IMPORTANT MANUAL
OWNER'S MANUAL
MODEL NUMBER:
961980019
SNOW THROWER
Always Wear Eye Protection During Operation
Do Not Throw Away
WARNING:
Read the Owner's Manual and
fol low all Warnings and Safety
In struc tions. Fail ure to do so
can result in serious injury.
415324 Rev 1 09.19.07 TH
Printed in the U.S.A.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 961980019 and is the answer not in the manual?

Questions and answers

Related Manuals for Poulan Pro 961980019

Summary of Contents for Poulan Pro 961980019

  • Page 1 IMPORTANT MANUAL Do Not Throw Away OWNER'S MANUAL MODEL NUMBER: WARNING: 961980019 Read the Owner's Manual and fol low all Warnings and Safety In struc tions. Fail ure to do so SNOW THROWER can result in serious injury. 415324 Rev 1 09.19.07 TH Always Wear Eye Protection During Operation Printed in the U.S.A.

  • Page 2: Auger Housing / Impeller Assembly

    SNOW THROWER - MODEL 961980019 (96198001900) REPAIR PARTS AUGER HOUSING / IMPELLER ASSEMBLY...
  • Page 3 SNOW THROWER - MODEL 961980019 (96198001900) REPAIR PARTS AUGER HOUSING / IMPELLER ASSEMBLY PART PART DESCRIPTION DESCRIPTION 191079 Pulley, Impeller 405976X479 Auger Assembly, LH 188909 Bearing Assembly, Flange 407768 O-Ring 155377 Nut, Hex Flange 5/16-18 407769 Bushing, Flange 3/4 180355...

  • Page 4: Control Panel / Discharge Chute

    SNOW THROWER - MODEL 961980019 (96198001900) REPAIR PARTS CONTROL PANEL / DISCHARGE CHUTE...

  • Page 5: Repair Parts

    SNOW THROWER - MODEL 961980019 (96198001900) REPAIR PARTS CONTROL PANEL / DISCHARGE CHUTE KEY PART DESCRIPTION 414280 Knob, Lever, Black 17501010 Screw #10-24 x 5/8 198475 Control, Cable, Deflector 73800600 Nut, Lock 3/8-16 19131316 Washer, Flat 3/8 404974 Control Assembly, Chute Rotater...
  • Page 6 SNOW THROWER - MODEL 961980019 (96198001900) REPAIR PARTS HANDLES...
  • Page 7 SNOW THROWER - MODEL 961980019 (96198001900) REPAIR PARTS HANDLES KEY PART DESCRIPTION 412682X479 Lever, Auger Control, RH 412681X479 Lever, Traction Drive Control, LH 169675 Retainer, Hairpin 17060408 Screw, Hex Head 1/4-20 x 3/4 412677 Bail, Interlock 196333X008 Arm, Impeller Rod...
  • Page 8 SNOW THROWER - MODEL 961980019 (96198001900) REPAIR PARTS DRIVE...
  • Page 9 SNOW THROWER - MODEL 961980019 (96198001900) REPAIR PARTS DRIVE KEY PART DESCRIPTION 401619 Chain, Drive 751153 Nut, Lock 5/16-18 402882 Clip, Retainer 17490508 Bolt, Hex Head 5/16-18 x 1/2 408981 Bearing, Flange 12000007 E-Ring, Retainer 402855 Sprocket & Shaft Assembly...

  • Page 10: Chassis / Engine / Pulleys

    SNOW THROWER - MODEL 961980019 (96198001900) REPAIR PARTS CHASSIS / ENGINE / PULLEYS 10 21 6 42...
  • Page 11 SNOW THROWER - MODEL 961980019 (96198001900) REPAIR PARTS CHASSIS / ENGINE / PULLEYS KEY PART KEY PART DESCRIPTION DESCRIPTION 414557 Spring, Traction Idler 851084 Screw, Hex Head 3/8-24 x 1-3/8 180522 Pulley, Idler (2-1/4) 155452 Guide, Belt - - -...
  • Page 12 SNOW THROWER - MODEL 961980019 (96198001900) REPAIR PARTS WHEELS / DECALS...
  • Page 13 SNOW THROWER - MODEL 961980019 (96198001900) REPAIR PARTS WHEELS / DECALS KEY PART DESCRIPTION 187833X421 Wheel Assembly, 16", LH 155443 Pin, Klik 1/4 187865X421 Wheel Assembly, 16", RH 146315 Screw, Hex Head, Tapping 5/16-18 x 5/8 179830 Bearing, Axle 174697 Washer, Thrust (1")

  • Page 14: Limited Warranty

    LIMITED WARRANTY The Manufacturer warrants to the original consumer purchaser that this product as manufactured is free from defects in materials and work man ship. For a period of two (2) years from date of purchase by the original consumer pur- chaser, we will repair or replace, at our option, without charge for parts or labor incurred in replacing parts, any part which we find to be defective due to materials or workmanship.
