Quality Craft QC115-MBK Quick Manual

IMPORTANT
PleAse NOTe: WheN yOu OPeN The CARTON CARefully CheCK The uNIT
ANd MAKe suRe TheRe Is NO dAMAge. If yOu hAve ANy PROBleMs WITh
The uNIT, WITh hOW The vARIOus fuNCTIONs WORK, dAMAged OR MIssINg
PARTs PleAse CAll 1-800-459-4409 (MONdAy TO fRIdAy, 8:30AM TO
5:00PM, esT) IMMedIATely fOR seRvICe.
NOTe: dO NOT ReTuRN uNIT TO The sTORe BefORe CAllINg The TOll fRee
NuMBeR. dO NOT dIsPOse Of yOuR CARTONs uNTIl yOu ARe COMPleTely
sATIsfIed WITh yOuR NeW sTOve heATeR.
NOTE: Light bulbs may become loose during shipping. If the flame effect is dim or
does not work, please check that light bulb or bulbs are finger tight in socket. See
instructions for replacing bulb or bulbs.
NOTE: The stove may emit a slight harmless odor when first turned on. This is caused
by activating the internal heater components for the first time and should not occur
again.
INSTRUCTION MANUAL
ATTeNTION:
1) Find a location for the stove heater that is protected from direct sunlight.
2) Do not plug the unit into the power outlet before reading all instructions.

IMPORTANT SAFETY INSTRUCTIONS

WheN usINg eleCTRICAl APPlIANCes, BAsIC PReCAuTIONs shOuld
AlWAys Be fOllOWed TO ReduCe The RIsK Of fIRe, eleCTRIC shOCK,
ANd INJuRy TO PeRsONs, INCludINg The fOllOWINg:
1) Read all instructions before using this electric stove heater.
2) This electric stove heater is hot when in use. To avoid burns, do not let
bare skin touch hot surfaces. The grill directly in front of the heater outlet
becomes hot during heater operation. Keep combustible materials, such as
furniture, pillows, bedding, papers, clothes, and curtains at least 3 feet (0.9
m) away from the front of the unit and keep them away from the sides and
rear.
3) extreme caution is necessary when any heater is used by, or near, children
or individuals with disabilities and whenever the stove is left operating and
unattended.
4) Always unplug heater when not in use.
5) do not operate any heater with a damaged cord or plug or after the heater
malfunctions, has been dropped or damaged in any manner.
6) do not use outdoors.
7) This heater is not intended for use in bathrooms, laundry areas and similar
indoor locations. Never locate heater where it may fall into a bathtub or other
water container.
8) do not run cord under carpeting. do not cover cord with throw rugs, runners,
or similar coverings. Arrange cord away from traffic area and where it will
not be tripped over.
9) To disconnect heater, turn controls to off, then remove plug from outlet.
10) do not insert or allow foreign objects to enter any ventilation or exhaust
opening as this may cause an electric shock or fire, or damage the heater.
11) To prevent a possible fire, do not block air intakes or exhaust in any manner.
do not use on soft surfaces, like a bed, where openings may become blocked.
12) A heater has hot and arcing or sparking parts inside. do not use it in areas
where gasoline, paint, or flammable liquids are used or stored.
ELECTRIC STOVE
HEATER
Model: QC115-MBK
13) use this heater only as described in this manual. Any other use not
recommended by the manufacturer may cause fire, electric shock, or injury
to persons.
14) Avoid the use of an extension cord because the extension cord may overheat
and cause a risk of fire. however, if you have to use an extension cord, the
cord shall be No. 14 AWg minimum size and rated not less than 1875 watts.
15) do not plug this product into a receptacle controlled by a wall switch
or dimmer.
16) When storing or transporting the unit and cord, keep in a dry place, free from
excessive vibration and store so as to avoid damage.

SAVE THESE INSTRUCTIONS

FOR FUTURE USE.
A 15 AMP CIRCuIT Is ReQuIRed TO OPeRATe ThIs heATeR. If The BReAKeR
TRIPs WheN The heATeR Is used TheN yOu MAy Need TO MOve The heATeR
TO ANOTheR lOCATION OR uNPlug OTheR APPlIANCes ThAT ARe ON The sAMe
CIRCuIT. If yOu ReQuIRe AN exTeNsION CORd use ONe ThAT Is RATed AT 1875
WATTs.
LEG ASSEMBLY
Before using your unit please install the legs as shown in diagram below.
After completely reading instructions, confirm that all controls on stove are in the OFF
position. Plug the unit into a 15 amp, 120 volt outlet.
1
