Summary of Contents for Hydro Spa Mark lll
- Page 1 Owner ’ s Manual Owner ’ s Manual...
- Page 2 This Owner’s Manual will acquaint you with the operation and general maintenance of your new Hydro Spa Mark lll Spa. Please keep this manual available for reference. If you have any questions about any aspect of your spa’s set up procedures, operation or maintenance, contact your authorized Hydro Spa dealer.
-
Page 3: Table Of Contents
Methods For Testing Spa Water Basic Chemical Safety Water Terminology SPA WATER MAINTENANCE & TROUBLESHOOTING SPA CARE AND MAINTENANCE RECORD WARRANTY WARRANTY REGISTRATION IMPORTANT: Hydro Spa, Reserves the right to change specifications, or design, without notification and without incurring any obligation. -
Page 4: Important Safety Instructions
WARNING SIGN MUST BE POSTED The Warning sign (RED) is packed with your new Hydro Spa. This sign must be posted in a prominent place in close proximity to the spa installation site immediately upon completion of spa installation. - Page 5 IMPORTANT SAFETY INSTRUCTIONS WARNING: To reduce The Risk of Injury: 1. The water in a spa should never exceed 104°F (40°C). Water temperatures between 100°F (38°C). and 104°F(40°C) are considered safe for a healthy adult. Lower water temper- atures are recommended for young children and when hot tub use exceeds 10 minutes. 2.
- Page 6 IMPORTANT SAFETY INSTRUCTIONS WARNING: Do not use drugs or alcohol before or during the use of a hot tub to avoid unconscious- ness and possible drowning. WARNING: Pregnant or possibly pregnant women should consult a physician before using a hot tub. WARNING: Water temperature in excess of 40°C (104°F) may be injurious to your health.
- Page 7 IMPORTANT SAFETY INSTRUCTIONS 4. Do not use the spa under influence of alcohol, narcotics, or other drugs. Use of the spa under these conditions may lead to serious consequences. 5. Always test the spa water temperature before entering the spa . Enter and exit the spa slowly. Wet surfaces can be very slippery.
-
Page 8: Choosing A Location
CHOOSING A LOCATION Outdoor Location In selecting the ideal outdoor location for your spa, we suggest that you take into consideration: 1. The proximity to changing area and shelter (especially in colder weather conditions). 2. The pathway to and from the spa (free of debris, dirt, leaves as not to be tracked into spa). -
Page 9: Wiring Diagram Hs200 System
WIRING DIAGRAM HS200 SYSTEM Figure 1... -
Page 10: Wiring Diagram Hs200M7
WIRING DIAGRAM HS200 M7 SYSTEM Figure 1b... -
Page 11: Gfci Wiring Diagram
GFCI WIRING DIAGRAM Figure 2... -
Page 12: Electrical Wiring Instructions
ELECTRICAL WIRING INSTRUCTIONS Important Notice: When installed in the United States, the electrical wiring of this spa must meet the requirements of the National Electric Code (NEC) and any applicable state or local codes. The electrical circuit must be installed by an electrical contractor and approved by a local building/electrical inspector. 1. -
Page 13: Equipment Area Diagram
EQUIPMENT AREA DIAGRAM Spa Cabinet Light Figure 3 Power Inlet Control Electrical Door Panel Equipment Pack Spa Drain Door Panel Screws CONTROL BOX - INSIDE VIEW Fuses Wiring Connections Figure 4 Ground Heater Tube Heater Element Inside Tube White Figure 5 Neutral Black CONTROL BOX WIRING... -
Page 14: Start-Up Instructions Hs200
START-UP INSTRUCTIONS - HS200 CONTROL FOR BEST RESULTS, READ EACH STEP IN ITS ENTIRELY BEFORE PROCEEDING WITH STEP. Prepare The Hot Tub For Filling Clear all debris from the hot tub. Remove filter lid. Place the end of your garden hose into the empty weir filter and begin filling with clean water. -
Page 15: Operating Instructions Hs200
OPERATING INSTRUCTIONS - HS200 Figure 8 Main Control Panel Blower Warm Heat Indicator Indicators Cool Jets 1 Light Control Panel Display (Jets 2) Figure 9 Auxiliary Control Panel Blower Jets 1 Your spa is equipped with a Topside control panel, air control knobs, on-off waterfall valve and aroma -therapy canister. - Page 16 OPERATING INSTRUCTIONS - HS200 Jets 1 control Your spa is equipped with a two speed motor on pump 1. Depress the JETS1 pad to turn on pump 1(low speed), depress the JETS1 pad second time to turn on pump 1(high), and depress the JETS1 pad again to turn pump1 off. Corresponding spa jets will operate when pump 1 is on (low or high).
- Page 17 OPERATING INSTRUCTIONS - HS200 Once a day the pumps and blower turn on to prevent the spa water from becoming stagnant in the plumbing lines of the therapy jets and blower lines when the spa used very little and improves the skimmer action to remove debris and suspensions from the water surface, once per day at the start first “filtration”...
-
Page 18: Display Messages Hs200
DISPLAY MESSAGES - HS200 Panel messages are very helpful to the user about the status of the spa and gives a quick clue toward solving a variety of problems. Here are the most common messages you may see on the Display and what they mean. -
Page 19: Start-Up Instructions Hs200M7
START-UP INSTRUCTIONS - HS200 M7 FOR BEST RESULTS, READ EACH STEP IN ITS ENTIRELY BEFORE PROCEEDING WITH STEP. Prepare The Hot Tub For Filling Clear any debris from the hot tub. Remove filter lid. Place the end of your garden hose into the empty weir filter and begin filling with clean water. - Page 20 START-UP INSTRUCTIONS - HS200 M7 Cont. Add Start-Up Chemical as recommended by your dealer. Refer to Page 26 for general guidance. Place Cover On Hot Tub Keeping the insulating cover in place anytime the hot tub is not in use will reduce the time for heating, thereby minimizing operating costs.
-
Page 21: Operating Instructions Hs200M7
OPERATING INSTRUCTIONS - HS200 M7 Figure 8 Main Control Panel Blower Warm Heat Indicator Indicators Cool Jets 1 Light Control Panel Display (Jets 2) Figure 9b Auxiliary Control Panel Jets 2 Jets 1 Your spa is equipped with a Topside control panel, air control knobs, on-off waterfall valve and an aroma -therapy canister. - Page 22 OPERATING INSTRUCTIONS - HS200 M7 Jets 1 control Your spa is equipped with a two speed motor on pump 1. Depress the JETS1 pad to turn on pump 1(low speed), depress the JETS1 pad a second time to turn on pump 1(high), depress the JETS1 pad again to turn pump 1 off.
- Page 23 OPERATING INSTRUCTIONS - HS200 M7 pump constantly draws water from the spa, runs it through the filters and the heater, then back through return jets to the spa. The ozone output is on whenever the circula- ion pump is running. Twice per day the pumps and blower (if equipped) turn on to pre vent the spa water from becoming stagnant in plumbing lines of therapy jets and blower lines when the spa used very little and improves the skimmer action to remove debris and suspensions from the water surface, twice per day at the start of every filter cycle...
-
Page 24: Display Message Hs200M7
DISPLAY MESSAGES - HS200 M7 Message Meaning Action required No message on display. Power has been The control panel will be disabled until power returns. The system cut off to spa. reset the time of day on each power up. Spa settings are pre- served. -
Page 25: Spa Care And Maintenance
SPA CARE AND MAINTENANCE Draining Your Spa To drain your spa, perform the following steps: 1. Turn the power off. (Turn breaker off). 2. Select a safe, suitable drainage area capable of safely assimilating 300 plus gallons of water, which may contain both unsanitary contaminants and chemical residue that could cause harm to plants or grass. -
Page 26: Filter Cleaning And Cartridge Replacement
NOTES: Iron and copper in the water can stain the spa shell if allowed to go unchecked. Ask your Hydro Spa dealer about a stain and scale inhibitor to use if your spa water has a high concentration of dissolved minerals. -
Page 27: Care Of Spa Cover
SPA CARE AND MAINTENANCE Care Of Spa Cover To clean and condition the vinyl cover: Remove the cover from the spa and gently lean it up against a wall or fence. Using a garden hose, spray the cover to loosen and rinse away any dirt or debris. Using a sponge and/or a soft bristle brush, and using a very mild soap solution (one teaspoon dish- washing liquid with two gallons of water), or baking soda (sodium bicarbonate), scrub the vinyl top in a circular motion. -
Page 28: Water Quality And Maintenance
SPA CARE AND MAINTENANCE The following steps should protect your spa from freezing: Disconnect the spa from the power supply. Remove the screws holding your spa access panel door. Open the valve and the spa will drain by gravity flow. Remove the filter cartridge, then clean and store in a dry place. -
Page 29: Basic Chemical Safety
WATER QUALITY AND MAINTENANCE Basic Chemical Safety When using chemicals, always read the labels carefully and follow directions. Though chemicals protect you and your spa when used correctly, they can be hazardous in concentrated form. Observe the following guidelines: Allow only a responsible person to handle spa chemicals. KEEP OUT OF THE REACH OF CHIL- DREN. - Page 30 WATER QUALITY AND MAINTENANCE Once the CH is balanced, it normally remains stable, although the addition of more water with a high or low calcium content will raise or lower the CH reading of the water. When the Calcium Hardness is within the recommended range, proceed. Balancing The pH The recommended pH level for your spa water is 7.4-7.6.
-
Page 31: Water Terminology
WATER QUALITY AND MAINTENANCE Sanitizer is extremely important for killing algae, bacteria and viruses, and preventing unwanted organisms from growing in the spa. At the same time, you don’t want too high a sanitizer level, or it can irritate your skin, lungs, and eyes. Always maintain the sanitizer level in your spa at the recommended level for each type of sanitizer. -
Page 32: Spa Water Maintenance & Troubleshooting
MAINTENANCE & TROUBLESHOOTING... -
Page 33: Spa Care And Maintenance Record
SPA CARE & MAINTENANCE RECORD NOTES:... -
Page 34: Warranty
Disclaimers The spa owner is required to provide adequate access to the spa for any repair or inspection. Hydro Spa shall not be liable for loss of use of the spa or other incidental or consequential costs, expenses, or damages, which may include but are not limited to water damage, or the removal of a deck or custom fixture. Under no circumstances shall we or any of our representatives be held liable for injury to any person or damage to any property, however arising. -
Page 35: Warranty Registration
Hydro Spa. Our Mark lll Series offers the ultimate combination of luxury amenities, ease of use and intuitive design. Each Mark lll Series model is backed by the Hydro Spa name, reputation and warranty. WARRANTY REGISTRATION You may process your warranty registration by logging on to Hydro Spa at www.hydrospa.com. - Page 36 6101 N. 45th Street St. Petersburg, FL 33714 727-573-9611 Fax 727-573-7758 www.HYDROSPA.com Part # 7622 1 - 8 7 7 - B E S T - S P A 6101 N. 45th Street St. Petersburg, FL 33714...
