Summary of Contents for Purple Line SeaGo
- Page 1 Boat Trailer Mover PATENT PENDING USER MANUAL design...innovate...improve Purple Line Document Reference SGO130-1304 SGO130-1304 SeaGo User Manual vs2.indd 1 3/05/2013 3:47:50 PM...
- Page 2 ANGULAR: DRAWN CHK'D APPV'D NAME SIGNATURE DETAIL B DATE SCALE 1 : 5 NOTES: Illustration purposes only Page 2 UNLESS OTHERWISE SPE DIMENSIONS ARE IN M SURFACE FINISH: TOLERANCES: LINEAR: SGO130-1304 SeaGo User Manual vs2.indd 2 3/05/2013 3:47:55 PM ANGULAR:...
-
Page 3: Table Of Contents
Retaining Pins (Not illustrated) Engagement Handle Positive (+) Red Battery Cable 1.8M Negative (-) Black Battery Cable 1.8M Before assembling and installing SeaGo™ check that all components have been supplied? Page 3 SGO130-1304 SeaGo User Manual vs2.indd 3 3/05/2013 3:47:56 PM... -
Page 4: Introduction
It will also aid in hitching and de-hitching the Boat Trailer from the tow vehicle. SeaGo™ features a quick release mount that allows the Power Mover to be swiftly installed and un-installed. When un-installed you can then and only then immerse the Boat Trailer into water to prevent corrosion and damage to the motor and gearbox and also prevent damage whilst the Boat Trailer is in transit and secure the unit from theft. -
Page 5: Installation Pre-Check Guidelines
Boat Trailer unless it is correctly secured by Prop-Jacks or Ramps and Wheel Chocks. Use an appropriate jacking product. 6. Unpack all the SeaGo™ components and ensure all are accounted for by checking them against the Packaged Contents list, as featured on Page 3 and listed Page 3. -
Page 6: Mechanical Assembly And Installation
Mechanical Assembly and Installation Diagram 1a: SeaGo Disengaged from Rollers Diagram 1: SeaGo Disengaged Position 20mm Gap 20mm Gap between roller & tyre Silder Bolts Slots Diagram 2: SeaGo to Disengaged Diagram 7: Mounting & Securing SeaGo Engagement Handle Slot for... - Page 7 1. Prior to commencing assembly, check that SeaGo™ is set in the disengaged position. SeaGo™ is set in the disengaged position when the Slider Bolts are positioned to the right of the Slots. Refer Diagram 1. 2. If SeaGo™ is set in the engaged position, insert the Handle into the Spindle and rotate clock-wise. Refer Diagram 2.
-
Page 8: Electrical Wiring Diagram
Power Movers SeaGo™ is supplied with a Battery Wiring Loom designed to connect to the Electronic Control Module and battery. Additionally, it has a two wiring looms that connect to the Electronic Control Module which include an Anderson Plug at the other end to connect to the Anderson Socket on the Power Movers. -
Page 9: Remote Control Handset
REMOTE CONTROL HANDSET OPERATION: SeaGo™ is supplied with a Remote Control Handset powered by three ‘AAA’ 1.5V batteries. The Remote is activated by pressing the Power Button (A) twice within 1 second. Once activated the Green LED will illuminate and the directional control buttons can now be accessed to move the Boat Trailer. -
Page 10: Pairing The Remote
PAIRING THE REMOTE: SeaGo™ is supplied by the factory with the Remote already paired to operate in single axle mode. Should you ever need to replace a Remote or set it up to operate in Dual Axle mode, follow these instructions. -
Page 11: Single Axle And Dual Axle Configurations
As advised on the previous page, the Electronics Unit with SeaGo™ is supplied by the factory to operate in single axle mode. The following procedures instruct you how to set the Remote up to operate in either single or dual axle modes. -
Page 12: Operating Safety Guidelines
The following safety guidelines will enable you to gain maximum benefit when using SeaGo™ and be able to operate safely. Accordingly please note the guideline and warnings. Before use check that there is no damage to the Boat Trailer or SeaGo™ that could affect its performance. -
Page 13: Operating Instructions
11. SeaGo™ will move the Boat Trailer at one speed (12cm per second) after an initial soft start. The speed may increase a little when descending and decrease a little when ascending. Note SeaGo™ is slightly more effective at reversing the Boat Trailer up an incline than moving it forward up an incline. -
Page 14: Trouble Shooting
‘AAA’ batteries. Refer page 10 to install batteries in the remote. Check that the 12V Battery used to power SeaGo™ is fully charged. The Control Unit will indicate if the charge in the battery is low when the Blue LED is on and the Red LED is flashing twice slowly. If the charge is low, recharge the battery or if this fails to improve the level of charge in the battery, replace it. -
Page 15: Maintenance Instructions
If the battery used to power SeaGo™ is not going to be used for long periods and is not charged by a trickle charger, it is recommended that the battery be disconnected from the Control Unit to prevent it from becoming completely discharged. - Page 16 5/238 Governor Road, Braeside, VIC 3195 +61 (3) 9588 2959 enquiries@purpleline.com.au www.purpleline.com.au SGO130-1304 SeaGo User Manual vs2.indd 16 3/05/2013 3:48:20 PM...
