- Page 1 User’s Manual 8CH DVR & ’ & ’ 8-Channel Standalone DVR Installation Guide & User’s Manual Version 2.54 - 0 -...
-
Page 2: Table Of Contents
User’s Manual 8CH DVR Directory 1. DVR FEATURE......................3 2. OUTLOOK ........................3 2.1 F ......................3 RONT ANEL 2.2 R .......................4 ANEL 2.3 R ....................5 EMOTE ONTROLLER 3. DVR INSTALLATION.....................5 3.1 I .....................5 NSTALL 3.2 C .................6 ONNECT AMERA AND ONITOR 3.3 C ....................6 ONNECT OWER... - Page 3 User’s Manual 8CH DVR 5.7 L ........................18 ANGUAGE 5.8 E .........................18 5.9 NTSC/PAL O ..................18 UTPUT ELECT 6. RECORD........................19 6.1 S ....................19 TART ECORDING 6.2 S .....................19 ECORDING 6.3 R ....................20 ECORDING ENGTH 7. PLAYBACK .........................21 8. BACKUP........................21 9. NETWORK........................22 9.1 H ....................22 ARDWARE...
-
Page 4: Dvr Feature
User’s Manual 8CH DVR 1. DVR Feature 8 Channel BNC Camera Input. 2 Channel BNC Monitor Output. Support Network: Static, DHCP. USB 2.0 Port For Backup And Playback With PC. VGA Output (Optional). NTSC / PAL. Video Loss Alarm. Motion Detection With Area Setting. PTZ Control With RS485 Port. -
Page 5: Rear Panel
User’s Manual 8CH DVR 1. PTZ Indicator 2. Network Indicator 3. HDD Access Indicator 4. Power Indicator 5. Enter/Exit Menu Setup 6. Move Prompt Up 7. Modify Item 8. Full Screen /Move Dome UP/Move Prompt Up In Motion Area 9. Channel Up/Move Dome Down/Move Prompt Down In Motion Area 10. -
Page 6: Remote Controller
User’s Manual 8CH DVR 2.3 Remote Controller 1. FULL One CH View or Move Dome Up 2. ALL All CH View 3. UP CH. UP CH View or Move Dome Down 4. QUAD Quad View or Move Dome Right 5. DOWN CH. DOWN CH View or Move Dome Left 6. -
Page 7: Connect Camera And Monitor
User’s Manual 8CH DVR 3.2 Connect Camera and Monitor There are eight cameras input and two monitors output with BNC connector. 3.3 Connect Power Cord Please use the power adapter supplied with DVR. 4. DVR System Boot 4.1 Detect Installed Hard Disk After connecting the power, system will boot-up firmware, date, video and detect installed hard disk. -
Page 8: Dvr Setup
User’s Manual 8CH DVR 5. DVR Setup Press “ Menu” into setup menu, use “ Up” and “ Down” to select item, then press“ Select” to modify setting and “ Menu” to confirm and exit. Menu Directory Camera Record Frame Rate Record Quality Record Record Schedule... -
Page 9: Record
User’s Manual 8CH DVR The button 「 Select」can increase value and the button 「REC」can reduce value. 5.2 Record Press 「 Up」 or 「 Down」 to move the prompt. Press 「 Select」to enter each sub menu, and press 「 Select」 or 「REC」 to modify each parameter. -
Page 10: Alarm
User’s Manual 8CH DVR To start motion record, make sure the period that you intend to record is “ ” in the “record Notice: schedule” menu. To start sensor record, make sure the period that you intend to record is “ ”in the “record schedule”... -
Page 11: Sensor
User’s Manual 8CH DVR EVENT REC DURATION The number indicates how long triggered recording lasts after the sensors are triggered or the movements in front of the camera. 5.3.1 Sensor There are three different modes for sensor setting: NONE & N.C & N.O. NONE means NOT INSTALLED, N.C means NORMAL-CLOSE, N.O means NORMAL-OPEN. -
Page 12: Motion
User’s Manual 8CH DVR Install example diagram: 5.3.2 Motion The first step, User need setup video record method by Motion Triggered. Please make Reference to 5.2.3. CHANNEL 1~8 SENSITIVITY: User can press [ Select] or [REC] to adjust sensitivity grade of motion detection. High (1----------4,OFF) Low When it is set to “OFF”, the channel can’t be trigger by movement. -
Page 13: Audio
User’s Manual 8CH DVR to move right. By the way, the area only can be selected from up to down and from left to right. When the block is covered by blue shadow, it’s active to record. When the block is transparent, it can’t be recorded. -
Page 14: Hard Disk Setup
User’s Manual 8CH DVR All numbers, letters and sign in the pane can be used as password. The default password of System is pressing six times of “1”. 5.5.2 Hard Disk Setup OVERWRITE ENABLE: If you choose ON, the recording continues and overwrites previous recording when hard disk drive space is full. -
Page 15: Time Setup
User’s Manual 8CH DVR 5.5.3 Time Setup Press「 Up」and「 Down」to move prompt and press 「 Select」 or 「REC」 to modify. User can select time zone. After confirming time zone, configure DVR system time. Move the prompt to the order of “APPLY”, and then press to confirm. -
Page 16: Ptz Setup
User’s Manual 8CH DVR 5.5.5.1 Local IP In the menu of “Local IP” user can set up IP type. IP type includes static and DHCP. If IP type is static, user can adjust the order of “IP address, gateway and net mask”. 5.5.5.2 Name Server Press 「... -
Page 17: Button Function
User’s Manual 8CH DVR ADDRESS: Dome’s address “0-255” (PELCO-D) and”0-31” (PELCO-P). PROTOCOL: Including “PELCO-D”, “PELCO-P”. Setting the protocol according to the dome’s protocol. BAUD RATE: Press “EDIT” button to select the value 1200,2400,4800,9600,19200bps. SPEED: Having “1-10” to select. PRESET: If protocol is PELCO-D, preset includes “1-32”. If protocol is PELCO-P, preset includes “1-255”. -
Page 18: Screen Adjustment
User’s Manual 8CH DVR the dome according to the method of above paragraphs. 5.5.7 Screen Adjustment Press「Select」button accessing to “ Screen Adjustment”. Press 「CH1」button to move the screen up, press 「CH2」 button to move down, press 「CH3」 button to move left, press 「CH4」 button to move right. 5.5.8 Key lock “KEY LOCK”... -
Page 19: Language
User’s Manual 8CH DVR 5.7 Language Press the button 「Select」to change language. 5.8 Exit Press「Select」button accessing to “ EXIT”, and press 「UP」or 「DOWN」to move the prompt, then press 「Select」to confirm. When choose the order of “Exit & Save Changes”, it will come back to live view and the setting will be saved. -
Page 20: Record
User’s Manual 8CH DVR 6. Record 6.1 Start Recording Press “ Record” to start recording. System will display some information on Screen. Note: When the DVR is recording, user can play back or handle menu bar simultaneously. ① Channel Name Recording Symbol ②... -
Page 21: Recording Length
User’s Manual 8CH DVR 6.3 Recording Length The lengths of record time based on 250G HDD are estimated as follows, using eight cameras:(just for reference) Record Frame Data Rate Record Time Format Record Quality Rate (GB/Hour) (Hour) High 5.85 50F/Sec Normal 4.59 2.48... -
Page 22: Playback
User’s Manual 8CH DVR 7. Playback Press “ Play” then system will list the time of all videos from HDD. Press “ Select” and then press “ Up” and “ Down” to move prompt. Press “ Select” to edit time value and press “ Menu ”to confirm. -
Page 23: Network
User’s Manual 8CH DVR interface. And then press [Select] to start copying. During backup “Writing to disk” is always displaying in the menu. After complete backup there will be a piece of suggestive message“Complete”, press 「MENU」to return to live view. Note: Complete backup once, user must pull out USB disk. -
Page 24: Connect Pc To Dvr-Net Viewer
User’s Manual 8CH DVR For example: Configure PC address as 192.168.1.171. Windows XP: Click “Start”→ “Settings”→ “Control Panel”→ “View”→ Double click the “Network Connections ” icon. Find ”Local Area Connection” and Right Click and select ”Properties”. Find ”Internet Protocol [TCP/IP]” and click “Properties”. Select ”Use the following IP address” and ”Use the following DNS server address”, and then input IP value. -
Page 25: Program Interface
User’s Manual 8CH DVR 2. Go for installing by setup. 3. Set up the install directory. 4. Execute: 1.Start >Program> VxViewer8Ch. 2.Start>Program> VxDDns. 9.4.2 Program Interface A: Run Vxviewer8Ch. 1. Double click “ ” icon on desktop to run the program. 2. - Page 26 User’s Manual 8CH DVR B: Run VxDDns. Make use of VxDDns, user can connect synchronously many DVRs to one PC. First set up DVR, enter menu bar “Network Settings”, adjust “Network” is “ON”, select order of “Name Server”. On the interface of “Name Server”, make sure “Network” is “ON”, “IP Address” is the PC which is connected to the DVR, “Port”...
-
Page 27: Button Function
User’s Manual 8CH DVR 9.4.3 Button Function 1. Connect/Disconnect 2. Pause 3. Rewind 4. Play 5. Fast forward 6. Stop playing or Dome running 7. Record or stop recording or Reduce Value 8. Split 9 9. Channel 1 10. Channel Up 11. -
Page 28: Local Recording
User’s Manual 8CH DVR 9.4.4 Local Recording User can save current view into PC.Click→”Start Local Recording” to start recoding. According to the following method to setup storage path for recording. Click “the right button of the mouse”→ ”Options…”. In the bar “Path for local recording” setup. 9.4.5 Play Local Recording Click “... -
Page 29: Connect Pc To Dvr - Ie Browser
User’s Manual 8CH DVR Still Capture In the player mode, click the right button of the mouse to select “Options…” to setup path for still capture. 9.5. Connect PC to DVR — IE Browser At first please turn all the Active X option ON at IE Internet safety setup. Select menu setup to enable the Active X option. - Page 30 User’s Manual 8CH DVR Open IE browser and input IP address of DVR in address bar. Press “Enter ” to connect PC to DVR. In the interface of “Viewer Player”, input “IP”、”PORT”、”PASSWORD” of DVR, then click ”CONNECT” to enter live view of DVR. Click buttons on the right to control DVR directly though network. NOTE: All the button functions on the right are the same as DVR’s.
-
Page 31: Optional
User’s Manual 8CH DVR 10. Specification ITEM DESCRIPTION NOTE Video Format NTSC / PAL Operation System None STAND-ALONE Camera Input Channel 8 channel Composite BNC Video Output Channel 2 channel Composite BNC Max. 30 frames/s NTSC Max 60 fps (Total) (Each Channel) Recording Frame Rate Max. -
Page 32: Appendix
User’s Manual 8CH DVR 11. Appendix 11.1 System Connect Sketch Map 11.2 Fittings Come Along With DVR - 31 -...
