6. Replacement of Probe
Vilhelmsborgvej 15  DK-7700 Thisted  Tel.: (+45) 97990800  contact@wintexagro.com
Dismount the sensors.
Dismount the three cheese-head screws with a 5 mm hex key.
Screw two of the cheese-head screws in again in order to be able
to dismount the revolving platform by pulling it down.
Use the special key which comes along with the Wintex 2000 to
loosen the probe from the oil hammer.
Dismount the scraper. Then dismount the lower screws on each
side. Loosen the upper screws. Tilt the whole plate, and pull up
the probe.
