- Page 1 USER’S GUIDE Installation & Operation Instructions Tank Farm Transmitter Model TFT 32 Series 2.4 Pressure Sensor Input (-B-)
- Page 2 Note: This page has been left blank intentionally.
-
Page 3: Table Of Contents
TFT32 Tank Farm Transmitter Manual Series 2.4 INDEX Bench Test and Connections· · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 4 Calibration System ·... -
Page 4: Bench Test And Connections
Connect Sensor as shown below, then apply Power. When properly connected figures will be shown on the LCD display. Test operation of the TFT32 by applying pressure to the sensor or 4-20mA input. The TFT32 will now display level in inches or cm. - Page 5 TFT32 Tank Farm Transmitter Manual Series 2.4 LOCAL NETWORK CONNECTIONS LAST (FURTHEST) TFT IN THE NETWORK 24VDC INPUT RELAY RS485 (1 AMP) SENSOR 120 ohm DO NOT TERMINATOR CONNECT SHIELD (supplied) IMPORTANT: 6 - CONDUCTOR SHIELDED MUST CONNECT TO A 18 - 22 AWG RECOMMENDED GOOD GROUND (<1 Ohm)
- Page 6 TFT32 Tank Farm Transmitter Manual Series 2.4 DIAL-UP LOCATION CONNECTIONS LAST (FURTHEST) TFT IN THE NETWORK 24VDC INPUT RELAY RS485 (1 AMP) SENSOR 120 ohm DO NOT TERMINATOR CONNECT SHIELD (supplied) IMPORTANT: MUST CONNECT TO A 6 - CONDUCTOR SHIELDED GOOD GROUND (<1 Ohm)
-
Page 7: Calibration System
The TFT32 has a simple 2-key calibration system. Operating and calibration modes are shown on the 4 digit display. The keys are used to calibrate the TFT32, and to view operating mode and functions. If the keys are not used for 10 minutes, the TFT32 will automatically go to NORMAL MODE. Except in OUTPUT SIMULATION mode, the Relay and RS485 serial output are not affected by use of the keys until your calibration is stored. -
Page 8: Calibration Menu
Ç Press to select inches, cm, percent or blank (other units) PERCENT INCHES CM OUTPUT SPAN CALIBRATION "0=" Enter minimum reading to be displayed by the TFT32 PERCENT "100=" Enter maximum reading to be displayed by the TFT32 Ç È... -
Page 9: Calibration Units Selection
TFT32 Tank Farm Transmitter Manual Series 2.4 NORMAL MODE RELAY ON - Relay energized LEVEL OFF - Relay de-energized The TFT32 Normal Mode is always Level CALIBRATION UNITS SELECTION Press È from NORMAL mode, display will show: PERCENT INCHES Ç... -
Page 10: Output Span Calibration
TFT32 Tank Farm Transmitter Manual Series 2.4 OUTPUT SPAN CALIBRATION LEVEL (Pressure Sensor) 100= Max Level Pressure Sensor Zero Level The Display will alternate between every 3 seconds. È È Ç 1524 100= È Ç 1523 È Ç 1522 Wait for the numeric value and press Ç to enter the zero level, or minimum level of the tank. With display on 0 = press È... -
Page 11: Level Calibration
TFT32 Tank Farm Transmitter Manual Series 2.4 LOW LEVEL CALIBRATION (IN-TANK) The Display will alternate between every 3 seconds. È È Ç 208.9 209.1 È Ç 208.8 209.2 È Ç 208.7 209.3 With tank level <30% of maximum level (100=) wait for the numeric value and press Ç to enter the current tank level. - Page 12 TFT32 Tank Farm Transmitter Manual Series 2.4 SETUP EXAMPLE: PS11 Sensor in a 70” Tank Page 12...
- Page 13 TFT32 Tank Farm Transmitter Manual Series 2.4 LOW LEVEL CALIBRATION (BENCH) The Display will alternate between every 3 seconds. È È Ç 208.9 209.1 È Ç 208.8 209.2 È Ç 208.7 209.3 With sensor input OPEN (sensor not connected) wait for the numeric value and press Ç to enter the level of the sensor in the tank.
- Page 14 TFT32 Tank Farm Transmitter Manual Series 2.4 PRESSURE SENSOR CONVERSION CHART (Bench Calibration) Examples of “Bench Calibration” Calculations - PS11 sensor Example 1 - Specific gravity of tank contents is 1.5 - Sensor is mounted at a level of 6 inches - Calibration units (CALU) are in inches LO = 6.0...
-
Page 15: Relay Calibration
TFT32 Tank Farm Transmitter Manual Series 2.4 RELAY OPERATION CHOICE The TFT32’s Signal Relay can be configured to operate as: ROC1 = Level Alarm ROC2 = Level + Signal Loss Alarm Ç È È roc2 ROC3 = Signal Loss Alarm only... -
Page 16: Damping
TFT32 Tank Farm Transmitter Manual Series 2.4 Example of Relay Calibration rAn2 = 184 R ON Span (Max Level) = 184 inches ron in percent =150/184 = 81.5% 150" roFF in percent = 30/184 = 16.3% SPAN = 184" R OFF 30"... -
Page 17: Baud Rate
TFT32 Tank Farm Transmitter Manual Series 2.4 BAUD RATE Select the highest Baud Rate whenever possible. All Transmitters connected to the network must have the same Baud Rate. È Ç bd 19 = 19200 bd 9 = 9600 bd 2 Ç... - Page 18 TFT32 Tank Farm Transmitter Manual Series 2.4 mA DISPLAY From Normal Mode press Ç Displays mA input signal as received from pressure sensor or 4-20mA transmitter. Ç Return to Normal Mode Page 18...
-
Page 19: Enclosure Installation
TFT32 Tank Farm Transmitter Manual Series 2.4 ENCLOSURE INSTALLATION Locate the enclosure within 10,000 ft (3,000 m) of the pressure sensor. It can be wall mounted with four mounting screws (supplied) or panel mounted with Option PM Panel Mounting Kit from Greyline Instruments. -
Page 20: Sensor Installation
TFT32 Tank Farm Transmitter Manual Series 2.4 PST THREADED PRESSURE SENSOR INSTALLATION MAX LEVEL 1/4" NIPPLE STAINLESS STEEL CONDUIT SHIELDED PAIR PST PRESSURE TO TFT32 SENSOR SHIELD TRANSMITTER 2 ft / 60 cm NEMA4 ENCLOSURE VENTED TUBE MUST NOT COME IN CONTACT... -
Page 21: Error/Warning Messages
100= (Max Level) must be greater than (Min Level). Indicates that the TFT32 has experienced electrical interference strong enough to corrupt the memory. The TFT32 must be reset and recalibrated. Reset Procedure 1: Reset will clear all memory. TFT32 will need recalibration after this È... -
Page 22: Communication Protocol
TFT32 Transmitters through other software programs on PC computers or PLC’s. The TFT32 uses an ASCII format command/response protocol. The TFT transmits an answer only when polled with a valid command and address. The Host computer always initiates the command/response sequence. - Page 23 TFT32 Tank Farm Transmitter Manual Series 2.4 COMMAND SET COMMAND DEFINITION COMMAND MESSAGE TYPICAL RESPONSE (Address 1) Read all #%1RA<CR> *%1RA+959.300XXX0AA<CR> parameters Read Span #%1RS<CR> *%1RS+999.900XXX0BF<CR> (Max Level) NBxx New Baud Rate *%1NB02 #%1NBxx<CR> xx = 00 = 38400 (TFT will change to new...
-
Page 24: Fuse Replacement
TFT32 Tank Farm Transmitter Manual Series 2.4 FUSE REPLACEMENT REMOVE 1. Disconnect Power 2. Remove 2 top screws 3. Pull and flip chassis 4. Remove 0.5 amp fuse with long nose pliers 5. Install new fuse TFT32 Tank Farm Transmitter... -
Page 25: Applications Hotline
TFT32 Tank Farm Transmitter Manual Series 2.4 APPLICATIONS HOTLINE For applications assistance, advice or information on any Greyline Instrument contact your Sales Representative, write to Greyline or phone the Applications Hotline below: United States: Tel: 315-788-9500 Fax: 315-764-0419 Canada: Tel: 613-938-8956 Fax: 613-938-4857... -
Page 26: Product Return Procedure
TFT32 Tank Farm Transmitter Manual Series 2.4 PRODUCT RETURN PROCEDURE Instruments may be returned to Greyline for service or warranty repair. Obtain an RMA Number from Greyline - Before shipping a product to the factory please contact Greyline by telephone, fax or email to obtain an RMA number (Returned Merchandise Authorization). -
Page 27: Warranty
Manual Series 2.4 LIMITED WARRANTY ______________________ Greyline Instruments warrants, to the original purchaser, its products to be free from defects in material and workmanship for a period of one year from date of invoice. Greyline will replace or repair, free of charge, any Greyline product if it has been proven to be defective within the warranty period. - Page 28 TFT32 Tank Farm Transmitter Manual Series 2.4 PS150 POWER SUPPLY 150 Watt Power Supply for TFT32 Tank Farm System Powers up to 32 Greyline TFT32 Transmitters + 6 RB12 Relay Boards CONDUIT ENTRY LOCATION +V +V -V -V SIDE VIEW...
- Page 29 TFT32 Tank Farm Transmitter Manual Series 2.4 MODEL 485OI9TB-24V RS232/RS485 Converter Converts RS485 signals from a TFT32 Transmitter to RS232 for connection to a PC Computer or Modem. – DB9 RS232 Connector plugs directly into your computer’s COM port – Optically isolates and protects your computer’s RS232 port –...
-
Page 30: Conversion Tables
TFT32 Tank Farm Transmitter Manual Series 2.4 CONVERSION GUIDE FROM MULTIPLY BY US GALLONS CUBIC FEET 0.1337 US GALLONS IMPERIAL GALS 0.8327 US GALLONS LITRES 3.785 US GALLONS CUBIC METERS 0.003785 LITRES/SEC 15.85 LITRES CUBIC METERS 0.001 BARRELS US GALLONS... -
Page 31: Specifications
TFT32 Tank Farm Transmitter Manual Series 2.4 SPECIFICATIONS: Mounting Electronics Enclosure: NEMA4X (IP 67), watertight and dust tight, 4.21" 107 mm fiberglass with clear, shatterproof Lexan cover Accuracy: 0.25% F.S., Repeatability: 0.1% F.S., Linearity: 0.1%F.S. Display: ¾” / 19mm high, 4 digit LCD Programming: 2-button Menu selection. - Page 32 TFT32 Tank Farm Transmitter Manual Series 2.4 THREADED CONNECTION PRESSURE SENSOR Wetted Materials: 316 and 15-5 PH Stainless steel Enclosure Material: 316 stainless steel Accuracy: ±0.25% FSO (RSS) includes non-linearity, 1/2" NPT hysteresis and non-repeatability CONDUIT Operating Temperature: -20°F to 190°F (-29°C to 88°C) Compensated Temperature: 0°F to 180°F (-18°...
