PlaySafe 22-PS302 Owner's Manual

Manchester ii deluxe 6-leg swing set
Hide thumbs

Advertisement

Quick Links

Download this manual
Model #: 22-PS302
Important: Keep this owner's manual; do not discard in case you need to contact Pacific Cycle, Inc. in the future. Should
there be a change of ownership, please transfer this manual to the new owner to ensure proper assembly and safety.
Pacific Cycle, Inc. warrants this product to be free of defective materials and workmanship for 90 days from the date of original
purchase.
THIS LIMITED WARRANTY IS THE ONLY WARRANTY APPLICABLE TO THIS PRODUCT, AND IS
EXPRESSLY IN LIEU OF ANY OTHER WARRANTY. ANY IMPLIED WARRANTIES, INCLUDING ANY
WARRANTY OF MERCHANTABILITY AND WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE, IS
LIMITED IN DURATION TO THE DURATION OF THIS EXPRESS WARRANTY. This limited warranty gives you
specific legal rights and you may also have other rights which may vary from state to state. This warranty is extended only to the
original consumer purchaser for non-commercial use.
PACIFIC CYCLE, INC. IS NOT RESPONSIBLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES. THIS LIMITED
WARRANTY DOES NOT COVER ANY PERSONAL INJURIES, DAMAGE TO, OR FAILURE OF THE PRODUCT OR
ANY OTHER LOSSES DUE TO ACCIDENT, ABUSE, MISUSE, ALTERATION, NEGLECT, NORMAL WEAR AND TEAR,
RUST, IMPROPER ASSEMBLY, IMPROPER FIT, IMPROPER MAINTENANCE OR USE OF UNAUTHORIZED
REPLACEMENT PARTS NOT DESIGNED FOR THE PRODUCT.
To make claim under warranty, notification of such defect must be given to Pacific Cycle, Inc. By calling the phone number
below, you will be instructed on how the product or part needing replacement should be shipped postpaid to Pacific Cycle, Inc.
Customer Service and Assistance
1-800-242-6110
Monday – Friday 8am-5pm CST
Please contact the Playsafe™ customer service team if you have any questions about our product, need assembly assistance or
need replacement parts for the swing set. You may also contact us by mail:
1
Owner's Manual and Assembly Instruction
90 DAY LIMITED WARRANTY
Model Name: Manchester II Deluxe
6-Leg Swing Set
Manual Date: September, 2007
2006 Pacific Cycle, Inc.
©

Advertisement

loading
Need help?

Need help?

Do you have a question about the 22-PS302 and is the answer not in the manual?

Questions and answers

Summary of Contents for PlaySafe 22-PS302

  • Page 1 1-800-242-6110 Monday – Friday 8am-5pm CST Please contact the Playsafe™ customer service team if you have any questions about our product, need assembly assistance or need replacement parts for the swing set. You may also contact us by mail: 2006 Pacific Cycle, Inc.
  • Page 2 Playsafe™ Customer Service Pacific Cycle, Inc 4730 East Radio Tower Lane Olney, IL 62450 Or by email: info@Playsafeoutdoors.com WARNINGS AND SAFETY INFORMATION BSERVE ALL WARNINGS AND STATEMENTS IN ORDER TO REDUCE THE RISK OF INJURY OR DEATH • BEFORE YOU ASSEMBLE THE SWING SET...
  • Page 3 ANCHORING ANCHORING is necessary to prevent tipping, lifting, and overturning. Playsafe™ recommends anchoring the swing set in concrete, especially in soft or sandy soil. When this is not possible, anchors can be purchased by calling 1-800-242-6110. To anchor the swing set in concrete, dig a hole at least 5” deep and 10” to 12” in diameter. Place the swing set leg in the hole, preferably on a brick or stone to keep if from sinking.

  • Page 4: Care And Maintenance

    FALL HEIGHT IN FEET FROM WHICH A LIFE THREATENING INJULY WOULD NOT BE EXPECTED Material Type 6 in. depth 9 in. 12 in. Double Shredded Bark Mulch 6’ 10’ 11’ Wood Chips 6’ 7’ 12’ Fine Sand 5’ 5’ 9’ Fine Gravel 6’...
  • Page 5 PRE-ASSEMBLED HARDWARE For easier assembly, Playsafe™ has pre-assembled some of the parts for you. Most of the screws and bolts should already be in place. If removal of this hardware is required for certain assembly steps, it should be replaced in its original position. If it is not necessary to remove the hardware, check to make sure it is tight before allowing children on the swing set.
  • Page 6 Support Bar x3 Corner Leg Fitting x2 Center Leg Fitting x1 Pre-Assembled Parts: • Swing and trapeze hooks should be in place on the top tube. • Hardware for legs should be in place in the corner fittings. • Hardware for support bars should be in place on the legs. •...
  • Page 7 Remove the hardware from the middle Part Ref. #: PSHW12 section of a leg. Match up the holes of the mid-leg and support bar and re-insert the hardware through both. Repeat the process for the opposite side and center legs. It may be necessary to pull both legs towards each other in order for the holes to align properly.
  • Page 8 Step Illustration Instructions Hardware Reference Secure the deluxe glider brackets with Part Ref. #: PSHW35, PSHW22 the V-screws and the bolts at the squared portions of the top bar. Remove the hardware from the arms of Part Ref. #: PSHW21, PSHW36 the brackets.
  • Page 9 Remove the pre-inserted hardware from the end sections. Then connect the seat section to the end sections by lining up the holes and reinserting the hardware. Once fully assembled, hang the chains from the swing hooks attached to the bracket bars. Ensure that the glider moves freely at the hinge points where the seat section connects to the end sections.
  • Page 10 LAWN SWING ASSEMBLY Required Parts: Lawn Swing Attachment x2, Vertical Pole x4, Foot Plate x2, U-Shaped Hand Rail x4, Seat Support Bar x8, Seat/Backrest x4 Assembly drawing Completed Swing Step Illustration Instructions Hardware Reference Secure the lawn swing attachments with the Part Ref.
  • Page 11 Join the two footrest sections by twisting them together until the Playsafe™ logo aligns. Insert the foot plate support bar through the footrest. Using an adjustable wrench, attach the Part Ref. #: PSHW4 vertical poles to the foot plate support bar.
  • Page 12 Using the hardware provided on the U- Part Ref. # PSHW17 shaped hand rails, attach the seat support bars and backrests. NOTE: This step is identical to Step 8 for installing the seats. After fully assembled, ensure the lawn Part Ref. #: PSHW21, PSHW36 swing swings freely.
  • Page 13 Step Illustration Instructions Hardware Reference Remove the hardware from the frame Part Ref. #: PSHW10 attachment and connect the extension. Re- insert the hardware and tighten. NOTE: Be sure that the lower part of the see-saw extension is buried and anchored per the anchoring instructions on page 3.
  • Page 14 SLIDE ASSEMBLY Required Parts: Slide x1 Rail/Ladder Leg x2 Front Leg x2 Ladder Step x2 Link Bar x2 Proper Placement: Slide Assembly Correct Location Incorrect Location Pre-Assembled Parts: • The screws and bolts for the slide rail/ladder legs are inserted on the slide. They will need to be removed prior to inserting the legs into the slide.
  • Page 15 Locate the slide front legs and insert them into the Part Ref. #: PSHW24 front hand rail tubes, on the underside of the slide. Align the holes and secure with the screws, washers and lock nuts. Slide the two ladder steps onto the legs of the slide. Part Ref.
  • Page 16 Check all parts on all rides before allowing a child on the swing set. • Be sure to check and tighten the hardware on a regular basis to ensure the safety of the users. Your Playsafe™ Manchester II Swing Set should now be fully assembled! 2006 Pacific Cycle, Inc. ©...
