IDE 4000 Flash Disk
1.8" and 2.5"
Product Specification and User Manual
January 2005
34-PS-0304-00 Rev. 2.1

Advertisement

Table of Contents
loading

Related Manuals for M-Systems IDE 4000

Summary of Contents for M-Systems IDE 4000

  • Page 1 IDE 4000 Flash Disk 1.8" and 2.5" Product Specification and User Manual January 2005 34-PS-0304-00 Rev. 2.1...
  • Page 2 Added information for new 1.8” form factor Updated available capacity information Section 1.2.8 Updated reliability information Section 1.2.9 January 2, 2004 Updated supported temperature ranges Sections 1.3.1, 9 Update CHS settings information Section 1.2.8 Product Specification and User Manual IDE 4000 Flash Disk 34-PS-0304-00 Rev. 2.1...

  • Page 3: Table Of Contents

    7.1. Unpacking the Drive ..................... 18 7.2. Handling Instructions....................18 7.3. Installing the Drive in a PC ................... 18 7.4. Using the IDE 4000 in an MS-DOS-Based Platform ............ 19 7.5. Troubleshooting ......................19 7.6. How to Get Help ......................20 Product Specification and User Manual IDE 4000 Flash Disk 34-PS-0304-00 Rev.
  • Page 4 8. Warranty..........................21 9. Ordering Information ......................22 How to Contact Us ........................23 Product Specification and User Manual IDE 4000 Flash Disk 34-PS-0304-00 Rev. 2.1...

  • Page 5: Specifications

    PECIFICATIONS 1.1. Critical Item Definition The dimensions of the IDE 4000 flash disk enable mounting in a standard 2.5”or 1.8” disk drive bay, as described in Section 1.2.11. Note: The information written in this document refers to both IDE 4000 2.5” and 1.8” unless otherwise stated.

  • Page 6: Access Time

    1.2.4. Access Time Standby to active (typical.): 0.1 msec 1.2.5. Seek Time The IDE 4000 has no seek time, as it has no moving parts. 1.2.6. Input Voltage The IDE 4000 input voltage is 3.3VDC to 5.0VDC. 1.2.7. Current Consumption The current consumption at an input voltage of +5 VDC is described in Table 2.

  • Page 7: Memory Capacity

    Memory Capacity As of software version 1.09, the changes listed in Table 4 apply to the CHS (Cylinder, Heads, Sectors) settings for the IDE 4000, capacities 128MB to 512MB (there are no changes for other capacities). Table 4: CHS Settings for Low-Capacity IDE 4000...

  • Page 8: Endurance

    Memory Capacity (MB) 2.5” Unit Weight (g) 1.8” Unit Weight (g) 8192 1.2.11.2 Dimensions Table 8 describes the nominal dimensions of the IDE 4000. Refer to Figure 2 for detailed mounting configuration dimensions. Table 8: Nominal Dimensions Dimensions IDE 4000 2.5”...
  • Page 9 Figure 2: IDE 4000 2.5” Assembly Figure 3: IDE 4000 1.8” Assembly Notes: 1. All dimensions are in mm [in]. 2. General tolerance is ±0.25 mm [±0.01 in]. Product Specification and User Manual IDE 4000 Flash Disk 34-PS-0304-00 Rev. 2.1...
  • Page 10 1.2.11.3 Connector Interface The pinout for the IDE 4000 interface connector is detailed in Table 9 and in Figure 4. Table 9: J1 Pin Assignment Pin Number Signal Name Pin Number Signal Name RESET- HD10 HD11 HD12 HD13 HD14 HD15 N.C.

  • Page 11: Environmental Conditions

    1.3.1. Temperature 1.3.1.1 Operating The IDE 4000 operates without degradation at a pressure of 1 atm over the following ambient temperature range: • Commercial temperature version: 0°C to +70°C : for IDE 4000 2.5” and 1.8” • Extended temperature version: -40°C to +85°C :for IDE 4000 2.5”...

  • Page 12: Altitude

    1.3.2. Altitude The IDE 4000 sustains full operation at altitudes ranging from sea level to 80,000 feet above sea level. It is also capable of full operation during air transportation via non-pressurized flights at altitudes greater than 80,000 feet above sea level.

  • Page 13: Drive Configuration

    RIVE ONFIGURATION The IDE 4000 must be configured as shown in Figure 5 before being mounted in the system’s drive bay. Figure 5: IDE 4000 Disk Address Setting by Jumper Product Specification and User Manual IDE 4000 Flash Disk 34-PS-0304-00 Rev. 2.1...

  • Page 14: Interface Connectors

    NTERFACE ONNECTORS The IDE 4000 has a 2-mm pitch interface connector located on the rear panel. It accesses the DC power source and the IDE bus through a non-shielded 44-pin flat cable. Figure 6 provides an example of a connector that can be used to interface with this connector, but any compatible connectors may be used.

  • Page 15: Supported Ide Commands

    IDE C UPPORTED OMMANDS The IDE 4000 supports the commands listed in Table 11. Table 11: IDE Commands Command Name Command Code CHECK POWER MODE 98h E5h EXECUTE DEVICE DIAGNOSTIC FORMAT TRACK IDENTIFY DEVICE IDLE 97h E3h IDLE IMMEDIATE 95h E1h...

  • Page 16: Ce And Fcc Compatibility

    FCC C OMPATIBILITY The IDE 4000 complies with the following CE requirements and FCC standards: • FCC Part 15 Class B • EN 55022 Class B, CISPR 22 Class B (MIC) • V-3/2001.04 Class B (Japan), AS/NZS 3548 Class B (Australia/NZ) •...

  • Page 17: Label Information

    Figure 7: Outside Label CE and FCC logos Product name Unformatted capacity value M-Systems logo Ordering information Serial number, including date code Part number Declaration ESD warning logo and statement Product Specification and User Manual IDE 4000 Flash Disk 34-PS-0304-00 Rev. 2.1...

  • Page 18: Using The Ide 4000 Flash Disk

    Before unpacking or handling a drive, take all proper electrostatic discharge (ESD) precautions, including personnel and equipment grounding. Before you begin installing the IDE 4000 in your system, perform a visual inspection and follow the recommendations below: • If the shipping container appears to be damaged or water-stained, notify your dealer.

  • Page 19: Using The Ide 4000 In An Ms-Dos-Based Platform

    • Run the DOS FDISK program to partition the IDE 4000. • Run the DOS FORMAT command to high-level format the IDE 4000. • If you want the IDE 4000 to be a bootable drive, run the DOS SYS command and change the partition to active.

  • Page 20: How To Get Help

    Before contacting M-Systems directly, first contact your dealer (if you did not purchase you IDE 4000 directly from M-Systems). If your dealer cannot provide the help you need, you can obtain technical support directly from M-Systems at one of the numbers in the list of offices on the last page of this manual, or from the M-Systems website www.m-systems.com.

  • Page 21: Warranty

    ARRANTY The warranty period of the IDE 4000 is 36 months (3 years). For details, please refer to the warranty certificate, which is included with the IDE 4000. Product Specification and User Manual IDE 4000 Flash Disk 34-PS-0304-00 Rev. 2.1...

  • Page 22: Ordering Information

    Commercial: 0°C to +70°C (for 2.5” and 1.8”) Extended: -40°C to +85°C (for 2.5” only) Note: the IDE 4000 in a 1.8” casing is available only in commercial temperature range. Product Specification and User Manual IDE 4000 Flash Disk 34-PS-0304-00 Rev. 2.1...
  • Page 23 This document is for information use only and is subject to change without prior notice. M-Systems Flash Disk Pioneers Ltd. assumes no responsibility for any errors that may appear in this document. No part of this document may be reproduced, transmitted, transcribed, stored in a retrievable manner or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without prior written consent of M-Systems.
