Hardware User Guide
DisplayPac-WN
Third Edition
© 2012 Computer Dynamics
Computer Dynamics is a division of Cimtec Automation. All rights reserved. No part of this publication
may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying,
recording, or otherwise without the prior written permission of Computer Dynamics.
This document contains Confidential/Proprietary Information belonging to Computer Dynamics.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Computer Dynamics DisplayPac-WN
- Page 1 © 2012 Computer Dynamics Computer Dynamics is a division of Cimtec Automation. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise without the prior written permission of Computer Dynamics.
- Page 2 Computer Dynamics warrants that each of its products will be free from material and workmanship defects for a period of one year from the invoice date. If the customer discovers a defect, Computer Dynamics will, at its option, repair or replace the defective product at no charge to the customer, provided it is returned during the warranty period of one year, with transportation charges prepaid.
-
Page 3: Important Safety Precautions
As a safety precaution, use a grounding wrist strap at all times. Place all electronic components in a static-dissipative surface or static-shielded bag when they are not in the chassis. DisplayPac-WN Hardware User Guide... -
Page 4: Safety And Warranty
-20° C (-4° F) or above 60° C (140° F), as this may damage the equipment. Unpacking After unpacking the DisplayPac-WN, check to ensure the following items are included and in good condition. Do not attempt to apply power to the system if there is damage to any of its components. -
Page 5: Table Of Contents
1.1. DisplayPac-WN Specifications......................1-1 1.2. LCD Selection Guide...........................1-1 2. Getting Started........................2-1 2.1. Input / Output Devices........................2-1 2.2. Starting the DisplayPac-WN and O/S Installation................2-1 3. Touch Driver Installation......................3-1 3.1. Introduction............................3-1 3.2. The ELO AccuTouch Driver Installation.....................3-1 3.2.1. Configuration Utility.......................3-2 4. DisplayPac-WN Mounting Guide...................4-1 4.1. -
Page 6: General Information
The Intel Core™ 2 Duo high performance processor delivers the most performance per watt available in the market. The DisplayPac-WN is designed to satisfy most of the applications in the industrial market, such as POS, KIOSK, Industrial Automation, HMI and Programmable Control System. It is a PC-based system with DDR2 SDRAM, VGA/LCD controller, four COM ports, and on-board 10/100/1000 Mbps Base-T Ethernet. -
Page 7: Getting Started
2. Getting Started 2.1. Input / Output Devices The following figure shows the I/O arrangement of the DisplayPac-WN. The backside of the chassis contains most of the connectors (10.4" is shown as an example). Brightness Adjustment Knob 5 Audio Jack... -
Page 8: Touch Driver Installation
The DisplayPac-WN supports the ELO AccuTouch touchscreen system, which consists of a touchscreen and an electronic touchscreen controller. The DisplayPac-WN touch device uses a RS-232 interface touch controller card via the COM3 port inside the DisplayPac-WN. When the touch driver is installed, the ELO system will detect COM4 port automatically. -
Page 9: Configuration Utility
Step 1. Enter “My Computer”, click the “ELO touchscreen” short-cut function. Step 2. Click “Align” function key to go to next step. Step 3. Correct 4 point locations on screen with the DisplayPac-WN. Screen display as follows. DisplayPac-WN Hardware User Guide... - Page 10 Step 4. Touch the “yes” function if the cursor follows your finger and finish the utility test. DisplayPac-WN Hardware User Guide...
-
Page 11: Displaypac-Wn Mounting Guide
4. DisplayPac-WN Mounting Guide The DisplayPac-WN is suitable for most industrial/commercial applications, by any kind of mounting approach. Three main mounting approaches: Panel Mount / Chassis / Open Frame are very easy for users to install, as the following illustrations show: 4.1. - Page 12 DisplayPac-WN Size VESA Mount Dimension VESA Mount Dimension 5.7" 75 x 75 mm 10.4" 75 x 75 mm 17" 75 x 75 mm 100 x 100 mm 19" 75 x 75 mm 100 x 100 mm DisplayPac-WN Hardware User Guide...
-
Page 13: Mm Panel Mount Displaypac-Wn
Panel is aligned with the front of the open frame metal housing • Touch/Glass is higher than open-frame metal housing. • Users can affix the DisplayPac-WN to their fixture (max. 12 mm) • VESA mount holes are also available for mounting from the rear. DisplayPac-WN Hardware User Guide... - Page 14 DisplayPac-WN Hardware User Guide...
-
Page 15: Mm Ip65 Displaypac-Wn
• Touch/Glass is aligned with the front of the open frame metal housing. • Users can affix the DisplayPac-WN to their fixture by M3 screws. • VESA mount holes are also available for mounting from the rear. DisplayPac-WN Hardware User Guide... -
Page 16: Chassis Displaypac-Wn
4.4. Chassis DisplayPac-WN Affix the DisplayPac-WN with four screws (standard VESA), and fasten to the wall with other four screws. • 100 x 100 mm • 75 x 75 mm DisplayPac-WN Hardware User Guide... - Page 17 DisplayPac-WN Size VESA Mount Dimension VESA Mount Dimension 5.7" 75 x 75 mm 10.4" 75 x 75 mm 12.1" 75 x 75 mm 15" 75 x 75 mm 100 x 100 mm 17" 75 x 75 mm 100 x 100 mm 19"...
-
Page 18: Known Issues
CMOS setting for panel [Flat Panel Type]. Lower resolution than CMOS setting in Windows may cause indistinct display. Recommendation in CMOS setting: • Choose “CRT” only when use external display. • Choose “Panel” only when use internal panel display. DisplayPac-WN Hardware User Guide... -
Page 19: Rma Request & Return Form
6. RMA Request & Return Form If you need to return one of our products for repair, please complete our RMA Request Form found on the support page of our website. DisplayPac-WN Hardware User Guide... - Page 20 Whether you’re looking for one of our standard products or a fully custom solution, Computer Dynamics has the breadth, experience and support to deliver what you need. For more than 25 years, CIMTEC Automation has been providing automation solutions throughout the world that deliver value, performance, and innovation.
