- Page 1 XRS 8W 8” Wide 800x480 Open Frame Display User’s Manual v1.0 XRS 8W...
-
Page 2: Table Of Contents
Table of Contents Display Features/Specifications ___________________ Optional Features ___________________ Controller Board Features ___________________ System Design ___________________ On-Screen Menu Features _______________________ Image Adjustment Menu _______________________ RGB Color Menu _______________________ Audio Menu _______________________ Image Position Settings _______________________ On-Screen Settings _______________________ Source Selection _______________________... -
Page 3: Display Features/Specifications
Display Features • Slimmest Open Frame Design in the Market • Detachable Brackets for Versatile Mounting • Convenient Extended Cables with Connectors • Easy Installation & Cable Replacement • VGA Analog Input • DVI Digital Input (If Available) • HDMI Digital Input •... -
Page 4: Optional Features
Optional Features Optical Enhancement Available Touchscreens Optical Bonding of Touchscreen 5 Wire Resistive Single Touch • • Superior Sunlight Readability 1.4mm Thickness • • Increased Contrast/Brightness USB 1.1 and 2.0 • • Shock/Vibration/Impact Protection FCC-B, CE • • Prevents Moisture & Condensation Build-Up MTBF 200,000 Hours •... -
Page 5: Controller Board Features
Controller Board Features Inputs & Outputs Operation • VGA Input • • H: 31kHz-96kHz, V: 55kHz-76kHz 6 OSD Languages • • Composite RCA Video Input English/French/Deutsch/Espanol/Korean/Italian • • NTSC/PAL Image Overscan (On/Off) • • HDMI Input 3 Color Status LED •... -
Page 6: System Design
System Design POWER MENU RIGHT LEFT OSD Menu Board Interface LCD Panel LED Backlight Connector LCD Interface Cable J 948 Backlight Connector Speaker Outputs 12V DC Power Composite Stereo Audio Input VGA Analog Input HDMI Digital Input Video Input... -
Page 7: On-Screen Menu Features
On-Screen (OSD) Menu System (A) Color Setting (B) Audio Setting (C) Image Setting (D) Menu Setting (C-1) Auto Adjust (D-1) Language (C-2) OverScan (A-1) Brightness (B-1) Volume (D-2) OSD Timer (C-3) Color Menu (A-2) Contrast (B-2) Audio Input (C-4) H position (D-3) Transparency (A-3) Color Temp (C-5) V position... -
Page 8: Image Adjustment Menu
Color Brightness Contrast Saturation Sharpness Picture Mode User Selection OK Enter Menu Descriptions Button and Function • YUV AV Color Menu : • Menu : Menu Off HDMI(DVI) Input • ▲ : Move Icon AV1 input • OK : Go to adjust items... -
Page 9: Picture Mode
Color Picture Mode Dynamic Normal Mild User SRGB Selection Adjust Menu Descriptions Button and Function • 5 Picture Modes • Menu : Menu Off • For AV1 input • ▲ : Move Item • HDMI(DVI) Input ( YUV menu) • SEL,OK : select Item •... -
Page 10: Rgb Color Menu
Color Brightness Contrast ColorTemp User Green Blue Selection Enter Menu Descriptions Button and Function • RGB Color Menu : • Menu : Menu Off D-Sub RGB Input, • ▲ : Move Icon HDMI(DVI) Input : RGB Menu • OK : Enter... -
Page 11: Color Temp
Color Color Temp Cool Normal Warm SRGB User Selection Adjust Menu Descriptions Button and Function • Menu : Menu Off • 5 Picture Modes • ▲ : Move Item • For DSUB RGB input • SEL,OK : select Item • SRGB Adjust Menu (VCOM,ICM,DCC): (UP + LEFT) button at SRGB Mode cf) 12 page... -
Page 12: Audio Menu
AUDIO Volume Audio Input HDMI Audio Selection OK Enter Menu Descriptions Button and Function • Audio Input : • Menu : Menu Off HDMI Audio and External Audio selection • ▲ : Move Icon (HDMI Input ) • : Enter... -
Page 13: Image Position Settings
IMAGE AUTO ADJUST H POSITION V POSITION CLOCK PHASE OverScan Selection OK Enter Menu Descriptions Button and Function • OverScan On/Of • Adjustment menu for DSUB RGB input • Menu : Menu Off • ▲ : Move Icon • : Enter... - Page 14 IMAGE OverScan Image YUV Menu DVI 1920x1200 Selection OK Enter Menu Descriptions Button and Function • OverScan On/Of • Image Menu : RGB Color menu /YUV Color Menu • Menu : Menu Off • ▲ : Move Icon at HDMI(DVI) input signals •...
-
Page 15: On-Screen Settings
O S D Lanquage English OSD Timer Transparency Reset Version FW Ver. 1.0 Selection OK Enter Menu Descriptions Button and Function • English , Francais, Deutsch, Español • Menu : Menu Off Italian, Korean • OSD Timer : 5 sec ~ 60 sec •... - Page 16 O S D Reset Selection Adjust Menu Descriptions Button and Function • Factory Reset • Menu : Menu Off • ▲ : Move Icon • SEL,OK : : Enter...
- Page 17 Descriptions SRGB Menu • SRGB Menu for DCC and ICM • VCOM : Default (139) • DCC : Default (6) • ICM Switch : Default ( On) Button and Function • Menu : Menu Off • ▲ : Move • : Adjust...
- Page 18 ICM Menu Descriptions • Adjustment menu for ICM (Red, Green, Blue, Yellow, Cyan) Button and Function • Menu : Menu Return • ▲ : Move Icon • : Adjust...
-
Page 19: Source Selection
Descriptions Input Message * Some Input signals are not shown • Message case : DVI. HDMI Power On start, Soft power On, 1920X1080 Input change • Input Signals : AV1, D-sub, DVI.HDMI Button and Function Signal List Message • SEL,OK : Menu Off Source Descriptions D-SUB... - Page 20 Voulme Message Volume • LEFT KEY (Keyboard) Ratio Message IMAGE RATIO • Menu : Menu return 16 : 9 Normal 4 : 3 • ARC Button or Right (Keyboard) Out of Range Message Dsub RGB Out of Range 9 0 . 5 k H z V : 1 0 0 .
- Page 21 Auto Configuration Message Auto Adjust • Auto Adjust of OSD menu on RGB signal Auto Color message Auto Color • Optimize RGB gain • DOWN key ( Keyboard ) • DOWN Button ( remote controller ) ( For Dsub RGB signal , Normal state )
- Page 22 Thank you for using Revosys Display solutions...
