Summary of Contents for Music Hall Audio mmf-9.1
- Page 1 INSTRUCTION MANUAL music hall http://www.musichallaudio.com august 2007...
-
Page 2: Congratulations On Your Purchase
You have selected an exceptional turntable. Each component used in the construction of the mmf-9.1 was selected to provide you with superior performance and the highest level of sound reproduction available today. We know of no turntable that costs as much to produce yet sells for so little. - Page 3 7. Cleaning Please refer to the MAINTENANCE section for detailed cleaning instructions. 8. Power Sources Connect the turntable only to a power supply of the type and voltage described in the operating instructions or specified on the rear panel of the unit. 9.
- Page 6 PARTS INVENTORY AND OPERATION CONTROL DIAGRAMS 1. 3 x removable transport screws 2. 1 x motor pulley 3. 1 x drive belt (packaged in parts bag) 4. motor alignment guide (packaged in parts bag) 5. 1 x platter 6. 1 x tonearm counterweight (located in packing material) 7.
-
Page 7: Getting Started
THE CARTRIDGE The mmf-9.1 comes standard with the Goldring Eroica LX cartridge. The Eroica LX is a low-output moving coil cartridge. The Eroica LX was chosen for its low mass, high rigidity body, rare earth Neodymium magnet, and its Gyger II line contact stylus. It is a perfect complement to the audiophile qualities of the mmf-9.1. -
Page 8: For Your Information
This manual provides valuable information that will help you get optimum performance from your system. Please contact your authorized music hall dealer for any additional clarifications you may require. Save the music hall mmf-9.1 shipping carton and all enclosed packing material for future use. Shipping or moving the mmf-9.1 in anything other than the original packing material may result in severe damage that is not covered by the warranty. - Page 9 SET-UP The music hall mmf-9.1 is supplied partially disassembled and carefully packaged for safe transport. To assemble the turntable, please follow the instructions carefully. 1. Clear a level (use a spirit level) and suitable workspace to assemble the turntable. This may be the final playing location.
- Page 10 You may first need to remove the tape. Save the guard for future use. 16. You will now set the tracking force. The mmf-9.1 comes complete with a factory installed Goldring Eroica LX. We recommend a tracking force of 1.75g. Please note;...
- Page 11 The tonearm is now zeroed. Check it, by once again floating the tonearm between the tonearm rest and the platter. If the tonearm doesn’t float parallel to the platter at zero, return to the previous steps and make the necessary adjustments. Return the tonearm to the tonearm rest.
- Page 12 NOTE If you are substituting another cartridge for the Goldring Eroica LX, you may need to make the following further adjustments to the tonearm (9) and cartridge: If you are a novice, music hall recommends getting professional help. All cartridges with half inch mounting holes can be fitted. Leaving the stylus guard on, fit the cartridge to the head shell (21) using the screws supplied with the cartridge by passing one screw through each slot in the finger lift and the head shell (21).
-
Page 13: Audio Connection
If you have any further questions regarding the adjustment of your turntable, please contact your music hall dealer. Azimuth Adjustment: Azimuth is the angle of the stylus to the record groove. Viewed from head-on, you want the stylus to be perpendicular to the record groove so as to not favor one channel over the other. -
Page 14: Mains Connection
(5) and play. MAINTENANCE The mmf-9.1 is designed for a long operational life. To preserve the appearance of your deck and maintain its performance, you should note the following points: * Make sure the stylus guard is on before you begin cleaning * PLINTHS - The plinths are constructed from medium density fiberboard, therefore they should not be subjected to extremes of temperature or direct sunlight. - Page 15 DUST COVER - This can be cleaned using any commercial acrylic or plastic cleaners. The simplest approach is to remove any dust with a damp, lint-free cloth without rubbing and then use a soft duster. Dust covers are more often damaged in cleaning than in use.
-
Page 16: Technical Specifications
TECHNICAL SPECIFICATIONS: Power Supply: 115V/50Hz or 230V/50Hz Power Absorption: 2VA 33⅓ - 45rpm (electronic speed control) Speeds: Speed deviation: ± 0.9% Wow and flutter: ±0.15 % Rumble Max: > -70 db Tracking force: 10 - 30 mN Effective tonearm length: 9.5 in (24.13cm) Overhang: .71 inch (18mm) -
Page 17: Troubleshooting
TROUBLESHOOTING music hall turntables are manufactured to the highest standards and undergo strict quality controls before leaving the factory. If, for some reason your turntable is not working properly, please take a few moments to review this list of potential causes. THE PLATTER DOESN'T TURN, ALTHOUGH THE DECK IS SWITCHED ON: ... -
Page 19: Claims Under Warranty
WARRANTY This entitles you to have the music hall mmf-9.1 repaired free of charge, at our discretion, for one year after the date of purchase, at any authorized music hall service center, provided the unit was purchased from an authorized dealer. Your original sales receipt is proof of purchase date.
