Summary of Contents for Perigee Power Solutions 7
- Page 1 User Manual Model: 007...
- Page 2 If the status bar indicates “low” see the Steps 3 & 4. The 201 modular battery pack may be connected to the 007 via the multi-port using our “Medium AUX battery MPI cable” (each sold separately). Image shows the 007 with panel connected &...
- Page 3 Using 110 AC The 007 does not ship with an internal inverter but it does support the use of one. Here are the options that allow you to use AC power with the 007. External 140W MSW inverter (12VDC Port) o Verify the inverter switch is in the “off”...
-
Page 4: Step 3 Checking Battery Condition
Perigee Power Solutions Solar Power Kit User Manual Step 3 Checking Battery Condition With Main Power to ON. Observe the LED Status Bar. Low (1-3 bars = 10.0V-10.5V, Batteries must be charged) Normal (4-7 bars = 10.6V-12.5V, normal operating range) Max (8-10 bars = 12.6V-14.5V, max battery capacity) - Page 5 Perigee Power Solutions Solar Power Kit User Manual Multiport Interfacing The multiport is capable of supporting many additional functions for all Perigee Products. You may link multiple kits together in parallel (very useful for our wall mount units), connect an auxiliary battery, use the port with a voltmeter to observe precise voltage levels, or connect to a compatible wind turbine.
- Page 6 The fuse is a standard auto type fuse that if tripped, will have a broken element that is visible when removed from the battery housing (or the dashboard as is the case with the 007).
- Page 7 Perigee Power Solutions Solar Power Kit User Manual Kit Duration Formula Battery duration formula based on total Amp hour and the Amp draw rate of a device you are interested in powering. Note: Puekerts Law is normally 90%. While this provides better formula results we modify to account for additional unknown variables such as environment, usage, &...
- Page 8 Perigee Power Solutions Solar Power Kit User Manual Battery Recharge Formula Derive the time it takes to recharge a battery from safe discharge level to a normalized state. Evaluate the following: Panel Wattage / Panel Voltage Rating = Amps (45W panel / 17.3V rating = 2.6A) 2.6 = panel amp rating...
-
Page 9: Limited Warranty
10% restocking fee derived from the original purchase price is applicable to all refunds. Please do not attempt to process returns from the store you purchased your kit. Ship to: Perigee Power Solutions 351 Green Ridge Road, New Oxford PA 17350. Send any return related questions to sales@perigeepower.com. Returns for purchases made on Amazon.com may be processed via their return request system. - Page 10 Perigee Power Solutions Solar Power Kit User Manual Specs: 1. Pelican Case 1150 • External Dimensions: 9.25"L x 7.56"W x 4.38"H • Weight < 7lbs (fully loaded with the following components) 2. Power Ports • Solar panel input color coded & keyed port •...
- Page 11 Perigee Power Solutions Solar Power Kit User Manual Notes: - 11 -...
-
Page 12: Contact Info
Panel Expansions (increases the kits solar recharge rate) Dual\Quad Delphi Daisy Chain Wiring Harness (supports additional panels for models 007-301) AC Wall Adapter (charge the from grid, 14Ah max &28Ah and up) Modular Battery Pack (201 swap use. 301/101/007 use via multi-port) Panel Extension Cable (12’...
