- Page 1 Autoboil Instant boiling water 01652 Autoboil 1.5 Litre White 03652 Autoboil 3.0 Litre White 05652 Autoboil 5.0 Litre White 07652 Autoboil 7.5 Litre White Zenith Autoboil - Installation and Operating Instructions - 81433 - June 2012 v1.01 Page1 of 12...
- Page 2 Intentionally left blank. Page 2 of 12 Zenith Autoboil - Installation & Operating Instructions - 81433 - June 2012 v1.01...
-
Page 3: Table Of Contents
Spare Parts ............ 10 Contact Details ..........12 Note: All plumbing must comply with AS3500.4.1 & AS3500.4.2 All electrical must comply with AS3350.1 & AS3350.2.15 Zenith Autoboil - Installation and Operating Instructions - 81433 - June 2012 v1.01 Page3 of 12... -
Page 4: Read These Warnings First
All plumbing connections must be made in accordance with local regulations. The Zenith Autoboil instant boiling water heater is not intended for use by young children or infirm people without supervision. Young children should be prevented from having access to ensure that they are not able to use or play with the heater. -
Page 5: Installation Procedures
Screw heater chassis to the wall using screws or bolts suited to the wall. Screws or bolts must be capable of supporting the heater weight when filled. Zenith Autoboil - Installation and Operating Instructions - 81433 - June 2012 v1.01 Page5 of 12... -
Page 6: Step 3 - Connecting
Minimum - 1 bar (100 kPa) maximum - 7 bar (1000 kPa). Warning: If pressure is likely to exceed 7 bar, a pressure limiting valve must be installed in the cold water supply line. Zenith recommends a valve rated at 3.5 bar (350 kPa) for this application. -
Page 7: Wall Mounting Template Dimensions & Electrical Diagram
318 5.0L 416 3.5L 65 CLEAR 448 5.0L 561 7.5L POSITIONING PIN COLD EXTERNAL PLUMBING VENT INLET ELECTRICAL WIRING POSITION INTERNAL PLUMBING BENCH TOP Zenith Autoboil - Installation and Operating Instructions - 81433 - June 2012 v1.01 Page7 of 12... -
Page 8: Problem Solving
Warning- the water may be boiling - show extra care. 5. Test that in every instance the electrical resistance does not exceed 1 ohm. Page 8 of 12 Zenith Autoboil - Installation & Operating Instructions - 81433 - June 2012 v1.01... -
Page 9: Operating Procedures
Boiling water will flow until the tap is returned to its normal vertical position. This operation allows the vessel to be filled without holding your hand where it may be affected by steam. Zenith Autoboil - Installation and Operating Instructions - 81433 - June 2012 v1.01 Page9 of 12... -
Page 10: Spare Parts
Tank Welded 7.5L Kit 90146NZ Insulation Kit 1.5L 90147NZ Insulation Kit 3.0L 90148NZ Insulation Kit 5.0L 90149NZ Insulation Kit 7.5L 90130NZ Clips for Curled Tank Kit Page 10 of 12 Zenith Autoboil - Installation & Operating Instructions - 81433 - June 2012 v1.01... - Page 11 Spare Parts Zenith Autoboil - Installation and Operating Instructions - 81433 - June 2012 v1.01 Page11 of 12...
-
Page 12: Contact Details
Registering your Zenith installation on the Zenith Heaters Limited website may help to establish date of installation, should it become necessary to service the appliance, under the terms of Zenith Heaters Limited warranty. To register your installation go to www.zenithheaters.co.nz and look under the heading “Warranty”.
