MiniRaQ
Installation Overview
(TM*)
Congratulations on your purchase of the MiniRaQ
is available in 4U, 6U and 8U sizes based on size and usage restrictions for a variety of
applications. The
MiniRaQ
It is designed to hold up to 400 pounds when properly installed for your most demanding
needs such as extended runtime battery back up systems, low profile power distribution
transformers, POE equipment and many other rack mountable products.
For installing the MiniRaQ
mentioned in this manual, please consult local building code requirements
Warning
to insure safe and secure installation.
(TM)
The MiniRaQ
System can be mounted on a variety of vertical substrates including
wooden framing studs 16" on center, solid or block concrete walls, and approved
plywood electrical panel or directly onto existing 2 Post racking. Please see detailed
instructions on the following pages.
Mounting hardware is provided for installing into solid wall studs and #12-24
screws for mounting on 2 Post rack. The
Back-to-Back configuration if clearances allow, which may increase U space utilization
in some instances.
Lances are incorporated into the
(TM)
MiniRaQ
to allow data and
power cable management for
input and output wiring using
either top or bottom egress,
as well as to facilitate service loops.
Large rear panel access allows
pass though cable routing in
2 Post Back-to-Back
mounting applications
Back-plate of
apparatus
is designed with
3 mounting options:
"A" hole pattern (10)
allows mounting
in standard 2 post open frame rack.
"B" Slots are centered at 16 inches
for #10 by 2" screws (10) into studs
or other solid wood surface.
"C" hole pattern (10)
accommodates
toggle bolts for mounting on block wall
or NEC electrical panel grade plywood.
All Trademarks are the property of their respective owners. *Patents pending.
(TM)
is designed from heavy gauge steel and finished to last a lifetime.
(TM)
System into any other surface not specifically
MiniRaQ
Built in level allows easy installation
for single service personnel
B
C
A
FIGURE 1
BlackHawk Labs, LLC Copyright 2007
www.miniraq.com
PAGE 1
(TM)
vertical rack system. The MiniRaQ
(TM)
can even be mounted in a 2 Post rack
Top access for data
or power cabling
The apparatus allows attachment
for 1U or 2U patch panel directly
inside the back-panel without
sacrificing any space in the mounting
surface of the side panels.
Earth Grounding Stud
integrated further
assisting quick and
convenient system install
Ancillary equipment, both rack
and non-rack mountable, can be
attached to the side of the
back-panel by hanging or screwing
onto the back-panel.
(TM)
