1 Instruction
1.1 Summary
Plugging into your computer's USB port, you can make and
receive Skype calls. It's Commercial speakerphone in high grade
of quality having large LCD with backlight. Phone rings for all
incoming calls. You can dial Skype numbers on the phone.
1.2 Features
1. Commercial speakerphone in high grade of quality, ideal for
conference calls
2. Large LCD with backlight
3. Phone rings for incoming calls, ring style and volume selectable
4. Dial Skype contacts and skypeout number by phone keypads
5. Caller ID function of Skype incoming calls
6. Echo cancellation, noise reduction, full duplex communication
1.3 System Requirements
1. Windows 2000 or XP
2. 400MHz processor and free USB1.1 or USB2.0 port
3. 128MB RAM and 15MB free disk space
4. Any broadband connection or minimum 33.6 Kbps dialup
1.4 Package Contents
1. one USB Speaker Phone
2. one User Manual
3. one USB Cable
4. one Installation CD
1
Advertisement
Summary of Contents for Waytec USB Speaker phone
- Page 1 2. 400MHz processor and free USB1.1 or USB2.0 port 3. 128MB RAM and 15MB free disk space 4. Any broadband connection or minimum 33.6 Kbps dialup 1.4 Package Contents 1. one USB Speaker Phone 2. one User Manual 3. one USB Cable 4. one Installation CD...
-
Page 2: Keypad Instruction
2 Using the USB Speaker Phone 2.2 Run Skype 2.1 Keypad Instruction (1) Download Skype software and install it (www.skype.com). The version must be 1.0.0.106 or higher. (2) Run Skype and log in with Skype account. VOL+ VOL- You can create a Skype account as shown below:... -
Page 3: Run Skypemate
2.3 Connect USB Speaker Phone to PC When USB Speaker Phone is connected to PC, the LCD shows "VOIP-PHONE". 2.4 Run SkypeMate That indicates the device and Skype are connected successfully. (1) Insert SkypeMate installation CD or download SkypeMate If the icon shown as (the phone is green and the outside is software, then install it. -
Page 4: Call To Normal Phone
The second incoming Skype call will be refused Credit from www.skype.com first. when talking. 2.7 Answer a call When USB Speaker Phone is ringing for an incoming call, pick up handset or press handfree key to answer the call. - Page 5 (except incoming call and outgoing call). (6) Ring style: They are 10 types of incoming ring (0-9). You can press “#” on USB Speaker Phone to select it when the phone is at ready state. You can select it in “Advanced” windows too.
- Page 6 The voice is heard from the computer’s sound card instead of the You have selected the wrong option when you installed USB Speaker Phone when I make or answer a call? SkypeMate (the phone’s driver). Go to “Tools -> Options ->...
