  • Page 1 ’ ’ ’ Digital Video Recorder 7493 Trans-Canada highway #103, St-Laurent (Quebec) H4T 1T3 Tel.: 514-668-1845 Fax: 514-789-0878 www.videowave.ca info@videowave.ca...

  • Page 2: Table Of Contents

    INDEX Ⅰ. System Configuration & How to install RDVR (Remote DVR) 1. System Configuration 2. RDVR(Remote DVR) Installation procedure 3. Network setup for Server DVR 4. Network setup for Client RDVR PC Ⅱ. How to use RDVR (Remote DVR) 1. Initial screen configuration and name 2.

  • Page 3: Rdvr(Remote Dvr) Installation Procedure

    Ⅰ. System Configuration & How to install RDVR (Remote DVR) 1. System Configuration ========================================== = = = = = = = = = = = = = = Remote DVR is a program to connect main DVR server from remote site thorough Network. After connecting with DVR server successfully with this RDVR(Remote DVR), user can monitor, search, backup, and DVR server setup, etc.

  • Page 4: Tcp/Ip Setup

    3. Network setup for Server DVR ========================================== = = = = = = = = = = = = = = 1. TCP/IP setup ※ For Windows Xp ※ Open Network Set up Panel 1. Just double click “My Network Places” for network setup.

  • Page 5: Network Setup For Client Rdvr Pc

    Please click on the Internet Protocol(TCP/IP), and click “Properties”. Now you can see the Internet Protocol(TCP/IP) Properties. Please check “Use the following IP address”, if you have fixed IP address, and then fill in all IP address, Subnet mask, and Default gateway, etc.

  • Page 6: Local Setup

    Ⅱ. How to use RDVR (Remote DVR) 1. Initial Screen Configuration and name ========================================== = = = = = = = = = = = = = = Remote DVR is a program to connect main DVR server from remote site thorough Network. (1) Date/Time Information (2) Remote Monitoring Indicator (3) Connected / Disconnected Status...

  • Page 7: Local Search

    (1) Date and Time Information Shows current date and time information. (2) Remote Monitoring Indicator If the Remote DVR is connecting to Server DVR, the network indicator will be flashing. (3) Connected / Disconnected Status Display status of connected or disconnected with Server DVR. (4) Connect / Disconnect Click to connect or disconnect with server DVR.
  • Page 8 (12) Division Screen User can select how many camera channels want to see on the Monitor at once by it. (13) Manual Rotation User can rotate the monitoring screen by clicking this button. (14) Auto Rotation User can see auto sequence screen by set time at System Setting part from camera 1 to 16. (15) Close S/W Click only for exit this RDVR software.

  • Page 9: Local Setup

    2. Local Setup ========================================== = = = = = = = = = = = = = = ※ Following is the procedure of connecting Server DVR with RDVR. 1. Click the Local Setup icon in the main RDVR GUI & Environment Setup. 2.
  • Page 10 For Event Notify pop up, users have to check the [Event select]. Events contents Wave File Name Wave file location C:₩program files₩RDVR₩sound₩eviewer Shutdown shutdown.wav Motion mstart.wav Sensor sstart.wav Video Loss videooff.wav Video On videoon.wav √ Users have to select the “ Event Select ” to get an Event Notify at the remote site RDVR PC, and also setup the remote notify schedule at the DVR Server setup.
  • Page 11 Save Directory : Select a folder to save a video data in your RDVR PC. User can monitor, search, backup the server DVR video data from remote site. To save the data, user should select a folder in RDVR PC. Default Screen-split : Select one of them to see initial screen split for RDVR, when user open the RDVR program.
  • Page 12 (3) Group site connection setup User has to do above Single site setup to make a Group site setup. Click the “New Group” to make a Group Name. Please fill in the group name, and click “OK”. Check the “Channel 1” and select one of single site name, and choose a camera No, which you want to monitor from the single site DVR.
  • Page 13 User can find the group name and its camera connection status by selecting here. (4) Connection server DVR Select Site name from Single or Group site list, and fill in User Name and Password. User has to get Remote access Authorized User name and Password to Login. <...

  • Page 14: Local Search

    3. Local search ========================================== = = = = = = = = = = = = = = Users have to click “Select Site” firstly, and select a site where you want to search. Now select Save Type either “Current” or “Past”. All other features are same as sever DVR search usage.
  • Page 15 4. 2- Way Audio ========================================== = = = = = = = = = = = = = = Users can communicate from RDVR site to Server DVR site. 2 Way Audio Select a DVR site, which you want to connect, and just “Double Click” the site name. Users have to setup “Mike”...

  • Page 16: Remote Search

    6. Remote Search ========================================== = = = = = = = = = = = = = = It is for searching the Server DVR recorded data (Saved Data) from RDVR site. Save Search Users can save the Server DVR data to RDVR site PC by [Save Search]. If you click the [Save Search], when you playback the server DVR recorded data, the data will be saved to your RDVR PC, and you can search them on “Local Search”...
  • Page 17 Ⅲ. How to use Event Notify Window 1. Initial Screen Configuration and name ========================================== = = = = = = = = = = = = = = This Event notify Window will be auto-activated, when Event (sensor, motion, system down, video loss, etc) happens with camera schedule or sensor.
  • Page 18 Descriptions / Contact information / Instructions It is from the server DVR setup information for Notify Info. Please refer to DVR User manual at the chapter 2-4 Recording schedule. 1) Descriptions Site name: Shows the server DVR name. Camera Description: Shows camera No. 2) Contact information Name: Shows contactable person name.
  • Page 19 Tip). To use Event Notify Window feature, firstly you have to set up the Network Notification and Notification schedule at the server DVR setup. Secondly, you have to check the Event Select. If you want to hear some sound with this Event Notify window, please make sound file(wave...
