Capella Technologies SecureDIMM II User Manual

For hp laserjet printers
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SecureDIMM Level II for
HP LaserJet Printers
User' s
Guide
May 2001
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SecureDIMM II and is the answer not in the manual?

Questions and answers

Summary of Contents for Capella Technologies SecureDIMM II

  • Page 1 SecureDIMM Level II for HP LaserJet Printers User’ s Guide May 2001...
  • Page 3 DIMM-SOFTWARE LICENSE AGREEMENT IMPORTANT: Please read this License carefully before using the included “I/O Driver Development Software” provided for the Capella Technologies DIMM product, hereinafter referred to as “SOFTWARE”. The right to use this SOFTWARE is granted only if you agree to the terms of the license. USE OF THIS SOFTWARE INDICATES YOUR ACCEPTANCE OF THE TERMS AND CONDITIONS OF THE LICENSE AGREEMENT.

  • Page 4: Limited Warranty

    LIMITED WARRANTY To the original purchaser, Capella Technologies, LLC. warrants the memory module (SIMM/ DIMM) and diskette on which the files are stored to be free of defects in materials and faulty workmanship for a period of ninety (90) days from the date the product is delivered. If during this period a defect in these SIMM/DIMM or diskette should occur, you may return the SIMM/DIMM or diskette with a copy of your receipt or other proof of payment to Capella Technologies, or to an authorized Capella Technologies distributor, and Capella...

  • Page 5: Table Of Contents

    Contents Introduction ... 6 Installing the SecureDIMM II Board ... 8 Testing the SecureDIMM II ... 8 Installing the Secure Level II Driver ... 9 Installing the RedMon Port Monitor and Capella Encryption Filter ... 17 aesCrypt Utility / Using aesCrypt Utility... 24 Additional Technical Support Information ...

  • Page 6: Introduction

    Capella Technologie’ s SecureDIMM™ is a hardware-based solution that addresses this need. In the event that a file can not be printed immediately due to network traffic or printer status (for instance, “printer off-line” or “printer out of paper”), client application output is stored or queued in print spool files on either the client system or network print server.
  • Page 7 truction and function it is really quite different. The Security DIMM presents two physical and logical sides. The first is the firmware side. It is on this side that the audit code is contained. The second side is the storage side. The DIMM also contains an optional interface for I/O capabilities.

  • Page 8: Installing The Securedimm Ii Board

    SecureDIMM can be installed in any of these slots. The SecureDIMM is installed exactly like a memory DIMM module. For instructions on how to install the SecureDIMM please reference the adding memory section of your printers HP LaserJet Printer User’ s Manual.

  • Page 9: For Windows 2000

    Level 2 Firmware in your printer before beginning the software installation. The software installation is performed in three phases: 1. Install the Standard HP LaserJet 4100 Drivers. 2. Install the RedMon Port Monitor and Capella Encryption Filter. 3. Install the Encrypted Printer Driver.
  • Page 10 Installing the Standard HP LaserJet 4100 Drivers 1. Close all other programs beginning the driver installation process. Place the hp LaserJet 4100 CD-ROM into your CD-ROM drive. The CD Browser program will start automatically. Click the Install Printer button. 2. Select the appropriate language for your location from the drop-down box and click OK.
  • Page 11 5. Select the No button and then click Next to install directly from the CD. 6. If your printer is attached to a network, skip to step 9. Otherwise, select the Connected to this computer button and click Next.
  • Page 12 8. Skip to step 14 to continue the installation. 9. If your printer is attached to a network, select the Connected to the network button and click Next. Otherwise, return to step 6. 10. Select the Basic Microsoft Server Setup button if your printer is attached to the network via a JetDirect card.
  • Page 13 12. Select your printer from the list of printers. Click the Next button. 13. Click Next to use the recommended printer communication mode. 14. Select your printer model from the list. Click the Next button. 15. Select the Custom Installation button to allow installation of the optional...
  • Page 14 16. Click the HP LaserJet 4100 PCL 5e Driver and HP LaserJet 4100 PS Driver check boxes to install these optional drivers. Click the Next button. 17. Change the Printer Name and Default Printer settings if required. Click the Next button.
  • Page 15 19. Select the Print a test page check box and unselect the Run Web Registration check box. Click the Finish button. The driver test page will be printed. 20. When the test page has printed, click the OK button. 21. The driver is now installed; click EXIT to close the CD Browser.
  • Page 16 22. Click EXIT one last time. The standard LaserJet 4100 printer driver installation is now complete.

  • Page 17: Installing The Redmon Port Monitor And Capella Encryption Filter

    Installing the RedMon Port Monitor and Capella Encryption Filter Double-click the My Computer icon on the Windows Desktop. Double-click the C: drive icon. Select File, then New, then Folder from the Menu Bar. Enter Capella Tech as the new folder name. Copy the RedMon15.exe file to the new Capella Tech folder.
  • Page 18 Click Start (on the Windows taskbar), then click Run… Type C:\Capella Tech\setup.exe and press the Enter key. Click the Yes button to confirm that you want to install RedMon. Click the OK button when the RedMon installation is complete. The RedMon Port Monitor and Capella Encryption Filter are now installed!
  • Page 19 1. Click Start (on the Windows taskbar), then Settings, then Printers. 2. Double-click the Add Printer icon. 3. Click the Next button to begin the Add Printer process. 4. Encrypted printers always use a redirected port on your local computer.
  • Page 20 Arguments for this program are: -e 000102030405060708090a0b0c0d0e0f Output: Printer: Run: Note that Printer: may reference any standard (not encrypted) printer driver that is configured to print to the port (network or local) where the printer is attached. Copy stdout to printer HP LaserJet 4100 PCL6 Hidden...
  • Page 21 5. Ot her wi s e , s e l e c t t he port: list-box and then click the Next button. 10. In the Manufacturers: list-box, select HP. In the Printers: list-box, select HP LaserJet 4100 PCL 5e (or any other appropriate driver).
  • Page 22 Click the Next button. 13. Enter a name in the Share as: box if you wish to share this printer with other users on your network, otherwise click the Do not share this...
  • Page 23 14. Click the Yes button to print a test page. Click the Next button. 15. When the test page has printed, click the OK button. 16. The encrypted printer driver setup is now complete.

  • Page 24: Aescrypt Utility / Using Aescrypt Utility

    The -e option selects the encryption operation. The key must match the key that has been programmed into the printer. It must be specified as a 128-bit hexadecimal value. The input-file specifies the file containing the decrypted print job. The output-file specifies the file to contain the encrypted print job.
  • Page 25 Copying Encrypted Files to a Printer Once an encrypted print job has been created, it needs to be sent to a printer. The exact details of this process will vary from installation to installation. What follows are some general guidelines.

  • Page 26: Additional Technical Support Information

    For example, type the following from a DOS/Windows command prompt: copy /b CryptTst.prn lpt1: Contact Capella Technologies for further assistance Copy the SecureDIMM II test file to the printer. For example, type the following at a DOS/Windows command prompt: copy /b CryptTst.prn lpt1: Was a...
