Precision SB15000OSP Owner's Manual page 2

Rules for Safe Operation
The following safety precautions are suggested. This broadcast spreader is designed, engineered
and tested to offer reasonably safe and effective service, provided that it is operated in strict
accordance with these instructions. Failure to do so may result in personal injury. Always observe
the rules of safe operation. Please read and retain this manual.
1. Do not allow anyone to operate the broadcast spreader without proper instructions.
2. Do not permit children to operate or ride on the broadcast spreader.
3. Wear eye and hand protection when handling or applying lawn or garden chemicals.
4. Read the chemical label instructions and cautions for handling and applying the chemicals
purchased for spreading.
5. Keep all nuts, bolts and screws tight to be sure equipment is in safe working condition.
6. Follow maintenance and lubrication instructions as outlined in this manual.
7. Always wear substantial footwear. Do not wear loose fitting clothing that can get caught in
moving parts.
8. Stay alert for holes in the terrain and other hidden hazards.
Operation
See Broadcast Spreader Operation and Application Chart, pages 4-6.
Maintenance Instructions
After each use, wash unit thoroughly, let dry. Lubricate all moving parts, including slide plate, axle
and upright shaft, with light oil.
Assembly Instructions
1. Remove Spreader from the carton.
2. This unit comes fully assembled.
2
26
10
18
21
16
1
15
8
22
11
12
2
28
SB15000OSP Broadcast Spreader
Ref. Part No. Qty. Description
1 3970 1 Hopper
2 2614 1 Spinner Disc
3 3971 1 Slide Plate
4 3972 1 Cover Plate
5 2564 1 Axle
6 3954 1 Gear Case Assembly
7 2148PU 1 Agitator Clip
8 2892RBG 1 Hopper Support
9 1660 2 1/4" x 1-1/4" Hex Head Bolt
10 5088GYG 1 Handle
11 2887RPG 1 Leg Stand
12 2546GYOS 1 Cross Brace
13 2890 2 Wheel
14 1040 2 Hubcap
25
26
7
15
15
3
4
20
23
19
9
24
5
17
27
6
Not all parts shown.
Ref. Part No. Qty. Description
15 1868 3 1/4" x 2-1/4" Carriage Bolt
16 2828 3 1/4" Wing Nut
17 1842 2 Axle Bushing Nylon Split
18 2444WC 1 Control Cable Assembly
19 1270 6 1/4" Hex Head Nut
20 6009 6 #6 x 3/4" Screw
21 1053 2 7/8" Tube Plug
22 3898 1 Shoulder Spacer
23 3899 1 .438 OD Washer
24 1060 2 Split Spacer
25 1086 4 1/4" X 2" Hex Head Bolt
26 1817 4 1/4" Flat Washer
27 1558 1 1/4" Nylock Nut
28 6129 1 1/4" x 1-1/2" Hex Head Bolt
7
13
14
