1. Keys and Input Ports
0
Light Indicator
SPK-2AE52 User Guide
1)
2)
3)
4)
5)
6)
Note: On Line-in state, (5) & (6) keys control the
volume only.
7)
8)
9)
1) Charging Indicator: Red LED light is on when
2) Working State Indicator:
ZHONGXIN ELECTRONICS INDUSTRIAL Ltd.
USB Charging port
Line-in port (Aux Port)
T-Flash Slot
Power On/Off
Previous track / Previous FM station (press
once) or Vol – (press and hold)
Next track / Next FM station (press once) or
Vol + (press and hold)
Play/Pause: Valid on MP3 playing state only.
Audio Source: Press this key to select different
audio source: T-flash card, FM radio and Line-in.
External FM antenna (optional)
the product is charging. LED light is off when
the charging is finished.
LED light on during MP3 playing state
LED light flashes slowly during FM radio state
LED light flashes rapidly during Line-in state.
Advertisement
Table of Contents
Summary of Contents for Velev SPK-2AE52
- Page 1 ZHONGXIN ELECTRONICS INDUSTRIAL Ltd. SPK-2AE52 User Guide 1. Keys and Input Ports USB Charging port Line-in port (Aux Port) T-Flash Slot Power On/Off Previous track / Previous FM station (press once) or Vol – (press and hold) Next track / Next FM station (press once) or Vol + (press and hold) Note: On Line-in state, (5) &...
- Page 2 ZHONGXIN ELECTRONICS INDUSTRIAL Ltd. SOURCE (INPUT) key When you press the INPUT KEY once, you can enter into the FM radio state; if you press the key twice, you can enter into the Line-in state. On the FM radio state, you must insert the external antenna into the 3.5mm audio port. Press the PLAY/PAUSE key down for few seconds, the player will auto-search the radio frequency and store them.
- Page 3 ZHONGXIN ELECTRONICS INDUSTRIAL Ltd. 7. Assembled State 6. The bicycle bracket for the 2.4 5. The bicycle bracket for the GHz remote control (Optional) speaker (Optional) 8. Specification FM: 87.5 - 107.5 MHz Speaker power: 2W+2W Frequency response: 150 Hz - 20 KHz Signal/Noise ratio: ≥80 dB Sensitivity: 600±100 mV Rated distortion: ≤1% (1W 1 KHz)
- Page 4 ZHONGXIN ELECTRONICS INDUSTRIAL Ltd.
