- Page 1 Model ATK100 OPERATOR’S MANUAL SAFETY ASSEMBLY OPERATION MAINTENANCE ESPAÑOL Read Operator’s Manual. Do not operate equipment until you have read this Operator’s Manual for Safety, Assembly, Operation, and Maintenance Instructions. D26409 Rev. 0 4/28/02...
-
Page 2: Safety Guidelines - Definitions
SAFETY GUIDELINES - DEFINITIONS This manual contains indicates an imminently hazardous situation which, if not information that is avoided, will result in death or serious injury. important for you to know and indicates a potentially hazardous situation which, if not understand. - Page 3 HAZARD RISK OF LOSS OF HEARING WHAT COULD HAPPEN HOW TO PREVENT IT • Long term exposure to noise produced from the opera- • Always wear ANSI S3.19 hearing protection. tion of air tools can lead to permanent hearing loss. HAZARD RISK TO BREATHING INHALATION HAZARD WHAT COULD HAPPEN...
- Page 4 HAZARD RISK OF INJURY (continued) WHAT COULD HAPPEN HOW TO PREVENT IT • Improperly maintained tools and accessories can cause • Maintain the tool with care. serious injury. • Keep a cutting tool sharp and clean. A properly maintained tool, with sharp cutting edges reduces the risk of binding and is easier to control.
-
Page 5: Specifications
1/2” Impact Wremch SPECIFICATIONS Maximum Torque 260 ft./lbs Maximum Free Speed @ 90 PSI 7,000 RPM Maximum Working Pressure 90 PSI Air Inlet 1/4” NPT Recommended Hose Size 3/8” I.D. ASSEMBLY Accessories Required IMPORTANT: Line pressure or hose inside diameter should be increased to compensate for unusually long air hoses (over 25 feet). -
Page 6: Maintenance
MAINTENANCE Lubrication Air tools require lubrication throughout the life of the tool. The air motor and bearing uses com- pressed air to power the tool. Because moisture in compressed air will rust the air motor, you must lubricate the motor daily. An inline oiler is recommended. To lubricate the air motor manually: Disconnect the tool from the air supply holding it so the air inlet faces up. - Page 7 Select the required impact socket. This tool has a 3/8" square drive, use 3/8” sockets. Use 3/8” extensions only when needed. Connect tool to air hose of recommended size. NOTE: The use of a quick connect set makes connecting easier. IMPORTANT: The use of air filters and air line lubricators is recommended.
- Page 8 Air Hammer SPECIFICATIONS Blows Per Minute 4,500 Maximum Working Pressure 90 PSI Air Inlet 1/4" NPT Recommended Hose Size 3/8" I.D. ASSEMBLY Accessories Required IMPORTANT: Line pressure or hose inside diameter should be increased to compensate for unusually long air hoses (over 25 feet). Minimum hose diameter should be 3/8”...
- Page 9 MAINTENANCE Lubrication Air tools require lubrication throughout the life of the tool. The air motor and bearing uses com- pressed air to power the tool. Because moisture in compressed air will rust the air motor, you must lubricate the motor daily. An inline oiler is recommended. To lubricate the air motor manually: Remove chisel.
- Page 10 OPERATION Before each use: Throttle Control Lever Drain water from air compressor tank and condensation from air lines. See air Air Inlet Throttle compressor’s operators manual. Safety Disconnect the tool Release from the air supply before lubricating or changing grinding abrasive.
- Page 11 MAINTENANCE Lubrication Air tools require lubrication throughout the life of the tool. The air motor and bearing use compressed air to power the tool. Because moisture in compressed air will rust the air motor, you must lubricate the motor daily. An inline oiler is recommended.
-
Page 12: Limited Warranty
Service will be scheduled according to the normal work flow and business hours at the service center location, and the availability of replacement parts. All decisions of DeVilbiss Air Power Company with regard to this limited warranty shall be final.
