MDI/MDIX RJ-45 Ports Automatically sense the types of WAN and LAN when connecting to Ethernet Note: Contains a reset button to restore the setting back to original factory defaulted setting as if your convenience of forgetting your applicable setting 1.1.2.

  • Page 6: Features

    Type II PC card slot Insert the 3G PC card as 3G WAN connection is needed WiFi LED A green light as connection on WLAN available WAN LED Power LED LAN LED A green light as A green light as A green light as connected WAN is connected power is on and...

  • Page 7: Configuring Wireless Wan Mobile Broadband Router

     Connects multiple computers to a Broadband either WCDMA or EV-DO even HSDPA modem to share the Internet connection. Note: The Wireless WAN Mobile Broadband Router is designed to work with either EVDO or WCDMA (UMTS) even up to 3.5G HSDPA PC cards. Please refer to your service provider for detailed feature information.
  • Page 8 a. Screw the antenna in a clockwise direction to the back panel of the unit. b. Once secured, position the antenna upward at its connecting joint. This will ensure optimal reception. 2. Connect a compatible Type II 3G cards with service to the Wireless WAN Mobile Broadband Router in one of the following ways: -...

  • Page 9: Establish Wifi Connection

    Picture 2.3 The Wireless WAN Mobile Broadband Router LAN Port is Note: “Auto-MDI/MDIX.” This provides patch Ethernet cable LAN Port access. 4. Connect the power adapter to the receptor on the back panel of your Wireless WAN Mobile Broadband Router. Then plug the other end of the power adapter into a wall outlet or power strip a.

  • Page 10: Wizard Setting

    2. Type in the IP Address http://192.168.123.254 ) of the Wireless WAN Mobile Broadband Router If you have changed the IP Address assigned to the Wireless WAN Mobile Note: default Broadband Router, ensure you enter the correct IP Address 3. Type “ admin”...
  • Page 11  Click on “Enter” button to get start. With wizard setting steps, you could configure the router in a very simple way. This configuration wizard includes settings of Login Password, WAN Setup Wireless Setup, Press “Next” button to start configuration. Step 1: Allow you to change the system password.
  • Page 12 You can change Password here. It is recommended that you change the system password into the one you prefer to on the basis of security 1. Key in your Old Password ( if it is the first initiation, the “ admin” will be the defaulted one.
  • Page 13 Pick up one of types you preferred to. 1. Click on “ Next” button Step 3：Configure the LAN IP Address, Host Name and WAN MAC Address. LAN is short for Local Area Network, and is considered your internal network. These are the IP settings of the LAN interface for the Wireless WAN Mobile Broadband Router, and they may be referred to as Private settings.
  • Page 14 address if needed. The LAN IP address is private to your internal network and cannot be seen on the Internet. There are 254 addresses available on the Wireless WAN Mobile Broadband Note: Router when using a 255.255.255.0 (Class C) subnet. Example: The router's IP address is 192.168.123.1.
  • Page 15 Click on ” Next” to continue. Step 6: Summary Click on the “Apply Settings” button Step 7: System is applying.

  • Page 16: Advanced Setup > Basic Setting

    Clicking “Finish” button to back to Status Page 2.2.2. Advanced Setup > Basic Setting 1. LAP IP Address: the local IP address of this device. The computers on your network must use the LAN IP address of your product as their Default Gateway. You can change it if necessary.
  • Page 17 Select the WAN types you prefer to get on the internet connection The WAN fields may not be necessary for Caution: For 3G WAN Networking. your connection. The information on this page will only be used when your service provider requires you to enter a to connect to User Name Password...
  • Page 18 1. DHCP Server: Choose either Disable or Enable 2. Lease Time: DHCP lease time to the DHCP client 3. IP Pool Starting/Ending Address: Whenever there is a request, the DHCP server will automatically allocate an unused IP address from the IP address pool to the requesting computer.
  • Page 19  Wireless - Enabled is the default. Selecting this option will allow you to set your Wireless Access Point (WAP) settings.  WMM Capable- Choose Enable or Disable WMM function  Service Set Identifier (SSID) is the name designated for a specific wireless SSID- local area network (WLAN).
  • Page 20 Key. 5: Click on “Save” to store you just select Advanced Setup > Basic Setting > Change Password You can change Password here. We strongly recommend you to change the system password for security reason. Click on “Save” to store what you just select or “Undo” to give up Advanced Setup >...
  • Page 21 This product’s NAT firewall filters out unrecognized packets to protect your Intranet, so all hosts behind this product are invisible to the outside world. If you wish, you can make some of them accessible by enabling the Virtual Server Mapping. A virtual server is defined as a Service Port, and all requests to this port will be redirected to the computer specified by the Server IP.
  • Page 22 Some applications require multiple connections, like Internet games, Video conferencing, Internet telephony, etc. Because of the firewall function, these applications cannot work with a pure NAT router. The Special Applications feature allows some of these applications to work with this product. If the mechanism of Special Applications fails to make an application work, try setting your computer as the DMZ host instead.
  • Page 23 IP Address of DMZ Host DMZ (Demilitarized Zone) Host is a host without the protection of firewall. It allows a computer to be exposed to unrestricted 2-way communication for Internet games, Video conferencing, Internet telephony and other special applications. Click on “Save” to store what you just select or “Undo” to give up NOTE: This feature should be used only when needed.
  • Page 24 Packet Filter enables you to control what packets are allowed to pass the router. Outbound filter applies on all outbound packets. However, inbound filter applies on packets that destined to Virtual Servers or DMZ host only. You can select one of the two filtering policies: 1.

  • Page 25: Inbound Filter

    example, T80, U53, U2000-2999, No prefix indicates both TCP and UDP are defined. An empty implies all port addresses. Packet Filter can work with Scheduling Rules, and give user more flexibility on Access control. For Detail, please refer to Scheduling Rule. Each rule can be enabled or disabled individually.
  • Page 26 Domain Filter let you prevent users under this device from accessing specific URLs. Domain Filter Enable Check if you want to enable Domain Filter. Log DNS Query Check if you want to log the action when someone accesses the specific URLs. Privilege HOST/ Netmask Setting a group of hosts and privilege these hosts to access network without restriction.
  • Page 27 URL Blocking will block LAN computers to connect to pre-defined Websites. The major difference between “Domain filter” and “URL Blocking” is Domain filter require user to input suffix (like .com or .org, etc), while URL Blocking require user to input a keyword only. In other words, Domain filter can block specific website, while URL Blocking can block hundreds of websites by simply a keyword.
  • Page 28 MAC Address Control Check “Enable” to enable the “MAC Address Control”. All of the settings in this page will take effect only when “Enable” is checked. Connection control Check "Connection control" to enable the controlling of which wired and wireless clients can connect to this device. If a client is denied to connect to this device, it means the client can't access to the Internet either.
  • Page 29 administration task. This feature enables you to perform administration task from remote host. If this feature is enabled, only the specified IP address can perform remote administration. If the specified IP address is 0.0.0.0, any host can connect to this product to perform administration task. You can use subnet mask bits "/nn" notation to specified a group of trusted IP addresses for example, "10.1.2.0/24".
  • Page 30 Advanced Setup > Advanced Setting > Routing I/F by IP The Routing Interface by IP allows you to specify what range of IPs of packets to be delivered to Internet via which session of connection Click on “Save” to store what you just select or “Undo” to give up...
  • Page 31 Advanced Setup > Advanced Setting > Routing I/F by Domain The Routing Interface by Domain allows you to specify what range of domains of packets to be delivered to Internet via which session of connection Click on “Save” to store what you just select or “Undo” to give up...
  • Page 32 Advanced Setup > Advanced Setting > System Log This page support two methods to export system logs to specific destination by means of syslog (UDP) and SMTP(TCP). The items you have to setup including: IP Address for Syslog Host IP of destination where syslog will be sent to. Check Enable to enable this function.
  • Page 33 Advanced Setup > Advanced Setting > Dynamic DNS To host your server on a changing IP address, you have to use dynamic domain name service (DDNS). So that anyone wishing to reach your host only needs to know the name of it. Dynamic DNS will map the name of your host to your current IP address, which changes each time you connect your Internet service provider.
  • Page 34 Host Name Username/E-mail Password/Key You will get this information when you register an account on a Dynamic DNS server. Click on “Save” to store what you just select or “Undo” to give up...
  • Page 35 Advanced Setup > Advanced Setting > SNMP In brief, SNMP, the Simple Network Management Protocol, is a protocol designed to give a user the capability to remotely manage a computer network by polling and setting terminal values and monitoring network events. Enable SNMP You must check either Local or Remote or both to enable SNMP function.
  • Page 36 Advanced Setup > Advanced Setting > Routing Routing Tables Allow you to determine which physical interface address to use for outgoing IP data grams. If you have more than one routers and subnets, you will need to enable routing table to allow packets to find proper routing path and allow different subnets to communicate with each other.
  • Page 37 Advanced Setup > Advanced Setting > System Time Get Date and Time by NTP Protocol Selected if you want to Get Date and Time by NTP Protocol. Time Server Select a NTP time server to consult UTC time Time Zone Select a time zone where this device locates.
  • Page 38 Advanced Setup > Advanced Setting > Scheduling You can set the schedule time to decide which service will be turned on or off. Select the “enable” item. Press “Add New Rule” You can write a rule name and set which day and what time to schedule from “Start Time” to “End Time”. The following example configure “ftp time”...
  • Page 39 Advanced Setup > Advanced Setting > Performance Beacon Interval Beacons are packets sent by an Access Point to synchronize a wireless network. Specify a Beacon interval value between 1 and 1000. The default value is set to 100 milliseconds. DTIM interval： Enter a value between 1 and 65535 for the Delivery Traffic Indication Message (DTIM).
  • Page 40 Advanced Setup > Tool Box > System Info You can view the System log, Routing Table information in this page...
  • Page 41 Advanced Setup > Tool Box > Firmware Upgrade You can upgrade firmware by clicking Firmware “Upgrade” button Advanced Setup > Tool Box > Backup Setting You can backup your settings by clicking the Backup Setting button and save it as a bin file.
  • Page 42 Advanced Setup > Tool Box > Miscellaneous MAC Address for Wake-on-LAN Wake-on-LAN is a technology that enables you to power up a networked device remotely. In order to enjoy this feature, the target device must be Wake-on-LAN enabled and you have to know the MAC address of this device, say 00-11-22-33-44-55.

  • Page 43: Troubleshooting

    3. Troubleshooting This section provides an overview of common issues, and possible solutions for the installation and operation of the Wireless WAN Mobile Broadband Router. 1. Unable to access the Configuration Menu when I use my computer to configure the router.
  • Page 44 Ensure the IP Address assigned to the wireless adapter is within the same subnet as the Access Point and gateway. The Wireless WAN Mobile Broadband Router has an IP Address of Wireless adapters must have an IP Address in the same range (e.g., 192.168.123.254.
  • Page 45 • Keep your product at least 3-6 feet away from electrical devices that generate RF noise. Examples include: microwaves, monitors, electric motors, and so forth. 5. I just do not remember my encryption key. What should I do? • If you forgot your encryption key, the WiFi card will be unable to establish a proper connection. If an encryption key setting has been set for the Wireless WAN Mobile Broadband Router, it must also be set for the WiFi card that will connect to the Wireless WAN Mobile Broadband Router.

  • Page 46: Technical Specifications

    4. Technical Specifications 3G Access 1*PC card Type II Slot supports both 16-bit and 32-bit bus rate. Standards IEEE 802.11b/g IEEE 802.3 IEEE 802.3u Wireless Standard IEEE 802.11b\g Turbo Data Rate 54, 48, 36, 24, 18, 12, 9, and 6 Mbps per channel, Auto Fall-Back 2.4 –...
