Masterclock TCDS Series User Manual

Digital clocks
Hide thumbs
Table of Contents

Advertisement

Quick Links

TCDS Series Digital Clocks
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TCDS Series and is the answer not in the manual?

Questions and answers

Related Manuals for Masterclock TCDS Series

Summary of Contents for Masterclock TCDS Series

  • Page 1 TCDS Series Digital Clocks User Manual...

  • Page 2: Table Of Contents

    TCDS Series User Manual Page 2 – Rev. 2.0.2 Table of Contents Forward ............................5 Disclaimer ....................................5 Copyrights ..................................... 5 Trademarks ................................... 5 Icons Used In This Manual ..............................5 Printing ....................................5 Compliance ............................ 6 CE Marking .................................... 6 FCC Statement ..................................
  • Page 3 TCDS Series User Manual Page 3 – Rev. 2.0.2 Specifications ..........................27 Communications I/O ................................27 Power Requirements ................................28 AC ....................................28 Internal Battery Circuit ............................... 28 Maintenance Free Rechargeable Battery ........................28 Operating/Storage Temperature and Humidity ......................... 28 Size and Weight ..................................
  • Page 4 TCDS Series User Manual Page 4 – Rev. 2.0.1 This page intentionally left blank.

  • Page 5: Forward

    Masterclock, Inc. assumes no liability resulting from errors or omissions in this document or from the use of the information contained herein. Masterclock, Inc. reserves the right to make changes or...

  • Page 6: Compliance

    TCDS Series User Manual Page 6 – Rev. 2.0.1 Compliance CE Marking Electromagnetic Compatibility 2004/108/EC Tested and Conforms to the following EMC standards : EN 55024:1998 +A1 +A2 EN 61000-4-2:1995 +A1:1998 +A2:2001 (Electrostatic Discharge) EN 61000-4-3:2000 +A1:2008 (RF Immunity) EN 61000-4-4:2004 (Fast Transient Common Mode)

  • Page 7: Weee

    RoHS directive. Exemption The TCDS series fall under the category of Monitoring and Control Instruments Equipment (Category 9 as defined in Annex 1A of WEEE 2002/96/EC Directive) which is excluded from the RoHS directive 2002/95/EC (reference Article 2, paragraph 1) requirements.

  • Page 8: Introduction

    DST feature requires that the clock be enabled to accept the time code date encoding, using the USB port and TCD-Set software application. The time code source must provide date encoding in the control bits/fields to the Masterclock/Leitch date encoding standard for SMPTE or the IEEE-1344 year encoding for IRIG-B.

  • Page 9: General Use Precautions

    Manual carefully, and follow the correct procedure when setting up the device. Do not open your Masterclock product or attempt to disassemble or modify it. Never insert any metallic object into the clocks case, doing so increases the risk of electrical shock, short circuiting, fire or personal injury.

  • Page 10: Unpacking And Installation

    TCDS Series User Manual Page 10 – Rev. 2.0.1 Unpacking and Installation Supplied (Ship Kit) The list below is for illustration purposes. Refer to your sales order for actual items shipped. • TCDS digital clock/date display • Mounting bracket • CD-ROM (TCD-Set USB Configuration Utility and User Manual) •...

  • Page 11: Connections

    TCDS Series User Manual Page 11 – Rev. 2.0.1 Connections Un-balanced Signal: Connect the 50 ohm (Ω) Balanced Signal: Secure the wires (not included) to RG59 coaxial cable (not included) to the BNC the terminal block, located on the back panel.

  • Page 12: Mounting

    TCDS Series User Manual Page 12 – Rev. 2.0.1 Mounting The TCDS digital time display is designed for table, wall or rack mount. Power and low voltage signal wiring should be installed according to local electrical codes, so to access the back of the clock.
  • Page 13 TCDS Series User Manual Page 13 – Rev. 2.0.1...

  • Page 14: Rack Mount Bracket

    TCDS Series User Manual Page 14 – Rev. 2.0.1 Rack Mount Bracket Attach the time code cable and power cord, and then secure the clock to the equipment rack or cabinet. Swivel Mount Bracket Mount both swivel brackets to the wall, attach the time code cable and power cord and secure...
  • Page 15 TCDS Series User Manual Page 15 – Rev. 2.0.1 This page intentionally left blank.

  • Page 16: Operating Environment

    TCDS Series User Manual Page 16 – Rev. 2.0.1 Operating Environment The TCDS contains microprocessor control electronics designed to operate indoors between 32˚ to 140°F (0˚ to 60˚C) with 0-90% relative humidity, non-condensing. The TCDS is not water or moisture proof. Treat it as you would any other delicate electronic device and do not expose it to water, excessive heat or physical abuse.

  • Page 17: Time Zone Offsets

    Masterclock’s GPS200A time code generator. For SMPTE time codes, date must be encoded to the Leitch specification. IRIG-B date decoding is supported for the IEEE 1344 standard. Masterclock’s master clock system also supports these specifications. Pre 2007 Standard – U.S.A. and Canada Traditional US/Canada daylight/summer time is configured as one (1) hour positive bias.

  • Page 18: Freewheeling Accuracy

    TCDS Series User Manual Page 18 – Rev. 2.0.1 Freewheeling Accuracy The TCDS has built-in provisions to allow the clock to freewheel and maintain accuracy for extended periods in the absence of time code. These features also allow the unit to be set manually and run without time code with precision.
  • Page 19 TCDS Series User Manual Page 19 – Rev. 2.0.1 This page intentionally left blank.

  • Page 20: Tcd-Set

    To install the software program on your Windows server, workstation or PC, complete the following steps. 1. Insert the CD, “Time Code Products”, supplied with your time display. 2. Run “Setup_TCD-Set.exe” executable file from the TCDS folder. By default, the setup utility will install the files to C:\Program Files\Masterclock\TCD-Set\.

  • Page 21: Usb Device Driver

    TCDS Series User Manual Page 21 – Rev. 2.0.1 USB Device Driver A USB type B port has been included on the rear cover of the clock to provide a means of configuring the clock via software and to allow for firmware upgrades for either firmware corrections or future product enhancements.

  • Page 22: Using Tcd-Set, Usb Configuration Utility

    The time shown is not perfectly in sync with that displayed by the clock, but is meant to give a view of the clock display for basic troubleshooting and maintenance purposes. This is a screenshot of a TCD-Set when connected to a typical TCDS clock from Masterclock:...
  • Page 23 TCDS Series User Manual Page 23 – Rev. 2.0.1 This is a screenshot of TCD-Set when connected to a TCDS112, which has two 6-digit display sections, so it can display a second time with its own time zone and DST settings: Click [Apply] from the main window to save the modified settings made from the sub-menus (i.e.

  • Page 24: Time Zone Offset

    TCDS Series User Manual Page 24 – Rev. 2.0.1 Time Zone Offset Modify the time zone by clicking the [Time Zone] button. This opens a new window that gives you a list of time zones, including descriptions to help with the selection. Select the desired time zone and click [OK] to close the window.

  • Page 25: Time Code Settings

    TCDS Series User Manual Page 25 – Rev. 2.0.1 Time Code Settings To use the automatic DST adjustments requires that date/year encoding is enabled. This product contains an automatic detection and gain control circuit for the incoming SMPTE 30/25/24 fps longitudinal/linear time code or for IRIG-B(0) pulse width modulated or IRIG-B(1) amplitude modulated time code.

  • Page 26: Set Date Time

    TCDS Series User Manual Page 26 – Rev. 2.0.1 Set Date Time The [Set Date Time] feature lets you manually set the time and date for the clock. This may be most useful for lab situations as the clock keeps time via its internal precision oscillator and real- time clock when time code is not present.

  • Page 27: Specifications

    TCDS Series User Manual Page 27 – Rev. 2.0.1 Specifications Communications I/O USB……………………........B type connect Format……………………………………………………..v1.1 DST supported Time Code Formats Masterclock/Leitch IEEE - 1344 Date Encoding Year Encoding SMPTE – 30 fps √ SMPTE – 25 fps (EBU) √...

  • Page 28: Power Requirements

    AC Input Connector ......... Universal IEC input connector AC power consumption ......10 W There are no user serviceable parts inside the TCDS digital clock. Please contact Masterclock, Inc. if you require servicing or repair. Internal Battery Circuit Maintenance Free Rechargeable Battery...

  • Page 29: Care And Cleaning

    TCDS Series User Manual Page 29 – Rev. 2.0.1 Care and Cleaning Adherence to regular and proper cleaning procedures is recommended to preserve appearance. Scratched or otherwise damaged lens caused by misuse, mishandling and improper storage or improper cleaning is not covered under the limited warranty.

  • Page 30: Minimize Hairline Scratches

    TCDS Series User Manual Page 30 – Rev. 2.0.1 Minimize Hairline Scratches Always store the clock face-up in the protective plastic shipping bag until ready for installation and during transporting to the installation site. Do not place the clock face (lens surface) down on any surface as this may scratch or mar the lens.

  • Page 31: Troubleshooting

    There are no user serviceable parts inside the TCDS digital clock/display. Please contact Masterclock, Inc. if you require servicing or repair. Clock is displaying dashes (- - - - ) and/or colon’s are flashing (i.e. unable to “lock” to time code) Possible reasons/solutions: 1.

  • Page 32: Not Displaying The Correct Local Time And/Or Date

    4. If you are using a time code source from another vendor, be certain your time code contains encoded year/date information to the IEEE 1344 [IRIG-B] or Masterclock/Leitch [SMPTE] time code encoding formats. IRIG-B(0)/B(1) time code format must have the year/date encoded to the IEEE 1344 specification in the CF (Control Functions).

  • Page 33: Limited Warranty

    Masterclock warrants this product against defects in materials and workmanship for a period of one year from date of sale. If Masterclock receives notice of such defects during the warranty period, Masterclock will, at its option, either repair or replace products that prove to be defective.

  • Page 34: Service Information

    – Rev. 2.0.1 Service Information We sincerely hope that you never experience a problem with any Masterclock product. If you do need service, contact Masterclock’s Technical Support team. A trained specialist will help you to quickly determine the source of the problem. Many problems are easily resolved with a single phone call or email.
  • Page 35 Masterclock, Inc. 2484 West Clay St. St. Charles, MO 63301 +1-(636)-724-3666 1-800-724-1778 support@masterclock.com sales@masterclock.com...

This manual is also suitable for:

Tcds26Tcds29
