Instruction
manual
Patent No. 5,579,902 + Application
08/690,299 119 Germany
Patent No. DE 42 05 840 C2 Germany
Patent No. 5,196,747 USA
Patent No. EP 0 608 916 B1 Europe
Patent No. EP 0 794 038 A2 Europe
To learn more about Porter-Cable
visit our website at:
http://www.porter-cable.com
Copyright © 2002 PORTER-CABLE Corporation
ESPAÑOL: PÁGINA 11
FRANÇAISE : PAGE 21
Double Insulated
Rotary Hammer
IMPORTANT
Please make certain that the person who is
to use this equipment carefully reads and
understands these instructions before
starting operations.
The Model and Serial No. plate is located on the main
housing of the tool. Record these numbers in the
spaces below and retain for future reference.
Model No. ______________________________________
Type ___________________________________________
Serial No. _______________________________________
MODEL
7765
Part No. 902390 - 06-07-02
Advertisement
Table of Contents
Summary of Contents for Porter-Cable 7765
- Page 1 MODEL Patent No. EP 0 794 038 A2 Europe 7765 IMPORTANT Please make certain that the person who is To learn more about Porter-Cable to use this equipment carefully reads and visit our website at: understands these instructions before http://www.porter-cable.com starting operations.
-
Page 2: General Safety Rules
WARNING: SOME DUST CREATED BY POWER SANDING, SAWING, GRINDING, DRILLING, AND OTHER CONSTRUCTION ACTIVITIES contains chemicals known to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are: • lead from lead-based paints, • crystalline silica from bricks and cement and other masonry products, and •... -
Page 3: Specific Safety Rules And Symbols
Dress properly. Do not wear loose clothing or jewelry. Contain long hair. Keep your hair, clothing, and gloves away from moving parts. Loose clothes, jewelry, or long hair can be caught in moving parts. Avoid accidental starting. Be sure switch is OFF before plugging in. Carrying tools with your finger on the switch or plugging in tools that have the switch ON invites accidents. -
Page 4: Replacement Parts
When servicing use only identical replacement parts. MOTOR Many Porter-Cable tools will operate on either D.C., or single phase 25 to 60 cycle A.C. current and voltage within plus or minus 5 percent of that shown on the specification plate on the tool. Several models, however, are designed for A.C. -
Page 5: Extension Cord Selection
18-20 FUNCTIONAL DESCRIPTION FOREWORD Porter-Cable Model 7765 Rotary Hammer can be used for impact drilling and for light chiseling work in masonry, using SDS or SDS-Plus style bits up to "diameter or SDS or SDS-Plus style chisels. ASSEMBLY and OPERATION... -
Page 6: Reversing Switch
Fig. 1 Fig. 2 REVERSING SWITCH This model is provided with a reversing switch (C) Fig. 2. The machine will operate in either the “right-hand” direction (clockwise rotation) for drilling holes, or the “left-hand” direction (counterclockwise rotation) for freeing jammed drill bits. To change the direction of rotation: STOP the motor by releasing the trigger switch and move the reversing switch as far as it will go in the desired direction (as indicated by the arrows molded into the machine housing). - Page 7 Fig. 5 Fig. 6 DRILL / IMPACT DRILL The “Impact” (hammer) mechanism may be switched “ON” or “OFF”. NOTES: Release trigger switch and allow machine to stop before switching between “Drill” and “Impact Drill”. Left-Hand rotation when impact drilling will damage the machine Impact ON: Turn selector (E) Fig.
-
Page 8: Maintenance
CENTER. At approximately 100 hours of use, take or send your tool to your nearest Authorized Porter-Cable Service Station to be thoroughly cleaned and inspected; worn parts replaced, when necessary; relubricated with fresh lubricant, if required; reassembled with new brushes; and performance tested. -
Page 9: Service And Repairs
(model number, type, serial number, etc.). ACCESSORIES A complete line of accessories is available from your Porter-Cable • Delta Supplier, Porter-Cable • Delta Factory Service Centers, and Porter-Cable Authorized Service Stations. Please visit our Web Site www.porter- cable.com for a catalog or for the name of your nearest supplier. - Page 10 PORTER-CABLE LIMITED ONE YEAR WARRANTY Porter-Cable warrants its Professional Power Tools for a period of one year from the date of original purchase. We will repair or replace, at our option, any part or parts of the product and accessories covered under this warranty which, after examination, proves to be defective in workmanship or material during the warranty period.
- Page 11 Porter-Cable • Delta products should be obtained by contacting any Porter-Cable • Delta Distributor, Authorized Service Center, or Porter-Cable • Delta Factory Service Center. If you do not have access to any of these, call 888-848-5175 and you will be directed to the nearest Porter-Cable •...
