Quality Craft MM220-46FDW Instruction Manual

Electric fireplace heater

Advertisement

Quick Links

design forward living
IMPORTANT:
PleAse NOTe: wheN yOu OPeN The cARTON cARefully check The uNIT ANd
MAke suRe TheRe ARe NO dAMAges. If yOu hAve ANy PRObleMs wITh The
uNIT, wITh hOw The vARIOus fuNcTIONs wORk OR wITh hIddeN dAMAges OR
MIssINg PARTs, PleAse cAll: 1-800-459-4409 (9:00 AM - 5:00 PM esT) fOR
cusTOMeR seRvIce.
NOTe: dO NOT ReTuRN uNIT TO The sTORe befORe cAllINg The TOll fRee
NuMbeR. dO NOT dIsPOse Of yOuR PAckAgINg cARTONs uNTIl yOu ARe
cOMPleTely sATIsfIed wITh yOuR New elecTRIc fIRePlAce heATeR
NOTe: Light bulbs may become loose during shipping. If the flame effect is dim or does
not work, please check that light bulb or bulbs are finger tight in socket. See instructions
for replacing bulb or bulbs.
NOTe: The electric fireplace heater may emit a slight harmless odor when first turned
on. This is caused by activating the internal heater components for the first time and
should not occur again.
iNStrUctiON MANUAl
ATTENTION:
1) Find a location for the electric fireplace heater that is protected from direct sunlight.
2) Do not plug the unit into the power outlet before reading all instructions.

iMPOrtANt SAFEtY iNStrUctiONS

WHEN USING ELECTRICAL APPLIANCES, BASIC PRECAUTIONS SHOULD ALWAYS
BE FOLLOWED TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, AND INJURY
TO PERSONS, INCLUDING THE FOLLOWING:
1) Read all instructions before using this electric fireplace heater.
2) This electric fireplace heater is hot when in use. To avoid burns, do not let
bare skin touch hot surfaces. The grill directly in front of the heater outlet
becomes hot during heater operation. Keep combustible materials, such
as furniture, pillows, bedding, papers, clothes, and curtains at least 3 feet
(0.9˛m) away from the front of the unit and keep them away from the sides
and rear.
3) Extreme caution is necessary when any heater is used by or near children or
individuals with disabilities and whenever the electric fireplace heater is left
operating and unattended.
4) Always unplug electric fireplace heater when not in use.
5) Do not operate any electric fireplace heater if the cord or plug is damaged,
or if the heater malfunctions, or if it has been dropped or damaged in any
manner.
6) Do not use outdoors.
7) This electric fireplace heater is not intended for use in bathrooms, laundry
areas and similar indoor locations. Never locate electric fireplace heater
where it may fall into a bathtub or other water container.
8) Do not run cord under carpeting. Do not cover cord with throw rugs, runners,
or similar coverings. Arrange cord away from traffic area and where it will
not be tripped over.
9) To disconnect electric fireplace heater, turn controls to off, then remove plug
from outlet.
10) Connect to properly grounded outlets only.
11) Do not insert or allow foreign objects to enter any ventilation or exhaust
opening as this may cause an electric shock or fire, or damage the heater.
ElEctric FirEPlAcE
HEAtEr
Model: MM220-46FDW
12) To prevent a possible fire, do not block air intakes or exhaust in any manner.
Do not use on soft surfaces, like a bed, where openings may become blocked.
13) The heater has hot and arcing or sparking parts inside. Do not use it in areas
where gasoline, paint, or flammable liquids are used or stored.
14) Use this electric fireplace heater only as described in this manual. Any other
use not recommended by the manufacturer may cause fire, electric shock, or
injury to persons.
15) Avoid the use of an extension cord because the extension cord may overheat
and cause a risk of fire. If you must use an extension cord, the cord must be
14 AWG and have a minimum rating of 1875 watts.
16) Caution: Do not plug this product into a receptacle controlled by a wall switch
or dimmer.
17) When storing or transporting the unit and cord, keep in a dry place, free from
excessive vibration and store so as to avoid damage.
SAVE tHESE iNStrUctiONS FOr FUtUrE USE.
CAUTION:
IF YOU USE THIS HEATER IN CONJUNCTION WITH A THERMAL CONTROL, A
PROGRAM CONTROLLER, A TIMER OR ANY OTHER DEvICE THAT SWITCHES THE
HEATER ON AUTOMATICALLY, REMEMBER TO OBSERvE ALL SAFETY WARNINGS
AT ALL TIMES. THE ELECTRIC FIREPLACE HEATER HAS SAFETY OvERHEAT
PROTECTION. IF THE OvERHEAT PROTECTION TRIPS, SWITCH OFF ALL SWITCH
BUTTONS AND WAIT APPROxIMATELY 5 -10 MINUTES. IT SHOULD RESET
AUTOMATICALLY ONCE THE UNIT COOLS DOWN.
WARNING:
PROCEDURES AND TECHNIqUES IF NOT CAREFULLY FOLLOWED WILL RESULT
IN DAMAGE TO THE EqUIPMENT AND WILL ExPOSE THE USER TO THE RISK OF
SERIOUS INJURY, ILLNESS OR DEATH.
THIS ELECTRIC FIREPLACE HEATER IS FOR USE ON 120 vOLTS. THE CORD HAS
A PLUG AS SHOWN AT A IN ILLUSTRATION BELOW. AN ADAPTER AS SHOWN AT
C IS AvAILABLE FOR CONNECTING THREE-BLADE GROUNDING-TYPE PLUGS TO
TWO-SLOT RECEPTACLES. THE GREEN GROUNDING PLUG ExTENDING FROM
THE ADAPTER MUST BE CONNECTED TO A PERMANENT GROUND SUCH AS A
PROPERLY GROUNDED OUTLET BOx. THE ADAPTER SHOULD NOT BE USED IF A
THREE-SLOT GROUNDED RECEPTACLE IS AvAILABLE.
A 15 AMP CIRCUIT IS REqUIRED TO OPERATE THIS HEATER. IF THE BREAKER
TRIPS WHEN THE HEATER IS USED THEN YOU MAY NEED TO MOvE THE HEATER
TO ANOTHER LOCATION OR UNPLUG OTHER APPLIANCES THAT ARE ON THE
SAME CIRCUIT. IF YOU REqUIRE AN ExTENSION CORD USE ONE THAT IS RATED
AT 1875 WATTS.
1
